BE I2500 Manuel utilisateur
o p e r a t i o n m a n u a l
I2500_3500 Inverter Generator Manual_2011.indd 1 18/10/2011 2:03:43 PM
2
t a b l e o f c o n t e n t s
4 Using the Operators Manual
5 Inverter Generator
6 Safety Rules
6 Hazard Symbols and Meanings
11 Component Chart
12 Engine Oil
12 SAE Viscosity Grades
13 Fuel
14 Air Cleaner
15 Starting Your Inverter Generator
17 High Altitude Operation
17 General Operation
18 AC Application
19 Output and Overload Indicators
21 DC Applications
23 Starting the Engine
23 Oil Alert System
24 Stopping the Engine
25 Maintenance Schedule
26 Engine Oil Replacement
27 Air Cleaner Service
28 Spark Plug Servicing
I2500_3500 Inverter Generator Manual_2011.indd 2 18/10/2011 2:03:43 PM
3
t a b l e o f c o n t e n t s
4 Using the Operators Manual
5 Inverter Generator
6 Safety Rules
6 Hazard Symbols and Meanings
11 Component Chart
12 Engine Oil
12 SAE Viscosity Grades
13 Fuel
14 Air Cleaner
15 Starting Your Inverter Generator
17 High Altitude Operation
17 General Operation
18 AC Application
19 Output and Overload Indicators
21 DC Applications
23 Starting the Engine
23 Oil Alert System
24 Stopping the Engine
25 Maintenance Schedule
26 Engine Oil Replacement
27 Air Cleaner Service
28 Spark Plug Servicing
30 Transporting and Storage
30 When Transporting the Generator
30 Before Storing the Unit for an Extended Period
31 Spark Arrest Service
32 Engine will not start
33 The Equipment that connects to the
Generator doesn’t start
33 There is no power in the DC Electric Outlet
34 Deficient AC Output
35 Size and Weight
35 Engine
35 Generator
36 Wiring Diagram
37 Exploded Parts View I2500
38 Parts List I2500
40 Exploded Parts View I3500
41 Parts List I3500
I2500_3500 Inverter Generator Manual_2011.indd 3 18/10/2011 2:03:43 PM
4
i n t r o d u c t i o n
The operating manual is an important part of your generator and should
be read thoroughly before initial use, and referred to often to make sure
adequate safety and service concerns are being addressed.
Reading the owner’s manual thoroughly will help avoid any personal injury
or damage to your machine. By knowing how best to operate this
machine you will be better positioned to show others who may also
operate the unit.
This manual contains information for the complete range of BE
generators, and was written to take you from the safety requirements
to the operating functions of your machine. You can refer back to the
manual at any time to help troubleshoot any specific operating functions,
so store it with the machine at all times.
Attention: Read through the complete
manual prior to the initial use of your
generator.
I2500_3500 Inverter Generator Manual_2011.indd 4 18/10/2011 2:03:43 PM
5
p r o d u c t i d e n t i f i c at i o n
If you need to contact an Authorized Dealer or Customer Service line
(1-866-850-6662) for information on servicing, always provide the
product model and identification numbers.
You will need to locate the model and serial number for the machine and
record the information in the places provided below.
I2500_3500 Inverter Generator Manual_2011.indd 5 18/10/2011 2:03:43 PM
6
The safety alert symbol ( ) is used with a signal word (DANGER,
CAUTION, WARNING), a pictorial and/or a safety message to alert you
to hazards.
indicates a hazard which, if not avoided, will result in death or
serious injury.
indicates a hazard which, if not avoided, could result in death
or serious injury.
indicates a hazard which, if not avoided, might result in minor
or moderate injury.
indicates a situation that could result in equipment damage.
Follow safety messages to avoid or reduce the risk of injury or death.
Save these Instructions
s a f e t y
This is the safety alert symbol. It is used
to alert you to potential personal injury
hazards. Obey all safety messages that
follow this symbol to avoid possible
injury or death.
e x p l o s i o n
k i c k b a c k r e a d m a n u a l
f i r e e l e c t r i c s h o c k
t o x i c f u m e s
I2500_3500 Inverter Generator Manual_2011.indd 6 18/10/2011 2:03:45 PM
7
s a f e t y
Generator exhaust contains carbon monoxide, a
poisonous gas that can kill you.
You CANNOT smell or see this gas.
• Use the generator outdoors, away from open windows, vents, or
doors that could allow the carbon monoxide gas to come indoors.
Keep the generator at least 1 meter (3 feet) away from any structure
or building during use.
• NEVER use a generator indoors, including in homes, garages,
basements, crawl spaces, and other enclosed or partially-enclosed
areas, even with ventilation. Opening doors and windows or using
fans will not prevent carbon monoxide build-up in the home.
• NEVER use a generator in enclosed or partially-enclosed spaces.
Generators can produce high levels of carbon monoxide very quickly.
When you use a portable generator, remember that you cannot smell
or see carbon monoxide. Even if you can’t smell exhaust fumes, you
may still be exposed to carbon monoxide.
• NEVER operate the generator in an explosive atmosphere, near
combustible materials or where ventilation is not sufficient to carry
away exhaust fumes. Exhaust fumes can cause serious injury or death.
• If you start to feel sick, dizzy, or weak while using a generator, get
to fresh air RIGHT AWAY. DO NOT DELAY. The carbon monoxide
from generators can rapidly lead to full incapacitation and death.
• If you experience serious symptoms, get medical attention
immediately. Inform medical staff that carbon monoxide poisoning
is suspected. If you experienced symptoms while indoors, have
someone call the fire department to determine when it is safe to
re-enter the building.
I2500_3500 Inverter Generator Manual_2011.indd 7 18/10/2011 2:03:45 PM
8
s a f e t y
Fuel and its vapors are extremely flammable and
explosive.
Fire or explosion can cause severe burns or death.
• Observe all safety regulations for the safe handling of fuel. Handle
fuel in safety containers. If the container does not have a spout, use
a funnel.
• Do not overfill the fuel tank, leave room for the fuel to expand.
• Do not refill fuel tank while the engine is running. Before refueling the
generator, turn it off and let it cool down. Gasoline spilled on hot
engine parts could ignite.
• Fill the tank only on an area of bare ground. While fueling the tank,
keep heat, sparks and open flame away. Carefully clean up any spilled
fuel before starting engine.
• Always fill fuel tank in an area with plenty of ventilation to avoid
inhaling dangerous fumes.
• NEVER store fuel for your generator in the home. Gasoline, propane,
kerosene, and other flammable liquids should be stored outside of
living areas in properly-labeled, non-glass safety containers. Do not
store them near a fuel-burning appliance, such as a natural gas water
heater in a garage. If the fuel is spilled or the container is not sealed
properly, invisible vapors from the fuel can travel along the ground and
can be ignited by the appliance’s pilot light or by arcing from electric
switches in the appliance.
I2500_3500 Inverter Generator Manual_2011.indd 8 18/10/2011 2:03:45 PM
9
s a f e t y
The GFCI may not function unless the generator is properly
grounded. Follow the correct procedure specified in the section
labeled GROUNDING INSTRUCTIONS.
These generators are equipped with a GFCI (Ground Fault Circuit
Interrupters) 120V duplex receptacles for protection against the hazards
of electrical shock from defective attachments such as, tools, cords,
and cables.
A GFCI is a device that interrupts electricity from either the utility or
generator by means of a special type of circuit breaker that determines if
a current flow to the ground occurs.
A GFCI can be used only with generators that have the neutral wire
internally bonded to the frame, and the frame properly grounded to the
earth. A GFCI will not work on generators that do not have the neutral
wire bonded to the frame, or on generators which have not been properly
grounded. All BE generators have internally bonded ground wires.
I2500_3500 Inverter Generator Manual_2011.indd 9 18/10/2011 2:03:45 PM
10
s a f e t ys a f e t y
Improper grounding can result in a risk of electrocu-
tion. Check with a qualified electrician for your local
requirements if you are in doubt as to whether the unit
is properly grounded.
This generator is equipped with a grounding terminal for added
protection. Using the ground path from the generator to an external
ground source as instructed in the section labeled “Grounding
Instructions” in the Preparation section of this manual can be neces-
sary. Please consult a qualified electrician for local regulations.
The generator is a potential source of electrical shock if not kept dry.
Keep the generator dry and do not use in rain or wet conditions. To
protect from moisture, operate it on a dry surface under an open,
canopy-like structure. Dry your hands if wet before touching the
generator.
Plug appliances directly into the generator. Or, use a heavy duty,
outdoor-rated extension cord that is rated (in watts or amps) at least
equal to the sum of the connected appliance loads. Check that the
entire cord is free of cuts or tears and that the plug has all three
prongs,especially a grounding pin.
NEVER try to power the house wiring by plugging the generator into
a wall outlet, a practice known as “back feeding”. This is an extremely
dangerous practice that presents an electrocution risk to utility workers
and neighbors served by the same utility transformer. It also bypasses
some of the built-in household circuit protection devices.
If you must connect the generator to the house wiring to power
appliances, have a qualified electrician install the appropriate
equipment in accordance with local electrical codes.
This product has been designed with internal grounding or floating
bonded neutral. If it should malfunction or breakdown, grounding pro-
vides a path of least resistance for electric current to reduce the risk of
electric shock.
I2500_3500 Inverter Generator Manual_2011.indd 10 18/10/2011 2:03:46 PM
