Baumatic BMC460BGL Manuel utilisateur

BMC460BGL / BMC450SS

44 Litre, 46cm high

compact combination

microwave oven

User Manual for your Baumatic

BMC460BGL

BMC450SS

44 Litre, 46cm high

compact combination microwave oven

NOTE: This User Instruction Manual contains important

information, including safety & installation points, which will

enable you to get the most out of your appliance. Please keep it

in a safe place so that it is easily available for future reference; for

you or any person not familiar with the operation of the appliance.

GS 21/02/13

Contents

Environmentalnote 4

Important safety information 5 – 9

Specifications 10–12

Product and aperture dimensions 10

Productspecifications 10

Electricaldetails 10

Oven parts and accessories 11

Turntableinstallation 12

Controlpanel 12

Using your microwave oven 13 – 19

Functions 13

Settingtheclock 14

Beforefirstuse 14

Microwavecooking 14-15

Microwavepowerlevelchart 15

Timesettingchart 15

Power level cooking chart 16

Ovencooking 16-18

Fanovencooking 17-18

Grillcooking 16-17

Grill+fancooking 18

Bottom-heat+fancooking 18-19

Preheatingfunction 19

Combination cooking 20 - 29

Microwave and grill cooking 20

Microwave and fan oven cooking 21

Microwave and grill + fan cooking 22

Microwave and bottom-heat cooking 23

Otherfunctions ` 24-25

Auto-cookingmenu 24

Defrostfunction 25

Safetylock 25

Microwave cooking guidelines 26 – 27

Materials you can use in a microwave oven 27

Materials not to be placed in a microwave oven 28

Utensilstable 28

Cleaning and maintenance 29 - 30

Theapplianceexterior 29

The appliance interior 29

Turntable and turntable support 29

General cleaning advice 29 - 30

Installation 30 - 33

Electricalconnection 30-31

Aperture and ventilation requirements 32

Fixing the appliance into the housing unit 33

Troubleshooting 34–35

Baumatic consumables 36

Contactdetails 37

Environmental note

oThe packaging materials that Baumatic uses are environmentally

friendly and can be recycled.

all packaging material with due regard for the

environment.

oPlease discard

IMPORTANT SAFETY INFORMATION

Your safety is of the utmost importance to Baumatic.

Please make sure that you read this instruction booklet

before attempting to install or use the appliance. If you

are unsure of any of the information contained in this

booklet, please contact the Baumatic Customer Care

ent.

eneral Information

t or housing unit (see the section entitled

liance when the turntable and

nly use ovenware that is suitable for being used in a

microwave should be wiped dry

le materials. If left unattended, they could pose a

your microwave oven, if you

by Baumatic and outlined in this manual should be

where it is likely to come into contact with the elements.

Departm

oThis appliance is designed for domestic household use for

heating food and beverages. It can NOT be used as a

freestanding microwave and must be built in to a standard

kitchen cabine

“Installation”).

oYou should only operate the app

turntable support are in position.

oYou should o

microwave.

oTo prevent corrosion occurring due to moisture/condensation,

the cavity and the door of the

after each use of the appliance.

oThe appliance must not be left unattended if you are heating or

cooking food in containers that are made of paper, plastic or

other flammab

fire hazard.

oIf you notice smoke coming from the appliance, you should keep

the door of the microwave closed and then disconnect it from

your mains supply. DO NOT use

think it is not operating correctly.

Installation

oIMPORTANT: Only the built in/built under installation

sanctioned

followed.

oDo not attempt to use your appliance outdoors or any place

oIMPORTANT: The adjacent furniture or housing and all

materials used in the installation must be able to withstand a

minimum temperature of 85°C above the ambient temperature

of the room it is located in, whilst in use.

oDo not attempt to use your appliance outdoors or any place

where it is likely to come into contact with the elements.

oCertain types of vinyl or laminate kitchen furniture are

particularly prone to heat damage or discolouration at

temperatures below the guidelines given above.

oAny damage caused by the appliance being installed in

contravention of this temperature limit, or by placing adjacent

cabinet materials closer than 4mm to the appliance, will be the

liability of the owner.

oFor use in leisure accommodation vehicles, please refer to

the appropriate information given in the installation instructions

for this appliance.

oThe use of this appliance for any other purpose or in any other

environment without the express agreement of Baumatic Ltd.

will invalidate any warranty or liability claim.

oYour new appliance is guaranteed against electrical or

mechanical defects, subject to certain exclusions that are noted

in Baumatic’s Conditions Of Guarantee. The foregoing does not

affect your statutory rights.

Service

oYour microwave complies with all relevant safety standards. In

order for it to continue to operate safely, only an engineer that

is approved by the Baumatic Customer Care Department

should work on the appliance.

oIMPORTANT: It is dangerous for a non qualified person to work

on the appliance, in particular if they remove the cover that

provides protection against exposure to microwave energy.

oIf you notice that the door seal, door surfaces, power cord and

plug are damaged. You should stop using the appliance,

disconnect it from the mains supply and contact the Baumatic

Customer Care Department.

oOnly genuine Baumatic spare parts should be fitted to your

appliance. These can be obtained from the Baumatic Spares

Department.

Warning and safety instructions

oThis appliance complies with all current European safety

legislation. Baumatic do wish to emphasise that this compliance

does not remove the fact that the appliance surfaces will

become hot during use and retain heat after operation.

oDO NOT place anything between the door and the door frame.

oDO NOT store anything that is flammable inside of the

microwave. When it is switched on, the items could catch fire.

oDO NOT switch the appliance on if there is no food or liquid

inside of the microwave. If you run the microwave whilst it is

empty, there is a chance that it will overload.

oThe door seals and the door surfaces should ALWAYS be kept

clean and free from debris.

Child Safety

oBaumatic strongly recommend that babies and young children

are prevented from being near to the appliance and not allowed

to touch the appliance at any time.

oIf it is necessary for younger family members to be in the

kitchen, please ensure that they are kept under close supervision

at all times.

oIMPORTANT: This appliance should only be operated by adults.

You SHOULD NOT allow young children to use the microwave

without supervision. Older children should only operate the

appliance if they have been thoroughly instructed on how to use

the microwave and the consequences of improper usage.

General Safety

oDo not allow electrical fittings or cables to come into contact

with areas on the appliance that get hot.

oDo not use the appliance to heat the room it is located in.

oDo not use the appliance to dry paper, textiles or animals.

oDo not install the appliance next to curtains or soft furnishings.

oDo not use the appliance to heat unopened bottles or cans etc.

oDo not use corrosive chemicals or vapours in this appliance. This

oven is especially designed to heat. It is not designed for

industrial or laboratory use.

oDo not heat cooking oil or liquid containing alcohol, as there is

the chance of spontaneous combustion.

oDo not boil eggs or similar foods in their shells, otherwise they

may burst. It is possible to poach eggs in your microwave,

providing you prick the yolks first.

oDo not attempt to lift or move cooking appliances by using the

oven door, as this may cause damage to the appliance or result

in injury to the person lifting the appliance.

Cleaning

oCleaning of the oven should be carried out on a regular basis.

oGreat care should be taken whilst using this appliance and when

following the cleaning procedure.

oIMPORTANT: The appliance must be disconnected from the

mains before following the cleaning procedure.

Installation

This appliance must be correctly installed by a

suitably qualified person, strictly in accordance

with the manufacturer’s instructions.

oBaumatic Ltd. declines any responsibility for injury or

damage, to person or property, as a result of improper

use or installation of this appliance.

oHeat, steam and moisture will be created during use of the

appliance, take care to avoid injury and ensure that the room is

adequately ventilated. If the appliance is going to be used for

prolonged periods of time, then additional ventilation may be

required.

oPlease consult with your qualified installer if you are in any doubt

about the amount of ventilation that you will require.

Declaration of conformity

This appliance complies with the following European Directives:

- 2006/95/EC regarding “low voltage”

- 2004/108/EC regarding “electromagnetic disturbances”

- Regulation (EC) N° 1935/2004 regarding “materials in contact with

food”

oThe above directives comply with 93/68/EEC regarding CE

marking.

oThe manufacturer declares that the oven is built using certified

materials and requires the appliance to be installed in

accordance with the standards currently in force. This appliance

must be used by a trained person for domestic purposes only.

Specifications

Product dimensions Aperture dimensions

Height: 454.5 mm Height: 450 mm (built in)

Width: 594 mm 458+2 mm MIN

(built under)Depth: 568 mm

Width: 560 mm

Depth: 550 mm MIN

Product specifications

o9 cooking functions

o15 auto functions

o5 power levels

oLED temperature and function display

oKnob and touch control operation

oSafety lock

oCapacity: 44 litres

oMicrowave output: 900 W

oGrill output: 1750 W

oHot air output: 1750 W

Standard accessories

oShort grill rack

oLong grill rack

oTrivet (For use as a base shelf for oven cooking, or to be used

with the GTR46 glass tray)

Optional extra

oGTR46 Glass tray

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Baumatic Four à micro-ondes

Baumatic

Baumatic BTM23.1SS Manuel utilisateur

Baumatic

Baumatic PMC355SS Manuel utilisateur

Baumatic

Baumatic BTM17.1SS Manuel de l'opérateur

Baumatic

Baumatic BTM17.3SS Manuel utilisateur

Baumatic

Baumatic BTM34SS Manuel utilisateur

Baumatic

Baumatic BTM25.5SS Manuel utilisateur

Baumatic

Baumatic GMGI250SS Manuel utilisateur

Baumatic

Baumatic BTM25.2M Manuel utilisateur

Baumatic

Baumatic BTM25.5SS 25 Manuel utilisateur

Baumatic

Baumatic BAM28TK- 2 Manuel utilisateur

Baumatic

Baumatic BTM17.5SS Manuel utilisateur

Baumatic

Baumatic BMIG3825 Manuel utilisateur

Baumatic

Baumatic BS099 Manuel utilisateur

Baumatic

Baumatic BTM24 Mode d'emploi

Baumatic

Baumatic BMC253SS Manuel utilisateur

Baumatic

Baumatic BSCM45-ANZ Manuel utilisateur

Baumatic

Baumatic BTM17.2SS Manuel de l'opérateur

Baumatic

Baumatic BTM23SS Mode d'emploi

Baumatic

Baumatic BMM174SS Manuel utilisateur

Baumatic

Baumatic BMC253SS Manuel utilisateur

Baumatic

Baumatic BTM25.5SS Manuel utilisateur

Baumatic

Baumatic BTM21SL Manuel de l'opérateur

Baumatic

Baumatic BMCI300SS Manuel utilisateur

Baumatic

Baumatic BTM25.3SS Manuel utilisateur

Manuels Four à micro-ondes populaires d'autres marques

Daewoo

Daewoo KOG-574R0S Manuel utilisateur

LG MH7040SS Manuel utilisateur

Sharp

Sharp R-895(AL)M Manuel utilisateur

Dometic

Dometic DOTRM13W Manuel utilisateur

Sanyo

Sanyo EM-X680 Manuel utilisateur

Sharp

Sharp R-393M Manuel utilisateur

KitchenAid

KitchenAid KMCX4510 Instructions d'installation

Smeg

Smeg S45MCX1 Manuel utilisateur

Russell Hobbs

Russell Hobbs RHM2044 Manuel utilisateur

Sunbeam

Sunbeam SMW759 Manuel utilisateur

Gallet

Gallet FMOE230S Manuel utilisateur

Bosch

Bosch CEG732X.1B Manuel utilisateur

Dometic

Dometic Roadmate 230 Manuel utilisateur

Samsung

Samsung SJ0396W Manuel utilisateur

Sanyo

Sanyo EM-P494WS Manuel utilisateur

Sharp

Sharp R-240 Manuel utilisateur

Electrolux

Electrolux EMS2840 Manuel utilisateur

Daewoo

Daewoo KOC-984T2S13 Manuel utilisateur
