BasIP SP-02 Manuel utilisateur

SP-02

Exported on 07/11/2019

– 2
Table of Contents
Device description................................................................................................ 5
Technical parameters.......................................................................................... 6
Main features ................................................................................................................................. 6
Functional capabilities ............................................................................................................... 6
Configuration throught web interface...........................................................7
Login ..................................................................................................................................................7
Main ....................................................................................................................................................7
System information......................................................................................................................................................7
Registration status .......................................................................................................................................................7
Configuration................................................................................................................................. 8
Network/Print logs settings .....................................................................................................................................8
Network settings...........................................................................................................................................................9
Log display settings.....................................................................................................................................................9
Network applications ..................................................................................................................................................9
Phone settings .............................................................................................................................................................10
SIP/NAT settings.......................................................................................................................................................... 11
SIP settings..................................................................................................................................................................... 11
Emergency call settings ............................................................................................................................................ 11
NAT settings .................................................................................................................................................................. 11
Dial plan settings......................................................................................................................................................... 12
Speed dial ...................................................................................................................................................................... 13
Provisioning Settings................................................................................................................................................. 13
SIP accounts settings ................................................................................................................................................ 14
Call settings................................................................................................................................................................... 15
Audio settings .............................................................................................................................................................. 16
Admin settings.............................................................................................................................16
Dial a number ............................................................................................................................................................... 17
Dial a number ............................................................................................................................................................... 17
Dialed calls..................................................................................................................................................................... 17
Chat.................................................................................................................................................................................. 18
Chat historty ................................................................................................................................................................. 18
Phone number.............................................................................................................................................................. 18

– 3
Message to send.......................................................................................................................................................... 18
Firmware upgrade...................................................................................................................................................... 19
Firmware upgrade...................................................................................................................................................... 19
Configuration upgrade ............................................................................................................................................. 19
Configuration Backup ............................................................................................................................................... 19
Setup password........................................................................................................................................................... 19
Reboot ...........................................................................................................................................................................20
Restore default ...........................................................................................................................................................20

– 4

•Device description(see page 5)

•Technical parameters(see page 6)

•Configuration throught web interface(see page 7)

Device description– 5

Device description

SIP handset BAS-IP SP-02P supports P2P SIP and SIP 2.0.

On the handset there is a button for quick access to the concierge, programmable buttons for

calling other subscribers and a button for opening the lock.

Also, this SIP handset has a call waiting function, an emergency call function, a "do not disturb"

mode and a doorbell.

Technical parameters– 6

Technical parameters

Main features

Number of VoIP accounts supported: 2

Supported protocol type: IPv4 and IPv6

Network connection: 1 PoE port IEEE 802.3af

Power supply: 1 PoE port IEEE 802.3af

Type of supported codecs: G.711μ/ A; G.722; ILBC; G.729

Sound processing algorithms: VAD; CNG; AEC; PLC; AJB; AGC

Additional function: Doorbell

Audio Transmission Method: Full Duplex

Number of control keys: 3

Configuration and programming method: WEB-interface

Installation Method: Wall and Desktop

Dimensions: 203 × 55 × 55 mm

Available colors: Black, White

Functional capabilities

Answering machine: Yes

Software update: Via Ethernet

Optional: Connecting the call button; SIP P2P, Do not disturb mode

Configuration throught web interface– 7

Configuration throught web interface

To enter the WEB interface of the handset, you need to connect it to the router, wait for the

download and pick up the handset. If there is a dial tone on the handset, it received an IP

address via DHCP. If there is no dial tone, you need to check that the DHCP mode is enabled on

the router.

In order to find out the IP address of the device, you need to pick up the phone and enter the

combination *12345#. The speaker will be announced a sequence of numbers in English.

Next you need to enter the IP-address in the address bar of the browser, username and

password.

Main

After entering the WEB interface, the following menu will be displayed:

System information

Product: Device Model.

MAC address: MAC address.

IP address: IP address of the handset.

Hardware Version: The current hardware version of the hardware.

Firmware datecode: Software Version.

Registration status

By default login is admin and password admin.

Configuration throught web interface– 8

Account 1, 2: Registration status of the account.

Also this menu has tabs:

Home: Current Menu

Admin:Advanced configration menu.

Configuration:Basic configuration menu.

Call Log: All Calls Menu.

Configuration

This menu shows the main settings of the device.

•Network/Print logs settings(see page 8)

•Network applications(see page 9)

•Phone settings(see page 10)

•SIP/NAT settings(see page 11)

•Dial plan settings(see page 12)

•Speed dial(see page 13)

•Provisioning Settings(see page 13)

•SIP accounts settings(see page 14)

•Call settings(see page 15)

•Audio settings(see page 16)

Network/Print logs settings

In this menu, the basic network settings and the log display are set.

Configuration throught web interface– 9

Network settings

DHCP:Enable/disable the mode of receiving network settings automatically.

IP:DeviceIP address.

Subnet mask:Subnet mask.

Default gateway:Default gateway address.

Primary DNS Server: The primary DNS server address.

Secondary DNS server:The address of the secondary DNS server.

Protocol:The network protocol used (IPv4 or IPv6).

Log display settings

Enable Print:Enable/disable logging mode.

Log level:Select the preferred logging level, where 0 is the minimum level, 7 is the most detailed

log.

Enable low-level logging:Enable/disable low-level logging to display it further.

Output to:Select the preferred output of log files (console, local file, syslog, and local file).

Syslog Server IP:The IP address of the log collection server.

Local file:The path to the location of the local file

Network applications

This menu displays TFTP and NTP server settings

TFTP server IP: Address of TFTP server.

By default, the SP-02 can have a DHCP mode enabled.

Option is enabled if DHCP is disabled.

Configuration throught web interface– 10

NTP enable: Enable/disable NTP server of timesynchronization

NTP server address: Address of NTP server.

Phone settings

Enable Dial Time Out: Enable/disable delay before dialing number.

Dial timeout: Set dial timeout.

Ring volume: Set ring volume.

Speaker volume: Set speaker volume.

Handset volume: Set handset volume.

Country zone: Select country zone.

Time Zone: Select time zone.
