Barnacle Systems BRNKL Guide d'installation
Basic Installaon Guide
BRNKL ALL-IN-ONE
BRNKL EXTERNAL CAMERA
BIG2112019
Before you start | 1
WARNING: Disconnect all AC power sources before accessing
electrical panels, switches or devices.
If you’re comfortable handling everyday electrical repair and
maintenance tasks on your boat, follow the instrucons in
this guide.
If your boat electrical system is complex, or you're
unfamiliar with basic electrical systems, hire a professional
installer or a marine electrician.
Before you start
Take a moment to consider
if this guide is for you.
Table of contents | 2
Table of contents
Before you start 1
Introducon 3
Installaon opons 4
Meet BRNKL 5
Basic connecons 8
What you need 10
Basic installaon steps 12
Step 1 | Acvang BRNKL 13
Step 2 | Posioning and assembling BRNKL 16
Step 3 | Connecng a house baery 20
Step 4 | Mounng and securing BRNKL 28
Step 5 | Connecng a starter baery 37
Step 6 | Connecng an addional baery 45
Step 7 | Connecng a bilge pump 53
Step 8 | Seng and calibrang BRNKL 63
Wiring reference 68
Legal and regulatory 72
Introducon | 3
Introducon
Ahoy! This guide explains how to
complete the BRNKL basic installaon.
The BRNKL basic installaon connects two baeries and a
bilge pump to BRNKL. This allows BRNKL to monitor and
send alerts for:
Boat locaon
GPS locaon.
Boat condion
Pitch, heel angle, and impact.
Cabin status
Moon,* temperature, humidity, and barometric
pressure. Camera image capture.
Bilge status
Bilge pump acvity.
Baery status
Baery voltage levels for house and starter
baeries. Oponally, you can connect up to two
addional baeries.
Go to brnkl.io for support, troubleshoong and more
informaon.
*BRNKL All-in-One model
Installaon opons | 4
Installaon opons
Add features to the BRNKL basic
installaon with add-on accessories.
Boat locaon
GPS locaon monitoring
and tracking.
Boat condion
Pitch, heel angle, and
impact monitoring.
Cabin status
Camera image capture.
Moon,* temperature,
humidity, and barometric
pressure monitoring.
Bilge status
Bilge pump acvity
monitoring.
Baeries (up to 4)
Baery voltage level
monitoring.
*BRNKL All-in-One model
Cabin entry
Door and window
monitoring.
Shore power connecon
Shore power connecon
monitoring.
Boat deck security
Floor mat sensor
monitoring.
Siren output
Siren alarm control.
Device control
AC and DC digital device
control (lights, etc.)
Device monitoring
Digital device monitoring
(engine status, etc.)
Basic installaon Add-on features
Accessories sold separately
This guide
Meet BRNKL | 5
Meet BRNKL
1 2 3 4 5 6 7 8 9 10 11 12 13 14
❶❷❸❹ ❺
❻
temperature, humidity,
and barometric
pressure sensors
❶
❷
❸
reset buon
wireless pairing buon
unassigned
GPS antenna port
connector
LED indicator light
❹
❺
❻
Boom view
Meet BRNKL | 6
All-in-One models
moon sensor
❽
❽
camera
❾
❾
Meet BRNKL | 7
External Camera models
❿
external camera port
❾
❿
Basic connecons | 8
BRNKL
Connects to the mobile data network. Includes
camera, moon sensor,* temperature sensor,
humidity sensor, barometric pressure sensor,
impact monitor, and pitch and heel monitor.
Basic connecons
Connect four devices to complete a
BRNKL basic installaon.
A BRNKL basic installaon connects these four devices:
Basic connecons | 9
House baery connecon
Powers BRNKL and monitors the house baery.
Starter baery connecon
Powers BRNKL and monitors the starter baery.
Bilge pump connecon
Monitors bilge pump acvity.
Addional baery connecon
Powers BRNKL and monitors an addional
baery. BRNKL can connect to two addional
baeries.
*BRNKL All-in-One model
