BAS WiFiAgent Manuel d'instructions

Step 5

Step 4

Start

Step 3

Step 1

Step 2

Indoor USB Wi-Fi antenna

WiFiAgent

QUICK USER GUIDE

Thank you for choosing our Indoor USB WiFi antenna WiFiAgent! It has been

developed by a team of engineers determined to continue the tradition of

excellence and innovation of REMO-Electronics products.

The Indoor USB Wi-Fi antenna WiFiAgent is made of high-quality materials

in accordance with thoroughly detailed design. The quality management system

is certied by ISO 9001:2011.

The antenna can be installed either on a table, or a shelf, or nearby a

window, or any other horizontal surface. You won’t even need any tools!

The WiFiAgent will improve the signal strength, as well as steadiness and

accuracy of data transmission on 2400MHz wireless network. Built-in Wi-Fi

adapter can provide the connection speed up to 150Mbps. Practical range of

connection is up to 1000 meters. Built-in Wi-Fi antenna adapter of WiFiAgent is

compatible with Microsoft Windows XP/7/8/10 10 or another OS based on Linux.

Create your own Wi-Fi network (Access Point Mode)

5 6

Run the utility by double-clicking Wait for switching the operation mode

Select mode: The Access Point

REALTEK USB

Wireless LAN

Utility

Before switching to Access Point mode

- disable the Windows rewall

Select the network with Internet access...

... and then click “Cong”

Make sure you have the Internet

Сonnection Sharing

Appendix 2. Utilities for searching and analyzing Wi-Fi networks

WirelessNetView (www.nirsoft.net/utils/wireless_network_view.html) NetSpot (www.netspotapp.com/netspot-windows.html)

Free Wi-Fi Scanner (lizardsystems.com/wi--scanner/) Wi-Fi Analyzer (The Store in Windows 10)

Conrm the wireless network settings

left-click

Select Network Name (SSID)

Select Network Authentication

and Data Encryption

Enter Passphrase...

... or Network key

Select Channel

Step 7

Step 6

Step 8

Step 9

Insert

Install

Reboot

Run App

Finish

This product comes with one year warranty against any defects in labor

or materials. REMO-Electronics warrants this product is free from defects

in material and workmanship for a period of one year from date of

purchase. Our obligation under this warranty is limited to repair or

replacement of any parts or workmanship that prove to be defective

upon inspection. This warranty does not apply to normal wear and tear

as well as to damages resulting from shipment, alteration or misuse of

the product.

Manufacturer:

REMO-Technologii, LLC., P.O.Box 500, Saratov, 410052, Russia

www.remo-electronics.com; info@remo-electronics.com

In order to gain maximum signal, we recommend to use special utilites,

which are able to scan Wi-Fi network and display detailed information

for each wireless network that are within range of WiFiAgent.

For example, you can choose the following utilities (for installation on

portable or stationary PC):

for Windows:

WirelessNetView (www.nirsoft.net/utils/wireless_network_view.html)

NetSpot (www.netspotapp.com/netspot-windows.html)

Free Wi-Fi Scanner (lizardsystems.com/wi--scanner/)

for Linux:

LinSSID (sourceforge.net/projects/linssid/)

iwScanner (kuthulu.com/iwscanner/index.php)

for OS X:

NetSpot (www.netspotapp.com)

Attention! These utilities can be presented as a demonstration and have

the status of Shareware Trial Version with a limited trial period of use.

Shareware programs may restrict commercial use, and periodically

remind the user about payment.

AB:CD:EF:LM

Find max signal

Appendix 1. Using the utility Realtek

Installation utility and driver

Connection to existing networks

Run the utility by double-clicking Click on the “Available network” Select the network to which you want to connect

Conrm the network and its parameters. Click on the “General”

Use information about the signal level

for setting the direction of the “WiFiAgent”

Active mode: the Station

If necessary, enter the password...

... or Network key

REALTEK USB

Wireless LAN

Utility
