®SETTE 270W

MANUAL

v2.1 May 11, 2018

INTRODUCTION

Thank you for purchasing the Sette

Conical Burr Coffee Grinder. With the

Sette, it’s now easier than ever to

make a delicious cup of coffee.

What follows are just some of the features that make the Sette

stand out from other grinders in its class.

CONICAL BURR GRINDER MANUAL

Sette 270W

Conical Burrs

Manufactured in Liechtenstein, the 40mm steel conical

burrs grind coffee at 3.5 grams to 5.5 grams a second.

depending on the setting. These conical burrs are durable

and will remain sharp for many years. The adjustment

mechanism provides precise burr alignment ensuring

accurate grinding.

Grind Adjustment

The Sette has 31 macro-adjustment steps which range from

ne for espresso to medium-coarse for manual brewing. A

stepless micro-adjustment with nine indicators allows the

user to precisely dial in a perfect espresso. The adjustment

mechanism is directly connected to the cone burr, resulting

in immediate and true grind adjustment. This unique

adjustment system gives the Sette a total of 270 discreet

grind settings.

Digital Control Panel

The control panel with backlit LED display is user-friendly.

Three preset buttons can be programmed to the tenth of

a gram for grind-by-weight operation. Simply press the

‘’START’’ button and the Sette automatically delivers

precise dosing.

Convertible Device Holder

A built-in convertible device holder allows you to grind

directly into your portalter, the supplied grounds bin, or

a range of manual brewing devices – a standout feature

amongst all other home grinders. The Sette’s grounds bin

is made from an anti-static plastic, with a spout for easy

transfer into your preferred brewing device. The device

holder can accommodate a wide range of portalter sizes

and includes an integrated hook for stability.

®SETTE 270W

MANUAL

v2.1 May 11, 2018

TABLE OF CONTENTS

INTRODUCTION 1

SAFETY INFORMATION 3

PARTS IDENTIFICATION 4

OPERATION 5

Initial Setup 5

Duty Cycle 5

Adjusting the Convertible Device Arms & Portalter Hook 6

Adjusting the Grind Settings 6

Recommended Initial Settings 6

Weight Based Grinding Operation 7

Programming 7

Burst Mode 7

Pulse Function/Manual Mode 8

Soft Reset Function 8

Bluetooth 8

Over-the-air Updates 8

Backlight 8

CARE & CLEANING 9

Removing the Bean Hopper 9

Removing the Cone Burr/Grind Adjustment Assembly 9

Reinstalling the Cone Burr/Grind Adjustment Assembly 10

Cleaning the Grounds Bin, Hopper & Burrs 11

Clearing a Clogged Grinder 11

Unclogging the Grinder 11

Automatic Cleaning 11

Recalibrating/Shimming the Cone Burr 12

WARRANTY & SERVICE 13

US & Canadian Warranty Information 13

International Warranty Information 13

Proof of Purchase & Product Registration 13

Information on Repair or Questions 13

®SETTE 270W

MANUAL

v2.1 May 11, 2018

SAFETY INFORMATION

Please read the information below very carefully. It contains

important safety information for this appliance. Please keep

these instructions for future reference.

CAUTION: ALWAYS unplug the electrical supply cord prior to cleaning the grinder.

! Use only with AC current and the correct voltage. See the

label on the base of the grinder to determine the correct

voltage.

! Only clean the grinder housing with a dry or slightly damp

cloth. Do not immerse the grinder, plug or cord in water or

any other liquid.

! Baratza will not accept any liability for damage, injury, or

warranty if the grinder is used other than for its intended

purpose (i.e. grinding roasted whole coffee beans) or is

improperly operated or repaired.

! This appliance may be used by children aged from 8

years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience and

knowledge if they are supervised or have been given

instruction concerning use of the appliance in a safe way

and understand the hazards involved.

! If the electrical supply cord is damaged, it must be

replaced by the manufacturer, its service agent or

similarly qualied persons in order to avoid a hazard.

! Always unplug the electrical supply cord before

assembling, disassembling or cleaning the grinder.

! To unplug, grasp the plug and remove from the outlet.

Never pull on the cord.

! Keep the appliance and its cord out of reach of children

aged less than 8 years.

! Do not leave your grinder unattended while powered ON.

! Cleaning and maintenance shall not be done by children

without supervision.

! Do not operate the grinder with a damaged cord or plug.

®SETTE 270W

MANUAL

v2.1 May 11, 2018

PARTS IDENTIFICATION

1. Hopper Lid

2. Bean Hopper

3. Bean Shutoff Knob

4. Hopper Alignment Indicator

5. Control Panel

6. Grind Adjustment Assembly

7. Adjustable Portalter Hook

8. Convertible Device Arms

9. Grounds Bin

10. Power Cord

11. Removable Grounds Tray

12. LCD Display

13. Memory Preset Buttons & Indicators

14. Grinding Indicator

15. Stop

16. Start/Pause

17. Grind Weight Adjustment Buttons

18. Installation/Removal Tab

19. Installation/Removal Indicator

20. Macro Adjust

21. Stepless Micro Adjust

22. Bag of Tools

15 16

1918

®SETTE 270W

MANUAL

v2.1 May 11, 2018

OPERATION

INITIAL SETUP

Hand-wash the hopper lid (1), bean hopper (2), grounds bin (9), and removable grounds tray (11) in warm, soapy water and

dry thoroughly. Do not wash the grind adjustment assembly (6) in water or it, and the cone burr, will rust.

With the bean shutoff knob (3) facing the 11 o’clock position, line up the 3 hopper tabs with the slots in the top of the

grinder. Set the hopper in place and rotate rmly clockwise until the hopper clicks into place. Install the hopper lid (1) onto

the bean hopper (2). Rotate macro-adjustment until the black grind setting indicator is at 18.

DUTY CYCLE (RATIO OF GRINDER USE:REST)

The Sette is designed for a maximum of 2 lbs (1 kg) per day, with a duty cycle of 10%. Exceeding this duty cycle will not

immediately break your Sette, however its longevity may be reduced if you exceed this. We want to remind everyone buying

the Sette that it was designed for home use (short duration grinding).

Here is a general overview of the duty cycle of the Sette Series:

1. Espresso (Settings 3-9): after grinding a dose of espresso (avg 18g), for approx 6 seconds, the 270Wi should

rest for about 60 seconds. This is about what you would expect if making back-to-back shots on a one-group

machine - 1 shot/minute.

2. Brew (Setting 15-30): if grinding a batch for lter brew (of no more than 150g of coffee in a single operation

- about the capacity of the included grounds bin) for approx 25 seconds. Then, the grinder should rest for

about 250 seconds - 1 grind batch/4 mins.

Note: The hopper must be installed with the black grind setting indicator (20) on a setting of 31

or lower for the motor to start. Ensure the shut-off knob (3) is in the open position.

®SETTE 270W

MANUAL

v2.1 May 11, 2018

ADJUSTING THE CONVERTIBLE DEVICE ARMS & PORTAFILTER HOOK:

To convert the device holder to the portalter holder position, push in on the right arm

and swing it down and to the left until it clicks into position (g. A). To return to the

original position, push in on the right arm and rotate to the right and up until it clicks

into place (g. B). The left arm will automatically move into position as the right arm is

moved.

When grinding directly into a portalter, you must rst convert the arms to portalter

holder position and swing the hook to the front. The hook is designed to support the

top lip of your portalter while the arms support the bottom of your portalter. It is

imperative that the hook is adjusted so that the portalter sits level. To adjust the

hook, loosen the 2mm hex screw that sits below the hook, adjust the portalter hook

up or down, and tighten screw once in the proper position. After adjusting the hook,

run a test grind. If the portalter does not sit level through the grinding process, further

adjustments may be needed.

ADJUSTING THE GRIND SETTING

The Sette has two different adjustments. The macro adjust makes large adjustments from 1-31, while the stepless micro

adjust allows for small adjustments to ne-tune. We recommend running the motor when making micro or macro grind

adjustments. It’s best to start with your micro adjustment at “E”, and dial in the macro as close to the desired grind as

possible, then adjust the micro as needed.

RECOMMENDED INITIAL SETTINGS

The macro settings shown in the table below can be used as a general guideline for starting points*. The actual particle

size for a particular setting will vary depending on many factors including the degree of roast (light vs. dark), freshness,

humidity, type of bean, oil content, etc. As such, there is no exact correct setting for any brewing method. Baratza

recommends starting with our suggested settings and adjusting to taste from there. For espresso, we recommend 9E.

For drip, we recommend 20E. With use, you will determine the setting that is right for your taste, brewing style, and your

favorite beans.

Espresso AeroPress V-60 Drip brew

3-9 10-15 13-18 15-25

*If you nd that your preferred setting is outside of this range, there is no need to be concerned, grind to your

personal taste.

g. A

g. B

Warning: The Sette grinds at a very high speed, so be careful not to overll the portalter or

bin! If a mound of coffee backs up into the chute it will clog the grinder. Unclogging requires

thorough manual cleaning.

®SETTE 270W

MANUAL

v2.1 May 11, 2018

WEIGHT BASED GRINDING OPERATION

Place the portalter or grounds bin onto the convertible arms. Press a preset button (1,2,3). The screen will show the

corresponding programmed grind weight in grams. Press ‘’START’’. There may be a slight delay as the machine tares and

then begins grinding. While grinding, the screen will count up in grams to the target weight, the motor will stop, hitting the

desired gram amount.

If you would like to stop before the cycle has completed, press the STOP button.

This will turn the motor off, and reset the screen to your initially chosen grind weight.

However, if you would like to pause the grind without resetting to the initially chosen

grind weight, press the PAUSE button. This will immediately pause the machine.

Pressing ‘’START’’ will resume grinding until the unit reaches the desired weight. To

reset the grind cycle press the STOP button.

PROGRAMMING

The Sette 270Wiis equipped with three programmable buttons (1, 2, 3). These only adjust the desired grind weight, they do

not adjust the grind setting (i.e. coarse/ne). Each button comes from the factory with the following presets: 1=18g, 2=25g,

3=35g.

You can easily adjust the presets by following these steps:

1. Select a preset button.

2. Press the up or down arrow buttons to adjust the weight.

3. Once you have reached the desired weight setting, press and hold the preset button for three seconds, at

which point the screen will blink to conrm. The setting is now saved, even if the grinder is unplugged.

BURST MODE

If during weight based grinding operation, a preset grind cycle is stopped within ve grams of the target weight due to

interference, pressing ‘’START’’ will provide a very short burst of grinding that can be repeated indenitely. Use this mode to

“top off” a dose. Exiting this mode requires removal of the grounds bin/portalter or pressing the STOP button.

If the grinder stops more than ve grams before the target weight, the grinder will not enter Burst Mode and instead will

behave as if paused. Simply press ‘’START’’ once more to resume grinding towards the target weight.

135

FineCoarse

791113151719212325272931

CoarserFiner A B C D E F G H I

Note that the Sette 270Wi, when new, will require 3 to 4 grind cycles to acquire an accurate

offset and dose within a few tenths of a gram of the target.

®SETTE 270W

MANUAL

v2.1 May 11, 2018

PULSE FUNCTION/MANUAL MODE

The Sette 270Wialso has a pulse function/manual weight

grinding mode. To turn the grinder on in this mode, simply hold

‘’START’’ for more than 2 seconds. The Sette will ash “P”, then

it will show 0.0, indicating that the scale has tared. Pressing and

holding ‘’START’’ again will engage the motor. The grinder will

count up as it measures ground coffee, and will cease grinding as

soon as ‘’START’’ is released. At this point, the ‘’START’’ button is

now a pulse button. To exit this mode, press STOP.

SOFT RESET FUNCTION

The soft reset function serves to erase the grinder’s “memory” of previous grinds. This is useful if the grinder has not

reached an accurate dose weight after 3-4 grinds (on a single grind setting), or after making a signicant change in grind

setting (15+ macro settings). Erasing the record of previous grinds allows the software to start learning with a clean slate.

Each preset (1, 2 & 3) has its own independent “memory”, so the Soft Reset function is specic to a single preset.

To perform a Soft Reset on a specic preset, make sure the desired preset is selected. Then double tap the PLAY button.

The grinder will ash “CC” then immediately grind the preset dose. From this dose forward, the grinder should reach

accuracy within 3-4 grinds, as long as the grind size is not changed.

BLUETOOTH

Your Sette 270Wi is equipped with Bluetooth thanks to collaboration between Baratza and Acaia. Bluetooth functionality

allows for easy updating of the software and user experience without the need to conduct physical repairs, as well as

access to Acaia’s suite of apps for coffee enthusiasts.

OVER-THE-AIR UPDATES

For the best experience, download Sette Updater (by Acaia) from the Apple App Store. If, in the future, changes are made to

the user experience or software, your 270Wican receive those updates via Bluetooth.

BACKLIGHT

To turn off the backlight, press and hold STOP for two seconds. To turn the backlight on, simply press the STOP button.

NOTE: 5g minimum for preset mode: The software prevents users from setting a preset below

5g. Due to the speed of the grinder, it is unable to be accurate for weights less than 5g.

®SETTE 270W

MANUAL

v2.1 May 11, 2018

CARE AND CLEANING

REMOVING THE BEAN HOPPER

Rotate the bean shutoff knob to the CLOSED position, then press the ‘’START’’ button to

purge any remaining beans. Remove the power plug from the power outlet. Remove the

hopper by rotating it counterclockwise until it stops, and then lift the bean hopper off of

the grinder housing. It can be helpful to remove/insert the hopper while the lid is on, to

provide stability.

REMOVING THE CONE BURR/GRIND ADJUSTMENT ASSEMBLY

1. The adjustable portalter hook must be swung to the side in order to remove the

grind adjustment assembly (g. C).

2. Rotate the bean shutoff knob so it is in the CLOSED position, then hold the START button to run any

remaining beans through the grinder (g. D).

3. Once the grinder has been fully purged, rotate the grind adjustment assembly beyond the coarsest setting

to the install/remove indicator (blue triangle). The assembly will release downward for removal (g. E).

g. C g. D g. E

®SETTE 270W

MANUAL

v2.1 May 11, 2018

REINSTALLING THE CONE BURR/GRIND ADJUSTMENT ASSEMBLY

1. Align the blue installation/removal indicator on the grind adjustment assembly with the blue installation/

removal indicator on the right side of the machine (g F).

2. Keeping the two blue indicators aligned, gently press up on the grind adjustment assembly and rotate the

black cone burr holder (g G) until the tabs and notches line up and the cone burr holder slides up into the

machine. At this point the cone burr and holder will be inserted into the machine and no longer visible (g

H). For a video tutorial, watch our video on youtube.

3. While applying upward pressure, rotate the grind adjustment assembly as shown (g H) rotating the blue

tab towards the rear of the grinder. The adjustment assembly will click as it properly engages and the black

macro adjustment will be aligned with the 1-31 scale on the machine.

g. F g. G g. H

Autres manuels pour Sette 270Wi

Table des matières

Autres manuels Baratza Broyeur

Baratza

Baratza Sette 270Wi Manuel utilisateur

Manuels Broyeur populaires d'autres marques

Parkside

Parkside PWS 230 C3 Manuel utilisateur

SUHNER ABRASIVE

SUHNER ABRASIVE ASC 9 Manuel technique

PTA

PTA P1322 Manuel utilisateur

Crown

Crown CT13313 Manuel utilisateur

Parkside

Parkside 280250 Manuel utilisateur

Climax

Climax VM2150 Series Manuel utilisateur

Jet

Jet JPSG-618M1 Manuel de service

Makita

Makita GA4030 Manuel utilisateur

DeWalt

DeWalt DWEN202 Manuel utilisateur

Grizzly

Grizzly G2790 Manuel utilisateur

Fein

Fein MSf843-1a Manuel utilisateur

Bosch

Bosch GWS 14,4 V PROFESSIONAL Manuel utilisateur

RAMSET

RAMSET CBAGR18 Manuel utilisateur

Bosch

Bosch 8-115 Z Manuel utilisateur

STEELE PRODUCTS

STEELE PRODUCTS SP-PB008 Manuel utilisateur

MW TOOLS

MW TOOLS ME15W Manuel utilisateur

Caravaggi

Caravaggi SP 20 Mode d'emploi

SUHNER ABRASIVE

SUHNER ABRASIVE UWK 10-R125 Manuel technique
