OPERATOR’S MANUAL
®
1 Banks Avenue • Superior • WI • 54880
Phone: 800-544-6532 • 715-395-6700
Fax: 800-772-2448 • 715-392-9348
Web: www.barko.com Email: [email protected]
MANUAL P/N
ISSUE NO.
ISSUE DATE
Serial Number Range:
Machine Serial Number:
NOTE:
This Operator’s Manual includes precautions and procedures for safely operating your BARKO machine. This manual includes
limited service, repair and parts information. Separate BARKO Parts and Service Manuals are available from your BARKO
dealer or from BARKO directly.
Engine, attachment and other component information may be limited in this manual. See separate manufacturer manual(s)
which accompanies this BARKO machine from the factory.
The information and illustrations in this manual have been approved as accurate at the time of printing. However, this manual
may contain information on options not present on your loader. BARKO Hydraulics, LLC reserves the right to make changes
and improvements in its product at any time without notice or obligation.
800-00499
1
09/09/2019
STATIONARY ELECTRIC LOADERS
295B - 495B - 595B (SE)
®
SUPERIOR • WI • USA • www.barko.com
MANUAL Table of Contents
CH-10 GENERAL INFORMATION 10-1
USE GENUINE BARKO PARTS 10-3
HYDRAULIC PRESSURE WARNING 10-4
INTRODUCTION 10-5
OTHER RESOURCES 10-6
UNAUTHORIZED PRODUCT CHANGES 10-6
KNOW YOUR BARKO 10-7
SAFETY SUMMARY 10-8
OPERATION ON SLOPED TERRAIN 10-12
WELDING SAFETY 10-13
FIRE PREVENTION 10-14
BARKO DEALER NET 10-16
PARTS TAB 10-16
MANUALS TAB 10-16
SERVICE TAB 10-17
ABBREVIATIONS 10-18
CH-13 MACHINE OVERVIEW 13-1
MODEL DESCRIPTION- 295B SE 13-2
MODEL DESCRIPTION- 495B SE 13-3
MODEL DESCRIPTION- 595B SE 13-4
MACHINE SERVICE 13-6
SAFETY WHILE SERVICING 13-6
INSPECTION & SERVICE SCHEDULE 13-7
LUBRICATION & FLUID SPECIFICATIONS 13-11
GENERAL TORQUE SPECIFICATIONS 13-15
NEW MACHINE BREAK-IN 13-19
OPERATION 13-20
PRE-START UP 13-20
START UP 13-21
SHUT DOWN 13-23
OPERATING & LOADING TECHNIQUES 13-24
MACHINE STORAGE 13-28
CH-18 DECALS 18-1
IMPROPER ELEC. CONNECTION DECAL 539-00883 18-2
ROTATING COOLER FAN DECAL 539-00885 18-2
HOT EXHAUST PIPE DECAL 539-00892 18-3
STAY CLEAR DECAL 539-00896 18-3
SERVO, SERVO ON/OFF 225 DECAL 539-01000 18-3
STAY CLEAR DECAL 539-00886 18-3
UNIVERSAL BOLT TORQUE DECAL 539-00881 18-4
GREASE DAILY DECAL 539-01002 18-4
GREASE TURNTABLE DECAL 539-00074 18-4
NOTE:
The beginning of each chapter has its own detailed table of contents.
®
SUPERIOR • WI • USA • www.barko.com
TORQUE CONFIRMATION DECAL 539-00923 18-4
MADE IN USA DECAL 539-00895 18-4
80-90 GEAR LUBE DECAL 539-00899 18-4
GREASE BOOM & CYL POINTS DECAL 539-00082 18-4
10 MICRON DECAL 539-00889 18-5
PRESSURES DECAL- (495B & 595B) 539-00941 18-5
PRESSURES DECAL- (295B) 539-01020 18-5
FALLING & SLIPPING HAZARD DECAL 539-00891 18-5
STAY CLEAR DECAL 539-00896 18-5
SERVO DECAL 539-00888 18-6
80-90 GEAR LUBE DECAL 539-00899 18-6
GREASE BOOM & CYL POINTS DECAL 539-00882 18-6
GREASE DAILY DECAL 539-01002 18-6
GREASE T. BRG & PINION DECAL 539-00074 18-7
HYD OIL LEVEL DECAL 539-00977 18-7
BATTERY DISCONNECT SWITCH DECAL 539-00880 18-7
DIESEL FUEL CAUTION DECAL 539-00887 18-7
COMBUS/FLAMMABLE FLUIDS DECAL 539-00886 18-7
HOT & PRESS FLUID DECAL 539-00894 18-8
HYD OIL ONLY DECAL 539-00884 18-8
HYD OIL STANDARDS DECAL 539-00890 18-8
ROTATING COOLER FAN DECAL 539-00885 18-8
MACHINE DAMAGE-INSPECT DAILY DECAL 539-00903 18-8
CH-26 HVAC 26-1
GENERAL HVAC SYSTEM 26-3
AIR CONDITIONING (A/C) SYSTEM 26-3
HVAC SERVICE SCHEDULE 26-4
HVAC SERVICING 26-5
HEATER-A/C UNDER-SEAT UNIT 26-5
CH-40 CAB 40-1
OPERATOR’S STATION LAYOUT 40-2
JOYSTICK CONTROL FUNCTIONS 40-3
SEAT LAYOUT 40-7
INSTRUMENT PANEL 40-10
MD3 MAIN SCREEN 40-11
MD3 SERVICE SCREEN 40-13
MD3 DIAGNOSTIC SCREEN 40-14
TRANSPORTING 40-20
CH-43 PLATFORM 43-1
TURNTABLE BEARING 43-2
SWING DRIVE 43-6
SWING GEARBOX 43-7
GEARBOX TROUBLESHOOTING 43-10
THIS PAGE INTENTIONALLY BLANK
®
SUPERIOR • WI • USA • www.barko.com
CHAPTER
1 BANKS AVE • SUPERIOR • WI • USA • www.barko.com
®
OPERATOR
GENERAL INFORMATION
10
Table of Contents- CHAPTER 10
USE GENUINE BARKO PARTS 10-3
HYDRAULIC PRESSURE WARNING 10-4
INTRODUCTION 10-5
OTHER RESOURCES 10-6
UNAUTHORIZED PRODUCT CHANGES 10-6
KNOW YOUR BARKO 10-7
SAFETY SUMMARY 10-8
OPERATION ON SLOPED TERRAIN 10-12
WELDING SAFETY 10-13
FIRE PREVENTION 10-14
BARKO DEALER NET 10-16
PARTS TAB 10-16
MANUALS TAB 10-16
SERVICE TAB 10-17
ABBREVIATIONS 10-18
800-10007
THIS PAGE LEFT INTENTIONALLY BLANK
10-3
Remember, use only...
* GENUINE BARKO PARTS *
NOTE
This Operator’s Manual has limited parts information. A BARKO
Parts Manual will have detailed parts lists and illustrations that may
assist in performing routine maintenance.
A BARKO Service Manual will have detailed service and
maintenance procedures which will assist servicing your BARKO
machine or attachment.
This Operator’s Manual must be with the machine at all times.
Purchase BARKO Parts and/or Service Manuals
from your authorized BARKO dealer.
BARKO HYDRAULICS, LLC
1 Banks Avenue
Superior, WI 54880
715-395-6700
www.barko.com
OPERATOR’S
®
10-4
WARNING
!
Raising hydraulic pressure on this
machine above the factory approved
settings may cause death, severe
injury or property damage and will
void the warranty.
The consequences of increasing hydraulic
pressure are serious. The function of the relief
valves is to provide a fuse action to protect the
machine and the operator from overloading. When
overloaded, the machine can become stressed to a
level where parts fracture causing death, severe injury
or property damage. This is an extremely
dangerous practice.
Accordingly, you are advised that the pressure
settings of this machine are limited to the factory
approved settings. Pressures in excess of these
settings render each and all Barko warranties null and
void and constitute an obvious misuse and abuse of
our product.
BARKO HYDRAULICS, LLC
OPERATOR’S
®
10-5
®
INTRODUCTION
EMAIL: [email protected]
1. Right Hand (RH) or Left Hand (LH)
Know the following information before ordering parts or servicing your BARKO machine:
Model and Serial Numbers are found on the Data Plate of your machine and/or
All parts for your BARKO machine or attachment may be ordered from your nearest BARKO
Dealer. If you are not certain of the dealer's location check our website or contact BARKO Customer
Service for assistance:
PHONE: 715-395-6700
Understand the correct servicing procedures before servicing your BARKO machine or
attachment. It is important to know the correct operating and servicing procedures of the machine and
all safety precautions to prevent the possibility of property damage and/or personal injury or death.
REFER TO A BARKO SERVICE MANUAL for detailed service schedules and procedures.
Your BARKO machine has been designed and manufactured with the highest quality of
materials and care in workmanship. This Operator’s Manual is intended to assist you in safe
operation and maintaining your BARKO to keep it in peak condition. A BARKO Operator’s Manual must
be with the machine at all times. Separate Parts and Service Manuals can be obtained from your
BARKO Dealer.
WEB: www.barko.com/dealer-locator
Right or left hand is determined when positioned in the machine from the normal
operator's seat position behind the boom or lifting arms.
Cylinders- The port location off center viewed from butt of cylinder.
Pump and Motor Rotation- Determined by viewing from the shaft end.
2. Model and Serial Numbers ---- IMPORTANT!
attachment. Machines and Attachments each have their own unique S/N's. Locations of the
data plate on popular BARKO models are:
240/260/270 On head right side of main lift cylinder
612/830/930/937 LH rear of front frame
70/80/110 LH, RH or rear of the head plate
295/495/595 RH on lower frame below platform
Grapples- Front or side head plate
Cylinders- ID numbers stamped on gland.
It is your responsibility to know and understand the factory warranty for your BARKO
machine or attachment. BARKO warranties are included with the Operators manual and
may be machine/serial number specific.
4. Safe Working Practices & Procedures
It is your responsibility to know and understand ALL safety warnings and follow safe
3. Warranty
service procedures in this manual before servicing your BARKO machine or attachment.
PAR T NO 53 9-00667
07/12/2018
Updated
OPERATOR’S
10-6
®
INTRODUCTION (continued...)
ŸSociety of Automotive Engineers (SAE) www.sae.org
ŸNational Timber Harvesting and Transportation Safety (THATS) Foundation
www.loggingsafety.com
ŸAmerican National Standards Institute (ANSI) www.ansi.org
ŸAssociation of Equipment Manufacturers (AEM) www.aem.org/groups/product-specific/forestry-
equipment-council-foec/
ŸForest Resource Association (FRA) www.forestresources.org
As a professional trained operator you are responsible for safety, both your own and that of
bystanders. Your knowledge and use of all safety practices and correct servicing procedures in this
manual, and your good judgement, can be a major factor in preventing some of the thousands of
injuries and deaths caused by industrial accidents each year.
DON'T FORGET - SAFETY FIRST!
A professional operator should also be familiar with the information contained in other applicable
sources such as:
ŸOccupational Safety and Health Administration (OSHA) www.osha.gov/SLTC/logging/
As owner / operator of this machine, BARKO advises you that NO CHANGES ARE TO BE MADE TO
ITS PRODUCTS INCLUDING DELETIONS OR ADDITIONS OTHER THAN A BARKO APPROVED
OPTION. Any unauthorized alterations to this BARKO machine may nullify and void your BARKO
factory warranty as well as component manufacturer warranties. KNOW YOUR WARRANTY!
Contact BARKO or your BARKO dealer for information on maximum permissible operating weights and
the effects of additional options may have on your machine. Weight and stability are important factors
when considering the addition of options or attachments. BARKO will not be held responsible for
any situation that may arise resulting from any unauthorized field changes to its products.
The installation of any unauthorized attachment or changes made of any kind to this BARKO product
could affect the products ability to perform as originally intended. The products integrity, stability and it's
ability to perform safely could be at serious risk!
UNAUTHORIZED PRODUCT CHANGES:
07/12/2018
Updated
OPERATOR’S
