READ & SAVE THESE INSTRUCTIONS
100In. High Volume Ceiling Fan
Owner’s Manual
WARNING: Read carefully and understand all ASSEMBLY AND OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety
precautions may result in serious personal injury.
Item #57937
Page 2 of 21
Thank you very much for choosing a Bannon™product!
For future reference, please complete the owner’s record below:
Serial Number/Lot Date Code: ________________________________
Purchase Date: ____________________________________________
Save the receipt, warranty, and this manual. It is important that you read
the entire manual to become familiar with this product before you begin
using it.
This fan is designed for certain applications only. Northern Tool and
Equipment is not responsible for issues arising from modification or
improper use of this product such as an application for which it was not
designed. We strongly recommend that this product not be modified
and/or used for any application other than that for which it was designed.
For technical questions, please call 1-800-222-5381.
Page 3 of 21
Table of Contents
Intended Use..........................................................................................................................................4
Packaging Contents..............................................................................................................................4
Technical Specifications......................................................................................................................4
Important Safety Information...............................................................................................................4
Specific Operation Warnings...............................................................................................................6
Assembly and Installation Instructions..............................................................................................7
Before Each Use..................................................................................................................................14
Operating Instructions........................................................................................................................14
After Each Use.....................................................................................................................................16
Maintenance ........................................................................................................................................16
Troubleshooting..................................................................................................................................17
Parts Diagram......................................................................................................................................18
Parts List..............................................................................................................................................18
Replacement Parts..............................................................................................................................19
Limited Warranty.................................................................................................................................20
Page 4 of 21
Intended Use
The Bannon 100In. High Volume Ceiling Fan is designed for large, high ceiling areas such as
factories, barns, ranches, gyms, and warehouses. The low electric usage is perfect for continuous
use.
Packaging Contents
Motor (1)
Blade Pack (8)
Remote Control (1)
Hanger Bracket &
Canopy (1)
Down Rod (1)
Hardware Packet (1)
Technical Specifications
Property
Specification
Motor
120 Volt / 60 Hz AC
Max Current Consumption
1.4 Amps
Watts
120 W
CFM
35,000
Important Safety Information
⚠WARNING
Read and understand all instructions. Failure to follow all instructions may result in serious injury
or property damage.
The warnings, cautions, and instructions in this manual cannot cover all possible conditions or
situations that could occur. Exercise common sense and caution when using this tool. Always be
aware of the environment and ensure that the tool is used in a safe and responsible manner.
DO NOT allow persons to operate or assemble this product until they have read this manual and
have developed a thorough understanding of how the product works. Industrial or commercial
applications must follow OSHA requirements.
Do not modify this product in any way. Unauthorized modification may impair the function and/or
safety and could affect the life of the product. There are specific applications for which the product
was designed.
Use the right tool for the job. DO NOT attempt to force small equipment to do the work of larger
industrial equipment. There are certain applications for which this equipment was designed. This
product will be safer and do a better job at the capacity for which it was intended. DO NOT use
this equipment for a purpose for which it was not intended.
Industrial or commercial applications must follow OSHA requirements.
⚠WARNING
Page 5 of 21
WORK AREA SAFETY
Inspect the work area before each use. Keep work area clean, dry, free of clutter, and well-lit.
Cluttered, wet, or dark work areas can result in injury. Using the product in confined work areas
may put you dangerously close to cutting tools and rotating parts.
Do not use the product where there is a risk of causing a fire or an explosion; e.g., in the presence
of flammable liquids, gases, or dust. The product can create sparks, which may ignite the
flammable liquids, gases, or dust.
Do not allow the product to come into contact with an electrical source. The tool is not insulated
and contact will cause electrical shock.
Keep children and bystanders away from the work area while operating the tool. Do not allow
children to handle the product.
Be aware of all power lines, electrical circuits, water pipes, and other mechanical hazards in your
work area. Some of these hazards may be hidden from your view and may cause personal injury
and/or property damage if contacted.
⚠WARNING
PERSONAL SAFETY
Stay alert, watch what you are doing, and use common sense when operating the tool. Do not use
the tool while you are tired or under the influence of drugs, alcohol, or medication. A moment of
inattention while operating the tool may result in serious personal injury.
Dress properly. Do not wear loose clothing, dangling objects, or jewelry. Keep your hair, clothing
and gloves away from moving parts. Loose clothes, jewelry, or long hair can be caught in moving
parts. Air vents on the tool often cover moving parts and should be avoided.
Wear the proper personal protective equipment when necessary. Use ANSI Z87.1 compliant safety
goggles (not safety glasses) with side shields, or when needed, a face shield. Use a dust mask in
dusty work conditions. Also use non-skid safety shoes, hardhat, gloves, dust collection systems,
and hearing protection when appropriate. This applies to all persons in the work area.
Do not overreach. Keep proper footing and balance at all times.
⚠CAUTION
FAN USE AND CARE
Do not force the fan. Products are safer and do a better job when used in the manner for which
they are designed. Plan your work, and use the correct product for the job.
Check for damaged parts before each use. Carefully check that the product will operate properly
and perform its intended function. Replace damaged or worn parts immediately. Never operate the
product with a damaged part.
Do not use a product with a malfunctioning switch. Any power tool that cannot be controlled with
the power switch is dangerous and must be repaired by an authorized service representative
before using.
Page 6 of 21
Disconnect the power/air supply from the product and place the switch in the locked or off position
before making any adjustments, changing accessories, or storing the tool. Such preventive safety
measures reduce the risk of starting the tool accidentally.
Store the product when it is not in use. Store it in a dry, secure place out of the reach of children.
Inspect the tool for good working condition prior to storage and before re-use.
Use only accessories that are recommended by the manufacturer for use with your product.
Accessories that may be suitable for one product may create a risk of injury when used with
another tool. Never use an accessory that has a lower operating speed or operating pressure than
the tool itself.
Keep guards in place and in working order. Never operate the product without the guards in place.
Specific Operation Warnings
⚠WARNING
To reduce the risk of injury to persons, the fan must be installed so that the blades are a height
greater than 3 meters (10 feet) above the floor.
To reduce the risk of electric shock, or personal injury, mount to outlet box marked “acceptable for
fan support of 22.7 Kg (50 lb.) or less” and use mounting screws provide with the outlet box and/or
support directly from building structure. Most outlet boxes commonly used for the support of
lighting fixtures are not acceptable for fan support and may need to be replaced. Consult a
qualified electrician if in doubt.
To reduce the risk of fire or electrical shock, this fan should only be used with fan speed control
part #: BF-5, manufactured by: Zhongshan Hongwei Motor Manfacturing Co,.Ltd.
To reduce the risk of fire or electrical shock, do not expose fan to water or rain.
Do not use fan near windows; rain and moisture may create an electrical hazard.
Do not alter fan’s assembly.
Automatically operated device — to reduce risk of injury, disconnect from power supply before
servicing.
Installation work and electrical wiring must be done by a qualified electrician in accordance with all
applicable codes and standards (ANSI/NFPA 70-1996) including fire-rated construction.
Before you begin installing the fan, switch power off at the service panel and lock service
disconnecting means prevent power from switched on accidently. When the service disconnecting
means cannot be locked, securely fasten a prominent warning device, such as a tag to the service
panel.
If the power supply cord is damaged, contact your local service center or a qualified electrician to
install an appropriate replacement cord to prevent any injury or damage.
The appliance should not be used in locations where special conditions prevail such as the
presence of a corrosive or explosive atmosphere (dust, vapor, gas).
After making wire connection, gently push connections into the outlet box with wire nuts pointing
up. The wires should be spread apart with the grounded conductor and the equipment grounding
conductor on one side of the outlet box and the ungrounded conductor on the other side of the
Page 7 of 21
outlet box.
When cutting or drilling in the ceiling or wall, do not damage electrical wiring and other hidden
utilities.
To reduce the risk of injury, do not bend blade holders during installation to motor, balancing or
during cleaning. Do not insert foreign object between rotating blades.
Attach the mounting bracket using only the hardware supplied with the outlet box. Fan is only to
be mounted to an outlet box marked “Acceptable for Fan Support”.
When moving or cleaning fan, turn off power at service panel and lock service disconnecting
means to prevent power being turned on accidently. When the service connecting means cannot
be locked, securely fasten a prominent warning device, such as a tag to the service panel.
All set screws must be checked and re-lightened where necessary before installation.
Do not place the fan near an open flame, cooking or heating appliance, or hot surface.
This fan should NOT be operated outside.
Assembly and Installation Instructions
⚠WARNING
To reduce the risk of injury to persons, the fan must be installed so that the blades are a height
greater than 3 meters (10 feet) above the floor.
To reduce the risk of electric shock, or personal injury, mount to outlet box marked “acceptable for
fan support of 22.7 Kg (50 lb.) or less” and use mounting screws provide with the outlet box and/or
support directly from building structure. Most outlet boxes commonly used for the support of
lighting fixtures are not acceptable for fan support and may need to be replaced. Consult a
qualified electrician if in doubt.
To reduce the risk of fire or electrical shock, this fan should only be used with fan speed control
part #: BF-5, manufactured by: Zhongshan Hongwei Motor Manfacturing Co,.Ltd.
Installation work and electrical wiring must be done by a qualified electrician in accordance with all
applicable codes and standards (ANSI/NFPA 70-1996) including fire-rated construction.
Before you begin installing the fan, switch power off at the service panel and lock service
disconnecting means prevent power from switched on accidently. When the service disconnecting
means cannot be locked, securely fasten a prominent warning device, such as a tag to the service
panel.
If the power supply cord is damaged, contact your local service center or a qualified electrician to
install an appropriate replacement cord to prevent any injury or damage.
When cutting or drilling in the ceiling or wall, do not damage electrical wiring and other hidden
utilities.
To reduce the risk of injury, do not bend blade holders during installation to motor, balancing or
during cleaning. Do not insert foreign object between rotating blades.
Attach the mounting bracket using only the hardware supplied with the outlet box. Fan is only to
be mounted to an outlet box marked “Acceptable for Fan Support”.
Page 8 of 21
All set screws must be checked and re-lightened where necessary before installation.
PREPARING FOR INSTALLATION
Unpack and inspect fan carefully to be certain all contents are included. Turn off power at fuse
box to avoid possible electrical shock.
DOWNROD INSTALLATION VAULTED CEILING INSTALLATION
May require a longer downrod for high vaulted ceilings (sold separately).
Page 9 of 21
MOUNTING BRACKET INSTALLATION
Remove the screws from the two matching holes (1) on canopy. Loosen (do not remove) the
screws in the matching slots (2) on the canopy. Rotate the mounting bracket and remove from the
canopy.
Install mounting bracket to the outlet box in the ceiling using the screws and the washers provided
with your outlet box.
Page 10 of 21
DOWNROD ASSEMBLY (included)
Remove clamp pin (1) and cross pin (2) from down rod (3).
Feed motor lead wires through downrod and canopy assembly and insert downrod into downrod
yoke.
Make sure to align holes in downrod with the hole in the yoke.
Install yoke cross pin (1) through yoke and downrod.
Insert clamp pin (2) into cross pin until it snaps securely into place.
Tighten set screws (3) in yoke.
USING EXTENDED DOWNROD
(Not included)
Loosen the downrod ball (1) from the downrod (2) by removing the screw (3).
Slide downrod ball (1) off of the downrod and remove pin (2).
Table des matières
Autres manuels Bannon Ventilateur
