Raturn®Controller
March 2009
INSTRUCTION MANUAL
Movement Responsive Caging System
Bioanalytical
Systems, Inc
2701 Kent Avenue
West Lafayette
Indiana 47906 www.BASInc.com
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
BASi products are trademarks of Bioanalytical Systems, Inc.
MANUFACTURER’S NOTE
This instrument, either wholly or in part, is manufactured for research purposes only. This instrument should be operated only by
trained laboratory personnel. Use for medical diagnosis is not intended, implied or recommended by the manufacturer. Use and
maintenance of this instrument and accountability for the same rests entirely with the user.
Bioanalytical Systems, Inc.
2701 Kent Avenue
West Lafayette, IN 47906
765.463.4527
www.BASInc.com
on the web
BASI
on the NASDAQ
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Safety Precautions The following general safety precautions must be observed during all phases of operation,
service, and repair of this instrument. Failure to comply with these precautions or with
specific WARNINGS,CAUTIONS,orNOTES elsewhere in this manual may impair
the protection provided by the equipment. Such noncompliance would also violate safety
standards of design, manufacture, and intended use of the instrument.
Bioanalytical Systems, Inc. assumes no liability for the customer’s failure to comply with
these requirements.
•For indoor use only.
•Ground the Instrument. To avoid electric shock, the instrument must be grounded with
the supplied power cable’s grounding prong.
•DO NOT exceed the operating input power, voltage, current level and signal type
appropriate for the instrument. Refer to the Installation Section for further information.
•Electrostatic discharge (ESD) can damage the highly sensitive microcircuits in your
instrument. ESD damage is most likely to occur as the I/O connectors are being
connected or disconnected. Protect them from ESD damage by wearing a grounding
strap that provides a high resistance path to ground. Alternatively, ground yourself to
discharge any static charge built-up by touching the outer shell of any grounded
instrument chassis before the I/O connectors are connected or disconnected.
•DO NOT place the instrument in fluid or expose the internal elements and/or back panel
to fluid.
•DO NOT Operate in an Explosive Atmosphere. Do not operate the instrument in the
presence of inflammable gasses or fumes. Operation of any electrical instrument in such
an environment clearly constitutes a safety hazard.
•Keep Away from Live Circuits. Operators must not remove instrument covers.
Component replacement and internal adjustments must be made by qualified
maintenance personnel. Do not replace components with the power cable connected.
Under certain conditions, dangerous voltage levels may exist even with the power cable
removed. To avoid injuries, always disconnect the power and discharge circuits before
touching them.
•DO NOT Service or Adjust Alone. Do not attempt internal service or adjustment unless
another person, capable of rendering first aid and resuscitation, is present.
•DO NOT Substitute Parts or Modify the Instrument. To avoid the danger of introducing
additional hazards, do not install substitute parts or perform unauthorized modifications
to the instrument. Return the instrument to the Bioanalytical Systems, Inc. Service
Department for service and repair to ensure that safety features are maintained in
operational condition.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
If you notice any unusual conditions as listed below, immediately terminate operation and
disconnect the power cable. Contact the Bioanalytical Systems, Inc. Service Department for
repair of the instrument. If you continue to operate without repairing the instrument, there is
a potential for hazard or damage to both the equipment and the operator.
•Instrument operates abnormally
•Instrument emits abnormal noise, smell, smoke or a spark-like light during operation
•Instrument generates high temperature or electrical shock during operation
•Power cable, plug or receptacle on instrument is damaged
•Foreign substance or liquid has penetrated the outer cover or cold-well of the
instrument.
•LCD displays an ERROR message
Throughout the course of this manual, the following will be used to designate important
information:
WARNING - This signifies an extreme hazard. Not following the instructions may result
in serious injury or death.
CAUTION - Following information relates to a hazard. If instructions are not followed
properly, it can result in irrevocable damage to the instrument.
NOTE - This implies that the following instructions are essential for the user to
understand in order to operate the equipment effectively.
Symbols:
Caution: Risk of Danger. User’s Manual must be consulted in all cases where this
symbol is marked.
Alternating current.
Fuse.
On (Supply).
Off (Supply).
Complies with European Union Directives
The European Waste Electrical and Electronic Equipment (WEEE) Directive
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
i
Table of Contents
Section 1. Introduction ...............................1
Product Description: ·····························1
Features: ···································1
Components: ································1
Section 2. Installation ...............................2
Identification of Parts ·····························2
Environment ·································3
Installation Procedures ·····························5
Section 3. Using the Raturn .............................8
Collaring an Awake Animal ···························8
Hooking an Animal to the Raturn ························9
Running the Raturn ······························9
Section 4. Maintenance ..............................10
Cleaning and Care ······························10
Replacement Parts ······························10
Accessory Part Numbers ···························10
Section 5. Troubleshooting Guide .........................11
Section 6. Contact BASi ..............................12
Contact Information ·····························12
Shipping Damage ······························12
Limited Warranty ·······························12
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Section 1. Introduction
The BASi Raturn uses a patented technology to maintain the integrity and patency of
multiple sampling lines in an awake, freely moving animal.
Product Description: The Raturn System consists of a turntable and drive mechanism connected to a control box.
The animal is tethered to a balance arm with a flag marker. As the animal moves left or
right, the flag enters a sensor, which causes the cage to rotate in the opposite direction of
the movement, keeping lines from tangling.
Features: •Patented, swivel-free technology for freely moving animals
•Fast and easy installation
•Tethers and caging available for multiple species
•Easy clean up between experiments
Components: •The Raturn system is shipped in a single box.
•Raturn Controller
•Base plate
•Raturn Platter
•Raturn Motor
•Upright arm with socket screws
•Balance arm and tether
•Power Cord
•Spare O-rings
•Replacement animal collars
•Instruction Manual
Section 1. Introduction
1
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Section 2. Installation
Identification of Parts Raturn System
A: Balance arm and tether
B: Upright arm with screws
C: Raturn motor
D: Raturn platter
E: Base plate
F: Raturn controller
Raturn Controller
Front
A: Red indicator lights for Raturn disable
B: Red and green indicator lights for Raturn on or off
C: Control switch for Raturn turntable activation
Section 2. Installation
2
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Back
A: Optical sensor plug port, for balance arm cable
B: Turntable plug port, for the Raturn motor
C: Raturn monitor port for animal activity cable (use only with Culex or Empis)
D: Outputs for animal activity monitoring
E: Plug port for power cable
F: Power switch
Environment General
•For indoor use only
•Place on a stable, level surface.
•Do not place the instruments in direct sunlight
Environmental Requirements
The Raturn is designed to operate under the following environmental conditions:
•Temperature: 10°C to 35°C
•Humidity: 15% to 50% (relative humidity)
•Pressure: 75 KPA – 106 KPA
•Altitude: < 2,000 meters
•Pollution Degree 2
CAUTION The Raturn must be protected from temperature extremes that could cause
condensation within the instrument.
Section 2. Installation
3
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Power Source Requirements
The Raturn requires a power source that meets the following specifications:
•Voltage: 100-240 VAC (auto select)
•Frequency: 50-60 Hz
•Power Consumption: VA (max)
•Connections: The power cable uses a three-wire system in accordance with international
safety standards. When connected to an appropriate ac power outlet, this cable grounds
the instrument frame.
WARNING To protect against electrical shock, the power cable grounding prong MUST
NOT BE removed.
WARNING Failure to comply with these requirements may result in injury to both the
user and the equipment.
Section 2. Installation
4
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
