BEA LZR FLATSCAN S Manuel utilisateur

LZR®- FLATSCAN S

EN PLEASE KEEP FOR FURTHER USE - DESIGNED FOR COLOUR PRINTING

COMPACT LASER SCANNER

FOR PERIMETER AND WORK OF ART

PROTECTION

User’s Guide for software version SW 0100 and higher

(refer to tracking label on product)

INTRODUCTION

The FLATSCAN S is a laser sensor designed for the protection of work of art and other valuables and for the

protection of perimeters.

It generates an invisible curtain with 400 laser beams, which covers the detection area with a high

resolution.

DESCRIPTION

1. Front cover (protective cover)

2. Housing

3. Laser window

4. LED-signal

5. USB connector (only for factory use)

6. Visible laser beams

7. Cable gland

8. Bracket (optional)

detection error LED

LED ﬂashes LED is offpower on no power

LED ﬂashes quickly LED ﬂashes slowly

LED-SIGNALS

SYMBOLS

Caution!

Laser radiation

Remote control

sequence

Possible

remote control

adjustments

SAFETY TIPS

The device emits invisible (IR) and visible laser radiations. The visible

laser beams can be activated during the installation process to adjust

the position of the detection field.

Do not stare directly into the visible red beams.

The visible laser beams are inactive during normal functioning.

Factory values Attention Note

Do not stare into the visible

red laser beams.

Only trained and qualiﬁed

personnel may install and setup

the scanner.

The warranty is invalid if

unauthorized repairs are made

or attempted by unauthorized

personnel.

CAUTION!

Use of controls, adjustments or performance of procedures other than those speciﬁed herein may result

in hazardous radiation exposure.

INSTALLATION AND MAINTENANCE

0°C

°C

-10°C

Avoid the presence of

smoke and fog in the

detection ﬁeld.

Avoid condensation.

Avoid exposure to

sudden and extreme

temperature changes.

Avoid direct exposure

to high pressure

cleaning.

Do not use dry or dirty

towels or aggressive

products to clean

the laser window.

Clean the laser window

with compressed air.

When needed, wipe the

laser window only with

a soft, clean and damp

microﬁbre cloth.

Keep the scanner

permanently powered

in environments where

the temperature can

descend below -10oC.

Avoid extreme

vibrations.

Do not cover the laser

window.

Avoid moving objects

and light sources in

the detection ﬁeld.

INSTALLATION

MOUNTING

Please do a thorough inspection and evaluation of the installation area to make sure the

sensor's installation will suit the intended use.

Only remove the front cover right before putting the sensor into service.

Make sure the laser window is never covered.

The device cannot be used for purposes other than its intended use, and particularly not the protection of

persons. All other uses than those speciﬁed cannot be guaranteed by the manufacturer of the sensor.

2 WIRING

BLUE

RED+

BLACK

BROWN

GREEN

GROUNDING

CABLE

MONITOR TEST

YELLOW

WHITE

OUTPUT 1(OPTO)

PINK

GREY

VIOLET

OUTPUT 2(RELAY)

12-24V DC POWER SUPPLY

COM

Bracket installation (optional):

Prepare the bracket for the

installation.

Fix the Flatscan S to the bracket Choose an appropriate location

and install the sensor on a solid

surface.

* Output status when scanner is operational (Factory default connection)

Since there is no monitoring, the red and blue cables must be connected to the power supply

*2Grounding: make sure that the sensor is correctly earthed.

30 minutes after last use, the sensor locks the access to the remote control session.

Cut and restore power supply : the remote control session will be accessible again during 30 minutes.

4 2

teach-in

HOW TO USE THE REMOTE CONTROL

Before using the remote control, please check the following points:

1. The max. distance between the sensor and the remote control is 4 m.

2. The sensor's curtain should not be perpendicular to a high reﬂective surface. A 3-degree angle is necessary between them

to guarantee communication between the sensor and the remote control.

3. The authorized operator or installer can set a password to avoid unwanted modiﬁcations in the chosen settings

After unlocking, the red LED

ﬂashes and adjustments can

be made by remote control.

If the red LED ﬂashes quickly after unlocking, you

need to enter an access code (1 to 4 digits). To end an adjustment session,

always lock the sensor.

ADJUSTING ONE OR MORE PARAMETERS

CHECKING A VALUE

= ﬁeld width: 4.2 m

X = THE NUMBER OF FLASHES INDICATES THE VALUE OF THE PARAMETER.

RESTORING TO FACTORY VALUES

An access code is recommended for sensors installed close to each other.

SAVING AN ACCESS CODE

DELETING AN ACCESS CODE

After power on, you have 1 minute to choose this setting.

The setting will take effect 1 minute later.

SETTINGS

(1)

(2)

(3)

(4)

(5)

(6)

(11) Detection ﬁeld 1 (W)

(12) Detection ﬁeld 1 (H)

(13) Detection ﬁeld 2 (W)

(16) Check Values

(17) Lock

(18) Output conﬁguration

(20) Multifunction key * 2

(7)

(8)

(9)

(10)

(14) Detection ﬁeld 2 (H)

* 1

(15) Uncovered zone

(19) Antimasking & Background

(21) Immunity ﬁlter

(22) LED activation

Visible spot - alignment

Laser beam - detec�on

0-9 Number keys

Detection ﬁeld

Redirection

Plus

Unlock

Minus

Output activation delay

Min. object size

Detection area activation

Mounting side

Fog ﬁlter

* 1. Mounting side: right

* 2. Match with other keys to change among different

functions

VISIBLE SPOTS

turn on / off the visible spots.

• Check the sensor's wiring.

• Set power to on.

• Switch on the visible spots, then align the curtain position precisely (refer to remote control instruction).

If necessary, adjust the tilt angle (with the universal bracket) to make sure the curtain covers the whole

detection area

• The laser spots have an oval shape. The further the laser spot hits, the bigger the spot diffuses (see

diagram below).

The visible spots will be automatically deactivated after 10 minutes.

30 minutes after the installation, you will need to reboot the sensor to be able to re-activate the visible spots.

ALIGNMENT

Do not stare into the visible beams directly!

Please make sure the detection curtain is in the right position for the intended application.

left

right center

400

0 - 550 cm

400

0 - 550 cm

MOUNTING

SIDE rightleft center

The Flatscan S can be placed either on the left side, right side or in a central position.

DETECTION

FIELD

FIELD 1FIELD 2

Detection area: detection will only be triggered by objects located in the detection area.

The dimension of detection area can be adjusted via the parameter.

Please note that the detection range can be guaranteed with a 5% reﬂectivity @4m diagonal

when the fog ﬁlter value is set to 0.

If the fog ﬁlter value is not set to 0, then the guaranteed detection distance with 5%

reﬂectivity will be shortened.

FACTORY VALUES

> >

10 20 25 30 35 40 45 50

515

374 324 299 274 250400 349

510 15 20 25 30 35 408

Minimum object size: detection will only happen when the detected object size is

bigger than the given minimum object size.

MIN. OBJECT

SIZE

Output activation delay: the detection will generate an output only when the detection

lasts longer than the chosen time.

OUTPUT

ACTIVATION

DEL AY

100 400 500 600 700 800 9000200

Fog ﬁlter: you can change the max. detection distance with a 5% reﬂectivity.

FOG FILTER

off

UNCOVERED

ZONE

Uncovered zone: can be increased in case of snow, dead leaves, etc.

Measured in speciﬁc conditions and determined by application and installation.

IMMUNITY

FILTER

Immunity Filter: is increased to ﬁlter out environmental interferences such as rain or

snow which can trigger false detection.

low

ﬁltering

FACTORY VALUES

high

300

OFF

OFF OFF

NO NC

ﬁeld 1

FACTORY VALUES

NO NONC

R1 NC NO POWER

NO DETECTION

DETECTION

* R2

ﬁeld 1 ﬁeld 2

ﬁeld 2 ﬁeld 1

error

alarm

ﬁeld 1 or

ﬁeld 2

OFF ﬁeld 1 and

ﬁeld 2

Detection area activation: detection ﬁeld 1 or detection ﬁeld 2 can be actived or

deactived according to the application.

OUTPUT

CONFIGURATION

ANTIMASKING &

BACKGROUND

LED ACTIVATION

DETECTION

FIELD

REDIRECTION

DETECTION

AREA

ACTIVATION

LED OFF

NO = normally open

NC = normally closed

antimasking

background

Antimasking: when the laser window is covered, the sensor will enter the error mode.

Background: when the background has changed, the sensor will enter the error mode.

* R2 default connection: Pink/ Grey

error

alarm

ﬁeld 1 or

ﬁeld 2

LED ON

ﬁeld 2
