Quick Start Guide

MODEL: 75QLEDSM20

75” ULTRA HD

ANDROID TVTM

Attach the TV stand

Which plug goes where?

Have you got everything?

Unpack the box (be gentle) and make sure all of these items are there:

Unless you are wall-mounting the TV, you will need to

attach its stands/legs. If you do want to wall mount the TV,

see page 7 of the User Manual.

Want to hook up your new TV to the internet, a DVD player or something else?

Use the basic guide below to see what the plug and port should look like for dierent

connections.

You can ﬁnd more of these on pages 10 - 11 of the User Manual.

(These cables do not come with your TV, however we have included a mini AV adaptor for you)

Use this to connect your soundbar, ampliﬁer, digital

receiver, or other external audio equipment.

Use this connection for a DVD player, gaming console,

computer and camera.

To watch free-to-air TV channels, you need an antenna

connection.

Use this to connect the TV to your modem for internet

access. This TV also has Wi-Fi connectivity.

Lay the TV face-down on a soft,

ﬂat surface (like the sofa, or a

towel on a table) larger than the

TV itself.

Match the stands to the

installation points on the

underside of the TV.

Attach the stands to the TV at

the installation points using

the screws provided.

(Grab a screwdriver

for this bit).

A. 75” Ultra HD Android TV

B. Remote Control

C. AAA Batteries (2)

D. Mini AV Adaptor

E. TV Stands (2)

F. Screws for TV Stand (4)

G. Warning Sheet

H. TV Toppling Safety Message

I. Quick Start Guide

J. Warranty Certiﬁcate

K. General Safety Warnings

L. User Manual

You will also need:

• Phillips-head screwdriver

• Someone to help lift the TV

HIJKL

This TV is heavy!

We recommend asking

someone to help you lift it.

Get to know the remote

Uh-oh, this isn’t right...

Is it plugged in?

Look at the manual!

Ok, time to give us a call

On-screen set-up

Set-up not going smoothly? We’ve got you!

We just need you to check a few things ﬁrst:

A new TV is exciting! So it’s easy to forget

something simple - like plugging it into the power

outlet. Psst... make sure the outlet is switched ON.

More often than not, the answer you need is right there in the User Manual.

The troubleshooting section on pages 44 - 46 may come in handy for tricky stu.

Your new TV is ready to enjoy!

Well done, you made it.

Now sit back and relax... your new TV is automatically covered

by a 3-year warranty. How nice!

Familiarise yourself with the remote control - you’ll be

spending a lot of time together.

Here are some of the buttons you’ll be using most often.

What? You mean the User Manual didn’t have ALL the answers? Speak to

us! We’d love to help you get up and running as quickly as possible.

Call our After Sales Support on 1300 886 649.

Operating hours: Monday-Friday, 8:30am-6pm; Saturday, 9am-6pm AEST

Point the remote

control at the

sensor on the TV.

Follow the on-screen set-up prompts to pair

voice-enabled remote with the TV, connect

the TV to the internet, sign in to Google

Account and tune TV channels.

How to pair the remote control:

1. Press and hold the LEFT and MENU buttons simultaneously for 5 seconds.

2. When the name of the remote control appears on the screen, select the name

and press the OK button.

3. If pairing is unsuccessful, please wait a few seconds and try again or you can

do this later by going to Settings > Remotes & Accessories.

Navigate and

select/conﬁrm

Change the

channel

Launch Netﬂix and

YouTube apps

Switch between

input source signals

On/Standby

Access Android

TV home screen

Enter on-screen

Summon the

Google Assistant

Adjust the

volume

REC
