B&B Electronics USR604 Manuel utilisateur

Install the Drivers

2Set DIP Switches

4Connect the Converter

Product Overview

Serial

Ports

LEDs

Power the Converter

USB Port

The USR602 can run on 5 V USB power if the host

port is providing 500 mA. It can also be powered

via the terminal block or barrel jack port.

Set the converter to RS-232 mode using the DIP

switches. Loopback pins 2 and 3. Using Hyper Termi-

nal or similar program, connect to the COM port. Set

the desired baud rate. Ensure that Hyper Terminal

local echo is OFF. Transmit data. If the same character

string is returned, the test is good.

DIP

Switches

Terminal block

and barrel jack

power

To prevent installation errors, do not plug in the

hardware until you have already installed the drivers.

Use the included CD to install the converter’s drivers in

the attached PC.

DIP

Switches SW# RS-232 RS-422 RS-485

4-Wire

RS-485

2-Wire

Port 1 1 Off ON Off ON

2 Off ON ON Off

Port 2 3 Off ON Off ON

4Off ON ON Off

Port 3 5 Off ON Off ON

6 Off ON ON Off

Port 4 7 Off ON Off ON

8 Off ON ON Off

When you connect the converter to the host

computer’s USB port the Found New Hardware

wizard will open. It will discover and install the

USB device. Then it will discover and install each

serial port. Allow Windows to install the converter

“Automatically.” There is no need to connect to the

Internet or Windows Update.

If a popup window says the software has not passed

Windows logo testing, that’s OK. Just click on

“Continue Anyway.”

When the wizard is complete the serial ports on the

converter will appear in Windows Device Manager

as new COM ports.

5Conﬁgure the Serial Ports

Open Control Panel. Click “System” to open the

Device Manager. Under “Ports,” double-click the

port to be conﬁgured.

On the “Serial Port Properties” window, set the

required communications parameters for the system

with which you are communicating. If necessary,

6Loopback Test

7LEDs

LED

Type Indication when ON

PWR

Computer is receiving adequate

voltage and current from USB or

power source

TX Serial interface is transmitting data

RX Serial interface is receiving data

click Advanced and set up the Advanced Properties.

(Refer to manual for more information.)

Troubleshooting

Fast, Easy Answers

One USB port is required for each installed device.

The USB port can be native to the PC or it can be a

USB port on a USB hub that is connected to a PC.

The device works with USB 1.1 or 2.0 ports. But it

has a maximum USB data rate of 12 Mbps.

To verify the installation you may open the Windows

Device Manager. Scroll down to Ports. Expand the

ﬂyout window. You should see the new ports. If there

are no exclamation points or other trouble indicators

the ports are installed correctly and ready for use.

Sleep & Hibernate: Windows 7 disables USB transmit

while in Sleep & Hibernate.

Terminal Block

One conductor per terminal.

Use copper wire only.

Wire size 16 to 28 AWG.

Tightening torque 5 KG -CM.

Wire temperature rating: 105 °C

(Sized for 60 °C ampacity

Fast and easy on the web:

www.bb-elec.com

Four-port USB to

Serial Converter

USR604

1-888-948-2248 | Europe: +353 91 792444

www.bb-elec.com

Recommended Accessories

Please double check

Step 6.

You can also use your

smart phone to access

complete documentation

on our website. Simply

scan the code to the right.

PS12VLB-INT-MED

Power Supply

http://www.bb-elec.com/

product_multi_family.asp?

MultiFamilyId=133&Trail=

16&TrailType=Top

MDR-20-24

DIN rail mount

power supply

http://www.bb-elec.com/

product_multi_family.asp?

MultiFamilyId=133&Trail=

16&TrailType=Top

USR604

Two Meter USB Cable

Panel mount adapters

DIN rail mount adapter

CD ROM with Drivers

First Things First...

Before you begin, be sure you have

the following:

707 Dayton Road | PO Box 1040 | Ottawa, IL 61350

Phone: 815-433-5100 | Fax: 815-433-5109

www.bb-elec.com | E-mail: [email protected]

•

Quick

Start

Guide

Information - FCC rules

This device complies with Part 15 of the FCC rules.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference.

(2) this device must accept any interference that may

cause undesired operation.

Information - UL Class 1 Div 2

Suitable for use in Class 1, Division 2, Groups A, B, C and

D Hazardous Locations, or Nonhazardous locations only.

WARNING - EXPLOSION HAZARD – DO NOT

DISCONNECT EQUIPMENT WHILE THE CIRCUIT IS LIVE

UNLESS THE AREA IS KNOWN TO BE FREE OF

IGNITABLE CONCENTRATIONS.

Install in accordance with control drawing

number 9340R0.

Ind. Cont. Eq.

For HAZ LOC

3HTV

E245458

Class I, Div. 2, Groups A, B, C & D

Temp. Code: T4A

Document number – PN9781_R000_USR604_4712qsg
