10 Display Controller
TYPES OF DISPLAY CONTROLLERS FOR BARCO DISPLAY SYSTEMS
The following models of Barco display controllers are available for your
display system. Please check which of the following models is delivered
with your system, and follow the corresponding installation instructions:
* Recommended PCI/PCIe slot
You can use x16 & x8 slots for x1, & x4 boards.
If you are using a display controller with a VGA jumper, you will need to
decide if you are going to use its on-board VGA capabilities. If you are,
check the setting of the Jumper at J-1 on the display controller. By
default, VGA should be enabled, on the top two pins. To disable the on-
board VGA capabilities move the jumper so that it is on the middle and
bottom pins.
Board Model VGA Jumper Compatible PCIe/PCI Slot
Barco MXRT 1150 No x1*, x8, x16 (PCIe only)
Barco MXRT 2150 No x16 (PCIe only)
Barco MXRT 2400 No x16 (PCIe only)
Barco MXRT 5200 No x16 (PCIe only)
Barco MXRT 5400 No x16 (PCIe only)
Barco MXRT 5450 No x16 (PCIe only)
Barco MXRT 7200 No x16 (PCIe only)
Barco MXRT 7300 No x16 (PCIe only)
Barco MXRT 7400 No x16 (PCIe only)
BARCOMED CORONIS PCIe Yes x8*, x16
BARCOMED CORONIS PCI Yes PCI 32 or PCI 64*
BARCOMED NIO PCIe Yes x8*, x16
BARCOMED NIO PCI Yes PCI 32 or PCI 64*
BARCOMED 5MP2FH PCIe Yes x8*, x16
BARCOMED 5MP2FH PCI Yes PCI 32 or PCI 64*
