BCM PPC15-525D Manuel utilisateur
PPC Series
15LQFKDQG:LQFK Touch Panel PC
Quick Reference Guide
4th– 03 March, 201
Copyright Notice
Copyright © 2011 BCM Advanced Research, ALL RIGHTS RESERVED.
Contents
1.1 Safety Precautions ................................................................................................3
1.2 Packing List ...........................................................................................................3
1.3 System Specifications ...........................................................................................4
1.4 System Overview..................................................................................................6
1.4.1 Front View.................................................................................................................... 6
1.4.2 Rear View..................................................................................................................... 7
1.5 System Dimensions..............................................................................................8
1.5.1 PPC 15” Series ........................................................................................................... 8
1.5.2 PPC 18” Widescreen Series ....................................................................................... 9
2.1 Jumper and Connector Setting, Driver and BIOS Installing.................................10
2.2 Installing Hard Disk & Memory ............................................................................11
2.2.1 Install 2.5” HDD......................................................................................................................... 11
2.3 Installing Panel PC Stand....................................................................................14
2.4 Installing Optional MSR Module ..........................................................................15
Quick Reference Guide
PPC Series Quick Reference Guide 3
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden power
surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
1.2 Packing List
z 1 x PPC 15”/18”W Series Panel PC
z 1 x CD/DVD-ROM contains the followings:
— Quick Reference Guide (this manual in PDF file)
— Ethernet driver and utilities
— VGA drivers and utilities
— Audio drivers and utilities
— WiFi drivers and utilities
— Touch controller drivers and utilities
z 1 x Power Adapter
z 1 x Stand for Panel PC (with 6 screws & 5 rubber-foot)
z 1 x MSR set with bracket (for optional MSR)
PPC Series
4 PPC Series Quick Reference Guide
Panel
Specifications PPC'PPC:'
LCD size 15", 4:3 18.5", 16:9
Display type XGA TFT WXGA TFT
Resolution 1024 x 768 1366 x 768
Color 16.7M 16.7M
Pixel pitch 0.297mm(H) x 0.297mm(V) 0.300mm(H) x 0.300mm(V)
Luminance 300 cd/m² 300 cd/m²
Contrast ratio 700 1000
Viewing angle 70(U), 70(D), 75(L), 75(R) 80(U), 80(D), 85(L), 85(R)
Response time 8 ms 5 ms
Backlight 2 x CCFL 2 x CCFL
Touch Type 5 Wires resistive 5 Wires resistive
Touch Light Transmission 80% 80%
Touch Interface USB USB
System
Board EBM-PNV
CPU Onboard Intel® Atom™ D525 Dual-Core 1.8 GHz CPU
System Chipset Intel ICH8-M
I/O Chip Winbond W83627DHG
Memory Onboard 1 GB up to 2GB & one 204-pin SODIMM support up to 4 GB DDR3
800 SDRAM2
SSD One CF socket by IDE secondary slave channel supports Type I / II Compact
Flash Card
HDD Drive Bay One 2.5" SATA HDD
WiFi Optional USB or Mini PCIe WiFi module
Watchdog Timer Reset: 1 ~ 255min. and 1sec. or 1min./step
H/W Status Monitor Monitoring system temperature and voltage. Auto throttling control when
CPU overheats
Expansion Slot One Mini PCIe slot
1.3 System Specifications
Quick Reference Guide
PPC Series Quick Reference Guide 5
Rear Panel I/O
Serial Port 1 x RS-232
Ethernet 1 x RJ-45
VGA 1 x DB-15
Audio port 1 x Line out
USB 2 x USB 2.0
KB/MS 1 x PS/2 KB & MS
Speaker 2W x 2
Mechanical & Evironmental
System Fan Passive Heat Sink
Color Front & Rear panel Black (Plastics)
Mounting Wall/Stand/VESA 100 mm X 100 mm
Power Input 100~250 Vdc/ 47~63 Hz
Power Output +12 Vdc / 5 A (60W)
Operating Temperature 0 to 40°C (32 to 140°F )
Storage Temperature -10°C to 50°C
Relative Humidity 0%~90% relative humidity, non-condensing
Dimensions 340 x 285 x 53 mm 372 x 324 x 53 mm
Weight 2.79 Kgs 3.79 Kgs
PPC Series
6 PPC Series Quick Reference Guide
1.4 System Overview
1.4.1 Front View
Note: The programmable function keys are available to be programmed by the
user, and they are unable to work unless programmed.
Quick Reference Guide
PPC Series Quick Reference Guide 7
1.4.2 Rear View
Connectors
Label Function Note
COM Serial port DB-9 male connector
DC in DC-in power connector
HDD HDD LED
LAN 10/100/1000Base-Tx Ethernet connector RJ-45
LAN/KBMS 10/100/1000Base-Tx Ethernet connector
or PS/2 keyboard & mouse
RJ-45 or 6-pin Mini DIN
LINE OUT Line-out audio jack
PWR Power LED
Reset Rest button
USB USB 2.0 connector
VGA CRT connector DB-15 female connector
PPC Series
8 PPC Series Quick Reference Guide
1.5 System Dimensions
1.5.1 PPC 15” Series
PPC Series
9 PPC Series Quick Reference Guide
1.5.3 PPC 18” Widescreen Series
(Unit: mm)
Quick Reference Guide
PPC Series Quick Reference Guide 10
1 Hardware
Configuration
2.1 Jumper and Connector Setting, Driver and BIOS
Installing
z Please refer to EBM-PNV Quick installation guide or user manual
Note: If you need more information, please visit our website:
http://www.EFPFRPFRP
