Balluff BF-IDM17 Manuel utilisateur

Model:

BF-IDM17 Operating Guide

RFID Reader

Company Addresses

Europe, Germany, Headquarter

Balluff GmbH

Schurwaldstraße 9

D-73765 Neuhausen, Germany

Argentina

Balluff Argentina S.R.L.

Echeverría 1050, 1st UF 2

1604 Buenos Aires - Florida Oeste

Australia

Balluff Pty Ltd.

18 Malvern Street

Bayswater, 3153 Victoria

Brasil

Balluff Controles Elétricos Ltda.

Rua Francisco Foga, 25 ,Distrito Industrial

CEP 13280.000 –Vinhedo –SP

Canada

Balluff Canada Inc.

2840 Argentia Road, Unit 2 Mississauga,

Ontario L5N 8G4

China

Balluff (Shanghai) Trading Co. Ltd.

No.800 Chengshan Rd, 8F, Building A, Yunding International Commercial Plaza

200125, Pudong, Shanghai

Japan

Balluff Co., Ltd.

Aqua Hakusan Bldg. 9F 1-13-7 Hakusan, Bunkyo-ku,

Tokyo 113-0001

Mexico

Balluff de México S.A. de C.V.

Anillo Vial II Fray Junipero Serra No. 4416; Colonia La Vista Residencial

CP 76232 Delegación Epigmenio González, Querétaro

USA

Balluff Inc.

8125 Holton Drive, Florence

Kentucky 41042-0937

Model:

BF-IDM17 Operating Guide

RFID Reader

Regulatory Information

This device complies with part 15 of the FCC Rules and with Industry Canada’s licence-

exempt RSSs.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that may

cause undesired operation.

Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio

exempts de licence. L’exploitation est autorisée aux deux conditions suivantes :

(1) l’appareil ne doit pas produire de brouillage;

(2) l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est

susceptible d’en compromettre le fonctionnement.

Changes or modifications not expressly approved by the party responsible for compliance voids

the user's authority to operate this equipment.

Note: This equipment has been tested and found to comply with the limits for a Class A digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate radio frequency energy and, if

not installed and used in accordance with the instruction manual, may cause harmful

interference to radio communications. Operation of this equipment in a residential area is likely

to cause harmful interference in which case the user will be required to correct the interference

at his own expense.

Model:

BF-IDM17 Operating Guide

RFID Reader

Purpose of the Device

The BF-IDM17 RFID Reader is intended to read and write ISO15693 / ISO14443 compliant data

carriers via magnetic field communication.

Variability

BF-IDM17 RFID Readers are available in different housings and shapes.

Model:

BF-IDM17 Operating Guide

RFID Reader

Connecting the Device

BF-IDM17 devices communicate via RS-232 with the controlling unit.

To ensure reliable operation in strong EMC environments it is recommended to connect metal

housings or dedicated functional ground pins directly to installations ground. The ground

Connection should be short and stable. Depending on the installation situation an indirect

ground connection using a RC combination may be required.

For further notes concerning the installation of the processor unit please refer to the operating

guide of the processor unit.

BIS M

RS-232

BIS M

Power

Supply

Power +

RS-232

Power

Model:

BF-IDM17 Operating Guide

RFID Reader

Installation notes

For proper operation at first a suitable mounting position has to be evaluated. The position

should respect the recommended clear zones as described. Furthermore, please note that

strong electrical or magnetic fields in the close environment may influence the RFID Reader.

Precise information concerning clear zones and distances are available on request.

For BF-IDM17 Readers are available in different housings respectively shapes different types of

installation may be considered.

a) Direct In-Hole mounting (Example):

Picture 2: Direct In-Hole mounting (Example)

b) Direct On-Wall mounting (Example):

Picture 3: Direct On-Wall mounting (Example)

Model:

BF-IDM17 Operating Guide

RFID Reader

c) Indirect On-Wall mounting using metal holder (Example):

Picture 3: Indirect On-Wall mounting using metal holder (Example):

Model:

BF-IDM17 Operating Guide

RFID Reader

Setup and Operation

For operation of BF-IDM17 Readers a controlling unit is needed. The BF-IDM17 Readers

communicate directly with the controlling unit if it is connected.

Status Indicators

The device will show its status using the 2 LEDs at the corners of the housing. In normal

operation state the meaning of these lights are as follows:

►Green light "Power" indicates that the device is connected to the processor unit and ready to

operate.

►Orange light "Tag present" indicates that a RFID tag has been detected in front of the

transceiver coil.

Electrical Data

Operating voltage (nominal)

+19,2…26,4 V DC

Current draw (at +26,4 V DC)

≤ 200 mA

Operating Frequency

13.56 MHz

Active principle

Magnetic field

Transmit power

Class 5

Mechanical Data

Housing Material

Metal / ABS-GF16 / PBT / PA12-GF30

Weight max.

400g

Ambient temperature

0…+70°C
