Bartec Agile X IS Manuel utilisateur

1/7

Subject to technical changes.

09/2020

Subject to technical changes.

12/2021

Installation manual

Agile X IS

10,1" Tablet-PC

Create a bootable USB stick with

Windows 10 IoT Enterprise operating

system (Bartec Version)

Introduction

formatting the USB stick

copy the operating system on the USB stick

install the operating system

Status: December 2021

Reservation: Technical data subject to change without notice. Changes, errors and

misprints may not be used as a basis for any claim for damages.

Table of content

Agile X IS

Installation manual: bootable USB stick for Windows 10 LTSC 1809

Subject to technical changes.

12/2021

II/7

1. Introduction........................................................................................................................................... 3

2. Note for installation .............................................................................................................................. 3

3. Requirements........................................................................................................................................ 4

4. Format USB flash drive ........................................................................................................................ 4

5. Copy the operating system on the USB stick .................................................................................... 6

Installation manual

Agile X IS

Installation manual: bootable USB stick for Windows 10 LTSC 1809

3/7

Subject to technical changes.

09/2020

Subject to technical changes.

12/2021

1. Introduction

This guide will describe how to create a bootable USB Flash Drive to update the Operating System of your

BARTEC tablets.

2. Note for installation

(1) Only install Operating Systems which are provided from BARTEC. Installing an Operating

System that is not designed for a BARTEC device may not work correctly with them.

(2) Using the Format and Rufus utility will delete all data currently on the USB flash drive.

(3) Make sure that PC, Notebook or Tablet (referred to in the following as the “computer”) is running

on AC Power during the preparation process. Do not unplug the AC Adapter, or any other

connected external devices during the process. Do not restart or turn off the computer during the

process as it may cause permanent damage to the file system structure of the USB Flash Drive.

Agile X IS

Installation manual: bootable USB stick for Windows 10 LTSC 1809

Installation manual

Subject to technical changes.

12/2021

4/7

3. Requirements

Computer with a Windows 7/8/10 operating system

USB flash drive (16GB or more) or Bartec Ex-i USB flash drive (P/N: 17-A1Z0-0007)

Rufus utility

4. Format USB flash drive

1. Insert the USB stick to your Computer.

2. Start Windows Explorer and select the USB Flash Drive.

3. Open the drop-down menu with right mouse click on the USB stick.

4. Select “Format…”

5. In the window “Format” select for “File system” NTFS and for “Volume label” RDVD.

6. Activate the check box for “Quick Format”

Installation manual

Agile X IS

Installation manual: bootable USB stick for Windows 10 LTSC 1809

5/7

Subject to technical changes.

09/2020

Subject to technical changes.

12/2021

6. Press “Start” button to begin the process

7. Press “OK” button in the next message to continue the process.

8. When the formatting process is complete, the message "Formatting was successful" (Format

Complete) appears.

9. Press the “OK” button to close this message. The Format partition window closes automatically

Agile X IS

Installation manual: bootable USB stick for Windows 10 LTSC 1809

Installation manual

Subject to technical changes.

12/2021

6/7

5. Copy the operating system on the USB stick

1. Run the Rufus application

2. Make the following settings in the "Drive Properties":

Device: RDVD (D :) [16GB]

Boot selection: XISLTSC19R01 –AgileXIS LTSC OEM.iso

Partition scheme: MBR

Target system: BIOS (or UEFI-CSM)

3. Make the following settings in the "Formatting Options":

Volume label: DVD_ROM

File system: NTFS

Cluster size: 4096 Byte (Standard)

Installation manual

Agile X IS

Installation manual: bootable USB stick for Windows 10 LTSC 1809

7/7

Subject to technical changes.

09/2020

Subject to technical changes.

12/2021

4. In “Status” appears “DONE”. Click on “START” to copy the operating system to the USB stick.

5. The transfer takes about 10-15 minutes.

After a successful transfer, the “Status” switch to green.

6. Close the Rufus application.

The USB stick is now setup for the installation.
