Basilico K047 Manuel utilisateur
800 W Electric Steamer
K047 v01: 23/08/21
Please read and retain these instructions for future reference
CAUTION! THIS ELECTRICAL APPLIANCE’S EXTERNAL SURFACES
WILL GET HOT IN NORMAL USE.
ALLOW TO COOL BEFORE TOUCHING THE EXTERNAL SURFACES.
WARNINGS AND SAFETY INSTRUCTIONS:
WHEN USING ELECTRICAL APPLIANCES, BASIC SAFETY PRECAUTIONS SHOULD ALWAYS BE FOLLOWED:
•READ ALL INSTRUCTIONS BEFORE USE.
•FOR DOMESTIC INDOOR USE ONLY.
•DO NOT USE OUTDOORS OR FOR COMMERCIAL USE.
•BEFORE USE, CHECK THOROUGHLY FOR ANY DEFECTS AND DO NOT USE IF DEFECTS ARE FOUND.
TAKE CARE NOT TO DROP THE APPLIANCE AS HEAVY IMPACTS MAY CAUSE INTERNAL DAMAGE.
•BEFORE CONNECTING THE APPLIANCE, CHECK IF THE VOLTAGE INDICATED ON THE BOTTOM OF THE
APPLIANCE IS IN ACCORDANCE WITH THE MAINS VOLTAGE IN YOUR HOME.
•CHECK THE APPLIANCE AND POWER CABLE CAREFULLY FOR DAMAGE BEFORE EACH USE.
•THIS APPLIANCE CAN BE USED BY CHILDREN AGED FROM 8 YEARS AND ABOVE, AND PERSONS WITH
REDUCED PHYSICAL, SENSORY OR MENTAL CAPABILITIES OR LACK OF EXPERIENCE AND KNOWLEDGE
IF THEY HAVE BEEN GIVEN SUPERVISION OR INSTRUCTION CONCERNING USE OF THE APPLIANCE IN
A SAFE WAY AND UNDERSTAND THE HAZARDS INVOLVED. CHILDREN SHALL NOT PLAY WITH THE
APPLIANCE. CLEANING AND USER MAINTENANCE SHALL NOT BE MADE BY CHILDREN WITHOUT
SUPERVISION.
•CHILDREN OF LESS THAN 3 YEARS SHOULD BE KEPT AWAY UNLESS CONTINUOUSLY SUPERVISED.
•SOME PARTS OF THIS PRODUCT CAN BECOME VERY HOT AND CAUSE BURNS. PARTICULAR
ATTENTION HAS TO BE GIVEN WHERE CHILDREN AND VULNERABLE PEOPLE ARE PRESENT.
•THE USE OF ANY ACCESSORY OR ATTACHMENTS NOT RECOMMENDED BY COOPERS OF STORTFORD
MAY CAUSE INJURIES AND INVALIDATE ANY WARRANTY YOU MAY HAVE.
•DO NOT LET THE POWER CABLE HANG OVER THE EDGE OF A TABLE OR COUNTER, OR TOUCH HOT
SURFACES.
Dimensions
(H) 43 x (W) 23.5 x (D) 32cm
Length of mains lead: 100cm
•800W 3-TIER STEAMER WITH 60 MINUTE TIMER
•3L CAPACITY IN EACH TIER (9L TOTAL CAPACITY)
•HEALTHY COOKING –STEAMING KEEPS NUTRIENTS
PRESENT IN THE FOOD AND DOESN’T REQUIRE FAT
Technical details
220-240V AC., 50/60Hz, 800W
800W Food Steamer K047 Instructions for Use
Please read and retain these instructions for future reference v001: 23/08/21
•DO NOT PLACE ON OR NEAR HEAT SOURCES.
•USE ON A LEVEL, STABLE SURFACE.
•DO NOT COVER THE ITEM IN ANY WAY WHEN IN USE AS THIS MAY CAUSE OVERHEATING.
•DO NOT USE THIS APPLIANCE FOR ANY OTHER USE THAN THE INTENDED USE IT IS DESIGNED FOR.
•ENSURE THERE IS SUFFICIENT DISTANCE BETWEEN THIS APPLIANCE AND OTHER ITEMS ON THE
WORK SURFACE OR WORKSTATION, OR SUFFICIENT DISTANCE BETWEEN THE APPLIANCE AND THE
CONFINES OF THE AREA IN WHICH IT IS SITUATED. WE RECOMMEND A MINIMUM CLEARANCE
AROUND ALL FACES OF AT LEAST 10CM.
•ALLOW THE ITEM TO COOL THOROUGHLY BEFORE PUTTING ON OR TAKING OFF PARTS.
•TO PROTECT AGAINST ELECTRIC SHOCK, DO NOT IMMERSE POWER CABLE, PLUG OR APPLIANCE, IN
WATER OR ANY OTHER LIQUID.
•UNPLUG FROM OUTLET WHEN NOT IN USE AND BEFORE CLEANING.
•DO NOT OPERATE ANY APPLIANCE WITH A DAMAGED POWER CABLE OR PLUG OR AFTER THE
APPLIANCE MALFUNCTIONS OR HAS BEEN DAMAGED IN ANY MANNER. WE RECOMMEND THAT THE
POWER CABLE IS NOT KINKED OR STORED IN A TWISTED MANNER, AND THAT YOU REGULARLY
CHECK ITS CONDITION.
•ANY REPAIRS MUST BE CONDUCTED BY A QUALIFIED ELECTRICIAN OR ELECTRICAL SERVICE AGENT.
•DO NOT PLACE THE APPLIANCE NEAR THE HEAT SOURCE OR IN A HOT OVEN, AS SERIOUS DAMAGE
COULD RESULT.
•NEVER LEAVE THE APPLIANCE IN OPERATION UNATTENDED.
•BURNS CAN OCCUR BY TOUCHING THE HOT SURFACE OF THE APPLIANCE, THE HOT WATER, THE
STEAM OR THE FOOD.
•NEVER IMMERSE THE APPLIANCE IN WATER!
•DO NOT MOVE THE APPLIANCE WHEN IT IS FULL OF LIQUID OR HOT FOODS.
•DO NOT TOUCH THE APPLIANCE WHEN IT IS STEAMING AND USE OVEN GLOVES TO REMOVE THE
LID, RICE BOWL AND STEAMER BASKETS.
•ALWAYS UNPLUG THE APPLIANCE IMMEDIATELY AFTER USE, WHEN MOVING IT OR PRIOR TO ANY
CLEANING OR MAINTENANCE.
•DO NOT LEAVE UNATTENDED.
•ALWAYS SWITCH OFF AFTER COOKING OR IF YOU HAVE TO LEAVE THE ROOM.
•THE USE OF OVEN GLOVES IS RECOMMENDED WHEN HANDLING HOT FOOD OR HOT GRILL.
•ALLOW TO COOL BEFORE CARRYING OR PLACING IN STORAGE.
800W Food Steamer K047 Instructions for Use
Please read and retain these instructions for future reference v001: 23/08/21
Please follow the instruction for use carefully!
This appliance produces boiling hot steam!
Instruction for use
1. Using warm water and washing up liquid, wash all the removable parts and the inside of the water tank,
rinse and dry.
2. Place the base unit on a stable surface, put the turbo ring around the heating element (the largest side
on the bottom).
3. Pour fresh water directly into the water tank up to the maximum level.
4. Place the base into the baskets and put the food on the centre of the base.
5. Place the baskets on the top of the juice collector and put the lid on.
6. Plug in and set the time for recommended cooking times (see table of cooking times), the indicator light
on and steam cooking has begun.
Parts
1. Lid
2. Rice bowl (1L capacity)
3. Steamer basket No. 3
4. Steamer basket No. 2
5. Base with clip and build-in egg holder
6. Steamer basket No. 1
7. Juice collector
8. Removable turbo ring
9. Inside maximum water level indicator
10. Water tank (1 hour continuous use)
11. Heating element
12. Exterior water level indicator
13. 60-minute timer
14. “ON” indicator light
15. Power cord
800W Food Steamer K047 Instructions for Use
Please read and retain these instructions for future reference v001: 23/08/21
7. Check the water level on the exterior water level indicator, if necessary, add water from the side of the
juice collector during cooking.
8. When the set time has elapsed, the Steamer switches off automatically, the timer rings and the indicator
light turns off.
9. Food can be reheated. Check water level.
10. Remove the lid, place the basket(s) on the plate.
11. Unplug the appliance, let it cool completely before cleaning.
Cleaning and maintenance
1. Empty the water tank and clean it with a damp cloth.
2. All the other removable parts can be put in the dishwasher.
3. Descale the appliance regularly. It is recommended to descale on every 8th use.
4. Position the turbo ring upside down around the heating element(the largest side on the upper). Fill the
water tank with cold water up to “MAX” level, fill the inside of the turbo ring with white vinegar to the
same level. Do not heat up (to avoid the descaling odour). Leave to stand overnight to descale. Rinse out
the inside of water tank with warm water several times.
5. To store, stack the baskets into one another in the order No.1 into No.2,then together into No.3. Put the
rice bowl into the Steamer basket No.1.At last place the baskets on the juice collector and put lid over
them all.
PLUG WIRING (UK & IRELAND)
This appliance is fitted with a moulded BS 1363 13-amp plug. This is fitted with a 7amp fuse.
If you have to replace the fuse, only those that are ASTA or BSI approved to BS1362 should be used.
If there is a fuse cover fitted, this cover must be re-fitted after changing the fuse. If the fuse cover is lost or
damaged the plug must not be used. Spare fuse holders and fuses are available from electrical outlets. If the
socket outlets in your home or office are not suitable for this product’s plug, the plug must be removed and
disposed of safely. Attempts to insert the plug into the wrong socket is likely to cause electric hazard.
800W Food Steamer K047 Instructions for Use
Please read and retain these instructions for future reference v001: 23/08/21
DISPOSAL
•Coopers of Stortford use recyclable or recycled packaging where possible.
•Please dispose of all packaging, paper, cartons, packaging in accordance with your local
recycling regulations.
•Plastics, polybags –Contains the following recyclable plastic.
Code & Symbol
Type of Plastic
Polypropylene
Commonly used for
Microwaveable food containers, yoghurt pots, butter
tubs, disposable plates and cups
Notes
Commonly recycled and collected from household
recycling bins (packaging tape itself not recyclable but
does not interfere with cardboard)
•At the end of the product’s lifespan please check with your local council authorised household waste
recycling centre for disposal.
