Baumatic Pythagora P61SS Manuel utilisateur

P61SS/P62SS Pythagora 60cm

gas hob

P67SS/P68SS Pythagora 70cm

gas hob

User Manual for your Baumatic

P61SS/P62SS Pythagora 4 burner 60cm

gas hob

P67SS/P68SS Pythagora 5 burner 70cm

gas hob

You will be mine

NOTE:This User Instruction Manual contains important

information, including safety & installation points, which will

enable you to get the most out of your appliance. Please keep it

in a safe place so that it is easily available for future reference; for

you or any person not familiar with the operation of the appliance.

DD 27/10/06

Contents

Environmental note 4

Important safety information 5 – 7

Specifications 8

Product & Aperture dimensions 8

Product specifications 8

Standard accessories 8

Electrical details 8

Gas details 9

Gas hob surface layout 9

Using the gas hob 10

Before first use 10

Turning the hob on 10

Automatic electric ignition 10

Energy saving tips 11

Cleaning 12

Cleaning the hob top 12

After each use 12

Cleaning the hob burners 12 - 13

Installation 13

Positioning 14

Unpacking the appliance 15

Installing the appliance 15 – 17

Gas connection 17

Ventilation requirements 18

Gas Safety (Installation and Use) Regulations 18 – 19

Gas Adjustment (Conversion to LPG and flow adjustment) 19 – 20

Gas tap maintenance 20 - 21

Electrical connection 21

Replacing the mains supply cable 22

My appliance isn’t working correctly 23

Baumatic Ltd. Conditions of Guarantee 24

Contact details 25

Environmental note

oThe packaging materials that Baumatic uses are environmentally

friendly and can be recycled.

oPlease discard all packaging material with due regard for the

environment.

Important safety information

Your safety is of the utmost importance to Baumatic.

Please make sure that you read this instruction booklet

before attempting to install or use the appliance. If you

are unsure of any of the information contained in this

booklet, please contact the Baumatic Technical

Department.

General Information

oThis appliance is designed for domestic household use and for

the cooking and frying of domestic foodstuffs.

oIMPORTANT: The adjacent furniture and all materials used in

the installation must be able to withstand a minimum

temperature of 85°C above the ambient temperature of the

room it is located in, whilst in use.

oCertain types of vinyl or laminate kitchen furniture are

particularly prone to heat damage or discolouration at

temperatures below the guidelines given above.

oAny damage caused by the appliance being installed in

contravention of this temperature limit, will be the liability of

the owner.

oYour new appliance is guaranteed against electrical or

mechanical defects, subject to certain exclusions that are noted

in Baumatic’s Conditions Of Guarantee. The foregoing does not

affect your statutory rights.

oThe use of this appliance for any other purpose or in any other

environment without the express agreement of Baumatic Ltd.

will invalidate any warranty or liability claim.

oYou should not use this appliance to store items on or as a work

surface.

oNo modifications to the appliance are permitted by Baumatic Ltd.

oYou should not store or place flammable or highly flammable

liquids/materials on top of or near the appliance. Items made

from aluminium, plastic or plastic film should also be kept away

from the appliance, as they may fuse to the surface.

oRepairs may only be carried out by Baumatic Service

Engineers or their authorised service agent.

Child Safety

oBaumatic strongly recommend that babies and young children

are prevented from being near to the appliance and not allowed

to touch the appliance at any time. During and after use, all

surfaces will become hot.

oIf it is necessary for younger family members to be in the

kitchen, please ensure that they are kept under close supervision

at all times.

oOlder children should only be allowed to utilise the appliance

when supervised.

General Safety

The appliance should only be installed and connected by a

CORGI registered installer.

Care should be taken to ensure that the units and work surfaces

that you build the appliance into, meet with the relevant

standards.

During use

Any film or stickers that are present on the hob surface when it

is delivered should be removed before use.

Care should be used when utilizing the appliance, otherwise

there is a risk of burns being caused.

oYou should not allow the electrical connection cables to come

into contact with the hob surface when it is hot or any hot

cookware.

oIf fat and oil overheats, then it can ignite extremely quickly. For

this reason, when cooking with fat and oil the appliance should

not be left unattended.

Make sure that all of the cooking zones are switched off after

use.

Cleaning

oCleaning of the hob should be carried out on a regular basis.

oIMPORTANT: Before attempting to clean the appliance, it

should be disconnected from the mains and cool.

oGreat care should be taken whilst using this appliance and when

following the cleaning procedure.

oYou should not use a steam jet or any other high pressure

cleaning equipment to clean the appliance.

Installation

This appliance must be correctly installed by a

CORGI registered installer, strictly in accordance

with the manufacturer’s instructions and the

relevant British Standards. Please see the specific

section of this booklet that refers to installation.

oBaumatic Ltd. declines any responsibility for injury or

damage, to person or property, as a result of improper

use or installation of this appliance.

oIf the appliance is being used in a Leisure Accommodation

Vehicle, the requirements of N 721 MUST be followed.

oBaumatic Ltd. DO NOT recommend that this appliance is

installed on any type of marine vessel.

Declaration of conformity

This appliance complies with the following European Directives:

-73/23/EEC dated 19/02/1973 Low Voltage Directive.

-89/336/EEC dated 03/05/1989 EMC Directive inclusive of

Amending Directive 92/31/EEC.

-93/68/EEC dated 22/07/1993 CE Marking Directive.

-89/109/EEC dated 25/01/1992 Materials that can touch food.

-90/396/EEC Gas Products.

-EN60335-1, EN60335-2, EN301-1 Safety Standards.

The manufacturer declares that the hob is built using certified

materials and requires the appliance to be installed in accordance with

the standards currently in force. This appliance must be used by a

trained person for domestic purposes only.

Specifications

P61SS & P62SS

Product dimensions:

Height: 500 mm

Width: 585 mm

Depth: 35 mm

Aperture dimensions:

Height: 480 mm

Width: 560 mm

P67SS & P68SS

Product dimensions:

Height: 500 mm

Width: 685 mm

Depth: 35 mm

Aperture dimensions:

Height: 480 mm

Width: 560 mm

Product specifications:

o1 x 3.30 kW triple crown wok burner

o2 x 1.75 kW semi-rapid burners

o1 x 1.00 kW auxiliary burner

o1 x 3.00 kW rapid burner (P68SS only)

oFlame failure safety device on each burner

oFront control operation

oHeavy duty cast-iron pan stands

oUnderknob auto-ignition

Standard accessories:

oLPG Conversion jets

oWok Stand

Electrical details

Rated Voltage: 230 Vac 50 Hz

Supply Connection: 3 A (double pole switched fused outlet with

3mm contact gap)

Max Rated Inputs: 0.008 to 0.02 kW (depending on model)

Mains Supply Lead: 3 core x 0.75mm²

Gas details

Connection: Rp ½ (ISO R7)

Type: Natural Gas (20.9 mbar), alternative LPG G30

(28-30 mbar), town gas G110 – 120 (8 mbar)

to order.

For future reference please record the following information which can

be found on the rating plate and the date of purchase which can be

found on your sales invoice. The rating plate of your hob is located on

the underneath of the appliance. Therefore it is a good idea to record

this information before you install your appliance.

Model Number ……………………………….

Serial Number ……………………………….

Date of Purchase ……………………………….

Gas hob surface layout

P61SS & P62SS

P67SS & P68SS

Using the gas hob

IMPORTANT: You should clean the hob surface (see

“Cleaning and maintenance” section).

The following symbols will appear on the control panel, next to each

control knob:

Black circle: gas off

Large flame: maximum setting

Small flame: minimum setting

oThe minimum setting is at the end of the anti-clockwise rotation

of the control knob.

oAll operation positions must be selected between the maximum

and minimum positions.

oNever select a knob position between the maximum and off

position.

Automatic electric ignition

To ignite a burner:

oPress in the control knob of the burner that you wish to light and

turn it anti-clockwise to the minimum position.

oIf you keep the control knob depressed, the automatic ignition

for the burner will operate.

oAs each burner has a flame failure safety device, once the burner

has lit, you will need to keep the control knob pressed in for

approximately 10 seconds.

oIf after you let go of the control knob, the flame goes out, you

should repeat the above process.

oIn case of power failure, the burners can be lit by carefully using

a match.

oIf the burner flame goes out once it is lit, then the flame failure

safety device will cut the supply of gas to the burner.
