Bayside LAGOON Manuel utilisateur
V1.0 Muti –EU WS (01/2019)
BAYSIDE
LAGOON
CEILING FAN
INSTALLATION
OPERATION
MAINTENANCE
WARRANTY INFORMATION
CAUTION
READ INSTRUCTIONS CAREFULLY FOR SAFE
INSTALLATION AND FAN OPERATION.
Lagoon Fan Installation Instructions
1 | P a g e
CONTENTS
GB
Installation instruction manual ...........................................................................................2
D
Installationsanleitung ........................................................................................................10
F
Guide d’installation............................................................................................................20
E
Manual de instrucciones de instalación.............................................................................28
I
Manuale delle istruzioni di installazione............................................................................36
NL
Installatiehandleiding.........................................................................................................44
EL
Εγχειρίδιο οδηγιών εγκατάστασης ....................................................................................52
Lagoon Fan Installation Instructions
2 | P a g e
THANK YOU FOR PURCHASING
Thank you for purchasing this quality Bayside product. To ensure correct function and safety, please read
and save all instructions before using the product.
SAFETY PRECAUTIONS
1. In Europe: This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning the use of the appliance in a safe way and
understand the hazards involved. Cleaning and maintenance shall not be undertaken by children
without supervision.
2. In Australia: The appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning the use of the appliance by a person responsible for their
safety.
3. Children should be supervised to ensure that they do not play with the appliance.
4. An all-pole disconnection switch must be incorporated into the fixed wiring, in accordance with local
wiring rules.
IN AUSTRALIA
WARNING:
FOR SAFE USE OF THIS FAN AN ALL-POLE DISCONNECTION
MUST BE INCORPORATED INTO THE FIXED WIRING IN
ACCORDANCE WITH THE WIRING RULES.
As outline in clause 7.12.2 of AS/NZS 60335-1 for meeting the
minimum electrical safety of this standard.
Please note warranty will be void if installation is without a means for
an all-pole disconnection incorporated in the fixed wiring in
accordance with the wiring rules.
Lagoon Fan Installation Instructions
3 | P a g e
Example: If a fan is connected to a circuit that can be isolated via an
all-pole safety switch at the switchboard, then this is considered to be
an all-pole disconnection to the ceiling fan electrical circuit, meeting
the requirements of clause 7.12.2 of AS/NZS 60335.1.
A single-pole switch on the active of the receiver input of remote
control must also be included in the wiring, and located the
same room as the ceiling fan.
5. Do not dispose of electrical appliances as unsorted municipal waste, use separate collection
facilities. Contact your local government for information regarding the collection systems available. If
electrical appliances are disposed of in landfills or dumps, hazardous substances can leak into the
ground water and get into the food chain, damaging your health and well-being.
6. The structure to which the fan is to be mounted must be capable of supporting a weight of 30kg.
7. The fan should be mounted so that the blades are at least 2.3 m above the floor in Europe or 2.1 m
above the floor in Australia.
8. This fan is suitable for indoor, alfresco and coastal areas where the fan is fully undercover with a
minimum of 1 walls. This fan is not waterproof. When installed in an alfresco or coastal area, the
ceiling fan must be positioned in a location protected from water, wind and dust. Exposure to these
elements will void the warranty. Mounting the fan in a situation where it is subject to water or moisture
is dangerous.
9. Only a licensed electrician should execute the installation.
Lagoon Fan Installation Instructions
4 | P a g e
BEFORE INSTALLATION
Unpack your ceiling fan carefully. Remove all parts and hardware. Examine all parts, you should have
the following:
Fan without light
Fan with light
1
Mounting bracket x 1
1
Mounting bracket x 1
2
Pre-assembled fan motor and canopy x 1
2
Pre-assembled fan motor and canopy x 1
3
Blades x 3
3
Blades x 3
4
Wood screw x 2
4
GX53 lamp x 1
5
Motor screws for blades x 10
5
Wood screw x 2
6
Wall switch x 1 set
6
Motor screws for blades x 10
7
Wall switch x 1 set
Fig. 1
Lagoon Fan Installation Instructions
5 | P a g e
INSTALLING THE MOUNTING BRACKET
The ceiling fan must be installed in a location so that the blades are spaced 300mm from the tip of the blade
to the nearest objects or walls.
Secure the hanging bracket to the ceiling joist or structure that is capable of carrying a load of at least 30kg,
with two long screws provided. Ensure at least 30mm of the screw is threaded into the support.
NOTE: The bracket screws provided are for use with wooden structures only. For structures other than
wood, the appropriate screw type MUST be used.
Angled ceiling Installation
This fan hanging system DOES NOT support a degree angled ceiling installation.
Fig. 2
Lagoon Fan Installation Instructions
6 | P a g e
INSTALLING THE FAN
Blade attachment (Fig.3)
Secure the blade on the motor by using 3 screws to tighten it, ensuring they are tightened simultaneously.
(Take care not to over tighten as this can damage blades)
Once completed, repeat the process on the remaining blades.
Light kit installation (For fan with light) (Fig.4)
Install the globe (included, Max. 23W, GX53) in the lamp holder.
HANGING THE FAN
Lift the fan assembly to the mounting bracket (1) and let the J-hook (2) of the mounting bracket go through
the hole of the hanging canopy (3) and hang up the fan assembly. Fig. 5
Connect the male and female connector together (4). Fig. 5
Complete the electrical wiring using the diagram below (Fig.6).
Fig. 3
Fig. 4
Fig. 5
Lagoon Fan Installation Instructions
7 | P a g e
ELECTRICAL WIRING DIAGRAM
WARNING: FOR YOUR SAFETY ALL ELECTRICAL CONNECTIONS MUST BE UNDERTAKEN BY A
LICENSED ELECTRICIAN.
NOTE: AN ADDITIONAL ALL POLE DISCONNECTION SWITCH MUST BE INCLUDED IN THE FIXED
WIRING.
NOTE: Wiring diagram includes the light kit wiring. The light wiring diagram and switch is omitted
when no light kit is used with the ceiling fan.
USE WITH WALL SWITCH WIRING DIAGRAM:
USE WITH REMOTE WIRING DIAGRAM: (REMOTE sold separately)
1/ Remote without plugs
Fig. 6
Fig. 7
Lagoon Fan Installation Instructions
8 | P a g e
2/ Remote with plugs
FINISHING THE INSTALLATION
Loosen two screws (1) from the mounting bracket (5).
Loosen two screws (2) by half thread from the mounting
bracket (5).
Lift the hanging canopy (3) of the fan assembly up to
the mounting bracket and let the L-shape slot on the
hanging canopy go through the screws (2) on the
mounting bracket. Turn the hanging canopy until it locks
in place at the end section of the L-shape slot and
secure it by tightening the two screws (1). Avoid
damaging the electrical wiring prepared previously.
Finally attach the canopy cover (4) to the mounting
bracket, secure it by pushing the hooks of the canopy
cover into the slot holes of the hanging canopy and turn
it anti clockwise.
Fig. 9
Fig. 8
Lagoon Fan Installation Instructions
9 | P a g e
USING YOUR CEILING FAN
FAN WALL CONTROL
Turn on the power and check the operation of the fan.
• OFF Position – Fan off
• 3rd Position – Low fan speed
• 2nd Position – Medium fan speed
• 1st Position – High fan speed
Light Control
• Toggle Switch – On/off
REVERSING SWITCH
Your ceiling fan can operate in either summer or winter mode.
SUMMER Mode: The reverse switch shall be in the “down” (SUMMER) position to make the fan rotate in an
anticlockwise direction. The airflow will be directed downwards, for cooling in summer.
WINTER Mode: The reverse switch shall be in the “up” (WINTER) position to make the fan rotate in a clockwise
direction. The airflow will be directed upwards assisting in the circulation of warm air, for energy conservation in
winter.
AFTER INSTALLATION
WOBBLE:
NOTE: ceiling fans tend to move during operation due to the fact that they are mounted on a rubber grommet. If the
fan was mounted rigidly to the ceiling it would cause excessive vibration. Movement of a few centimetres is quite
acceptable and DOES NOT suggest any problem.
TO REDUCE THE FAN WOBBLE: Please check that all screws which fix the mounting bracket and down rod are
secure.
NOISE:
Fig. 11
Fig. 10
