Barfield 2311FA Manuel de l'opérateur

2311FA

Pressure Tester

USER INSTRUCTION MANUAL

M/N: 2311FA, P/N: 101-00212

Doc. P/N: 56-101-00212

Revision E

August 8, 2023

____________________________________

56-101-00212 Revision E Page | i

Corporate Headquarters

4101 Northwest 29thStreet

Miami, Florida 33142

www.barfieldinc.com

Email: [email protected]

Barfield Inc. Confidential and Proprietary Information.

This document and all the information contained herein is the sole property of Barfield Inc.

No intellectual property rights are granted by the delivery of this document or the disclosure of its content.

This entire document is proprietary information and shall not be reproduced or disclosed to a third party

without the express written consent of Barfield Inc.

This document and its content shall not be used for any purpose other than that for which it is supplied.

56-101-00212 Revision E Page | ii

SAFETY

Before using this instrument, the operator should read and understand all of the related data.

This includes the applicable local safety procedures, this publication, and the instructions for the

accessories/options/equipment you are using it with and the system or components under test.

This equipment was designed to be safe when used as per the procedures of this Instruction

Manual.

Before you start an operation or procedure in this publication, make sure that you have the

necessary skills (if necessary, with qualifications from an approved training establishment).

Always follow good engineering practices.

WARNING: A WARNING notice indicates a hazard with a potential for property damage,

personal injury, or death if the instructions are not followed. The operator should

not proceed beyond the WARNING notice until required conditions are understood

and fully complied with.

CAUTION: A CAUTION notice indicates a hazard with a potential for damage to the equipment

and or loss of data if the instructions are not followed. The operator should not

proceed beyond the CAUTION notice until required conditions are understood and

fully complied with.

GENERAL WARNINGS

WARNING: Do not use this equipment when it is not in its normal condition.

WARNING: When testing with this equipment follow the appropriate procedures as per the

WARNING label.

WARNING: Do not use this equipment for purposes other than as specified in this manual.

WARNING: Do not use this equipment in an atmosphere with explosive gas, vapor, or dust.

WARNING: Utilize appropriate skin and eye protection when adding or draining fluids.

WARNING: It is not recommended that the same pressure gauge be used for different fluids as

cross-contamination and even explosive failure may occur (Ref. ASME B40.100-

2005).

WARNING: Do not use this equipment without an open vent plug or equivalent installed on the

reservoir.

PRESSURE WARNINGS

WARNING: Ensure that the equipment is safe to use with all accessories. Many liquid and gas

mixtures are dangerous. This includes mixtures that occur due to contamination.

WARNING: Before attaching or disconnecting pressure equipment, safely release all pressure.

Pressurized gases and fluids are dangerous.

WARNING: Prevent a dangerous release of pressure by making sure all the related pipes,

hoses and equipment have the correct pressure rating, are safe to use and are

correctly attached.

56-101-00212 Revision E Page | iii

CAUTIONS

CAUTION: To prevent damage to the instrument, do not let dirt get into the pressure

mechanism. Before you attach equipment, make sure it is clean.

CAUTION: Do not allow Master Gauge to go below zero.

CAUTION: Do not apply vacuum or a hydraulic vacuum to Master Gauge.

CAUTION: Do not insert objects into the Master Gauge.

CAUTION: A Vented Plug must be installed on the reservoir before Tester use.

CAUTION: Make sure that the maximum working pressure of the Tester (600 psig), or the

maximum working pressure of the Master Gauge being used, whichever is lowest, is

not exceeded during the test.

CAUTION: Place a rag over the Vented Plug while removing it, to avoid possible exhaust spray.

CAUTION: Use Teflon tape if necessary to help prevent leaks.

CAUTION: Teflon tape is an excellent thread sealer; however, if not properly applied, pieces

may enter the hydraulic system and cause malfunctions or damage.

CAUTION: When changing from one type of fluid to another, complete disassembly and

cleaning is necessary to prevent contamination of the system being checked,

following the procedure of section 3.3 CHANGING TESTER FLUID.

CAUTION: Do not use alcohol to clean the O-rings.

MARKING AND SYMBOLS

Warning –Read and

understand operator’s manual

before using this machine.

56-101-00212 Revision E Page | iv

CONTACT INFORMATION

Users are requested to notify the manufacturer of any discrepancy, omission, or error found in

this manual. Inquiries should include specific questions and reference the publication title,

number, chapter, page, figure, paragraph, and effective date.

Please send comments to:

TECHNICAL CUSTOMER SUPPORT - GSTE

BARFIELD, INC.

P.O. BOX 025367

MIAMI, FL 33102-5367

USA

Telephone (305) 894-5400

(800) 321-1039

Fax (305) 894-5401

Email gsesales@barfieldinc.com

MAINTENANCE AND REPAIR INFORMATION

The manufacturer of this equipment does not recommend the user to attempt any maintenance

or repair. In case of malfunction, contact the manufacturer to obtain the list of approved repair

facilities worldwide, ensuring that this equipment will be serviced using proper procedures and

certified instruments.

BARFIELD PRODUCT SUPPORT DIVISION

Telephone (305) 894-5400

(800) 321-1039

Fax (305) 894-5401

Email gsesales@barfieldinc.com

Shipping Address:

Barfield, Inc.

4101 NW 29th Street

Miami, Florida 33142

USA

Mailing Address:

Barfield, Inc.

P.O. Box 025367

Miami, FL 33102-5367

USA

56-101-00212 Revision E Page | v

REVISION RECORD

REV.

ECO #

REV. DATE

DESCRIPTION OF CHANGE

N/A

April 1, 1999

Initial release.

260-00717

January 25, 2008

Chapters 2 and 3 were reorganized.

Updated Figure 1, 4 and 5, Table of

Gauges, and Maintenance Information.

Updated Manual Format.

260-00829

April 12, 2011

Updated warranty information.

260-01009

September 16, 2014

Reformatted for CE and updated logo.

260-01426

August 8, 2023

Complete revision.


 56-101-00212 Revision E Page | vi
TABLE OF CONTENTS
Safety / General Warnings / Pressure Warnings
Cautions / Marking & Symbols
Contact Information / Maintenance Information
Revision Record
Table of Contents
List of Figures / List of Tables
 PAGE
INTRODUCTION.............................................................................................................1
1. PUBLICATION BREAKDOWN........................................................................................1
2. INFORMATION PROVIDED WITH THE TEST SET .......................................................1
3. RECERTIFICATION .......................................................................................................2
CHAPTER 1: GENERAL................................................................................................4
1. INTENDED USE.............................................................................................................4
2. DESCRIPTION...............................................................................................................4
3. SPECIFICATIONS..........................................................................................................5
4. RECOMMENDED GAUGES...........................................................................................6
5. RECOMMENDED FLUIDS .............................................................................................6
6. CONSUMMABLES .........................................................................................................7
CHAPTER 2: INSTALLATION .......................................................................................8
1. ASSEMBLY ....................................................................................................................8
CHAPTER 3: OPERATION ............................................................................................9
1. OPERATING CONTROLS..............................................................................................9
2. FILLING TESTER WITH FLUID....................................................................................10
3. CHANGING TESTER FLUID........................................................................................11
4. OPERATION PROCEDURES.......................................................................................12
CHAPTER 4: RECEIVING, SHIPPING, AND STORAGE.............................................14
1. RECEIVING..................................................................................................................14
2. SHIPPING ....................................................................................................................14
3. SHORT-TERM STORAGE............................................................................................14
4. EXTENDED STORAGE................................................................................................14
CHAPTER 5: MAINTENANCE & REPAIR ...................................................................15
1. GENERAL ....................................................................................................................15
2. REPAIR........................................................................................................................15





 56-101-00212 Revision E Page | vii
LIST OF FIGURES
 PAGE
Figure 1 Identification Label ..................................................................................................... 1
Figure 2 Owner Warranty Registration Card............................................................................. 2
Figure 3 Limited Warranty........................................................................................................ 3
Figure 4 2311FA Pressure Tester with a Digital Gauge (Not Included)..................................... 4
Figure 5 Container/Shipping Case, P/N 194-00079.................................................................. 8
Figure 6 2311FA Pressure Tester Parts................................................................................... 9
Figure 7 2311FA Piston, Shaft, & Handle Assembly................................................................16

 LIST OF TABLES
 PAGE
Table 1 Physical Characteristics............................................................................................... 5
Table 2 Environmental.............................................................................................................. 5
Table 3 Conformity................................................................................................................... 5
Table 4 Specifications of Recommended Gauges .................................................................... 6



56-101-00212 Revision E Page | 1

INTRODUCTION

1. PUBLICATION BREAKDOWN

This user instruction manual establishes the standards of operation for the 2311FA Pressure

Tester.

Its purpose is to provide sufficient information for the personnel unfamiliar with this tester to

understand it, identify its parts, and operate it in accordance with proper procedures,

operating techniques, precautions, and limitations.

Note: The manufacturer has designed this equipment to be safe when operated using the

procedures and instructions detailed in this manual. Do not use this equipment for

any other purpose than that stated.

2. INFORMATION PROVIDED WITH THE TEST SET

In addition to this User Instruction Manual, the Test Set is delivered with the four information

items described below.

A. The identification label (refer to Figure 1) is located above the handle of the Test Set

case and provides the following information:

Manufacturer Name

Equipment Part Number

Equipment Model Number Equipment Serial Number

Equipment Modification (if applicable) Equipment Options (if applicable)

Figure 1 Identification Label

2311FA

PRESSURE TESTER

101-00212

56-101-00212 Revision E Page | 2

B. The Owner's Warranty Registration card (refer to Figure 2), is to be completed by the

owner and returned to Barfield, Inc. within ten (10) days of purchase to ensure

automatic update of printed matter and validation of warranty.

To register your unit, please visit https://www.barfieldinc.com/warranty_registration or

scan the QR code on the supplied Warranty Registration.

Figure 2 Owner Warranty Registration Card

C. Each new or re-certified unit is delivered with a Certificate (not pictured) that shows the

date when the unit was tested by the manufacturer, its serial number, and when the next

certification is due. This certificate confirms that the unit performed according to its

design specifications.

D. For 2311FA Limited One Year Warranty refer to Figure 3.

3. RECERTIFICATION

A. The Test Set has a one-year recertification requirement. Maintenance required by the

Test Set and the Pressure Gauge must be performed by qualified technicians in a shop

equipped with the necessary tooling and resources. Contact Barfield for Maintenance

and Calibration requirements.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels barfield Équipement de test

barfield

barfield 1811G Manuel de l'opérateur

barfield

barfield 2548H Manuel du propriétaire

barfield

barfield DPS400 Manuel utilisateur

barfield

barfield DFQ40K Manuel de l'opérateur

barfield

barfield 1811GA Series Manuel de l'opérateur

barfield

barfield DPS1000 Manuel de l'opérateur

barfield

barfield DPS1000 Manuel de l'opérateur

barfield

barfield TT-1000A Manuel de l'opérateur

barfield

barfield DPS1000 Manuel de l'opérateur

barfield

barfield 1811NG Manuel de l'opérateur

barfield

barfield TT1200A Manuel de l'opérateur

barfield

barfield TT-1000A Manuel de l'opérateur

barfield

barfield 1811D Series Manuel de l'opérateur

barfield

barfield 2548H Manuel de l'opérateur

barfield

barfield DPS1000 Manuel de l'opérateur

Manuels Équipement de test populaires d'autres marques

SMART

SMART KANAAD SBT XTREME 3G Series Manuel utilisateur

Agilent Technologies

Agilent Technologies BERT Serial Manuel utilisateur

Agilent Technologies

Agilent Technologies N3280A Manuel utilisateur

Vernier

Vernier Go Direct Voltage Manuel utilisateur

Lifeloc

Lifeloc R.A.D.A.R. Manuel utilisateur

Fluke

Fluke T5-600 Instructions d'utilisation et d'installation

Mercury

Mercury TSL01 Manuel utilisateur

MAHA

MAHA MBT Series Manuel utilisateur

Fuji Electric

Fuji Electric P-61 Manuel utilisateur

ETC

ETC SealerAtor Manuel utilisateur

Skyfine

Skyfine ETHYWAY V2 Manuel utilisateur

Appion

Appion G5 Twin Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 8159-0112A Manuel utilisateur

BW Technologies

BW Technologies MicroDock II Manuel utilisateur

Sun Nuclear

Sun Nuclear 1027 Manuel utilisateur

Biomark

Biomark HPR LITE READER Manuel utilisateur

Hioki

Hioki 3169-20 Manuel utilisateur

Ashcroft

Ashcroft ATE-100 Manuel utilisateur

barfield 2311FA Manuel de l'opérateur

Manuels Équipement de test populaires d'autres marques
