Ballard Designs LO483 Manuel utilisateur
PRODUCT NAME: LED Illuminated Hanging Sphere
ITEM NUMBER: LO483
ASSEMBLED DIMENSIONS: 7.48”H x 7.87” Diameter
PRODUCTS ARE NOT INTENDED
FOR COMMERCIAL USE.
UPDATED: 9-21-2022 Page 1 of 4
MADE IN CHINA
IMPORTANT SAFETY INSTRUCTIONS:
-For your safety, read entire Instruction Sheet before using fixture.
-Keep product out of reach of children. Fixture is not a toy.
-Protect from excessive moisture. Bring indoors during rain/inclement weather.
-Protect fixture from chemicals, liquids and excessive heat.
-Do not drop, stand on, jump nor place heavy objects on fixture.
-Do not use fixture if cracked or broken. Warranty voided if lamp opened without permission.
-Disconnect from charger when not in use.
-CHARGING: Place on level surface in DIRECT SUNLIGHT or use USB-C cord (included).
-NOTICE: 5V MAX Charger ONLY (not included). Higher than 5V will damage battery.
-Dust or grime may block SOLAR PANELS and PREVENT CHARGING. Periodically use a water
dampened cloth to wipe panels clean.
WARNING:
-Built-in rechargeable battery IS NOT replaceable.
-Do not remove or replace built-in battery.
-Do not dispose fixture into trash. Refer to local regulations for proper disposal.
-Battery should be fully discharged before disposal.
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
COMPONENTS
INCLUDED:
Page 2 of 4
ENVIRONMENTAL PROTECTION:
This symbol on the product dictates that Waste electrical products should not be disposed of
with household waste. Please recycle where facilities exist. Check with your Local Authority or
retailer for recycling advice.
Approved Location for Use: Indoor/Outdoor Environment
Charging Time: Approximately 4 hours via USB; 8-10 hours via solar (depends on sunlight intensity)
Running Time: Approximately 4 - 6 hours
Remote Range: Approximately 13 to 26 feet
CLEANING and CARE: Periodically wipe down with a soft, clean cloth. Turn off when not in use.
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
Retain these instructions for future reference.
1 - Fixture (A) 1- USB-C Cord (D)
STEP 1: ASSEMBLE LAMP
Fit loop on Hanger (B) onto Fixture (A) hook/loop.
Hook/Loop screws into Fixture top. Gently tighten if
necessary. Do not over-tighten.
(A)
(B)
ASSEMBLY AND USE
Prevent accidentally discarding small parts or
hardware. Retain all carton contents until assembly
and installation are complete.
1 - Hanger (B) 1 - Remote Control (C)
Hook/Loop
Page 3 of 4
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
STEP 2: CHARGE BATTERY
Connect USB-C Cable (D) to a computer or 5V
OUTPUT charging adapter. Insert other end of Cable
into Type-C Port on Fixture (A).
Prior to use, charge for 4-5 hours (or until fully charged).
NOTE: Indicator light is RED during CHARGING and
GREEN when fully charged and process is complete.
Do Not Charge in Rain or Water
Electrical Shock Hazard
Charge in a Dry Indoor Evironment
WARNING
OR
NOTICE: 5V Output ONLY
NOT INCLUDED:
STEP 3: POWERING LAMP
ON/OFF Dimmer Switch: Turn on/off by HOLDING DOWN switch on bottom of Fixture(A) for
approximately 2-3 seconds.
COLORS: Quick press button or use Remote Control
SENSOR: ON position activates twilight function, turning light on in low light environments. Light
will automatically turn off when environmental light is restored.
SENSOR OFF: Hold switch down 4-5 seconds until red light flashes.
SOLAR PANELS
- To achieve optimum lighting performance, place fixture in a location where it can absorb maximum
sunlight during the day. Direct sunlight. No shaded areas.
-Ensure there are no other light sources (street lamps, porch lights, etc.) near charging location as
they could interfere with process. Lower solar light levels (winter months) may affect charging time.
-Keep Panels clear of dust, grime and debris by periodically wiping down with a damp cloth.
5
V
O
L
T
S
2.1mm
2.1mm
Switch
Charging
Port 16 solid colors, including white.
Brightness +
Brightness -
FLASH: Flash Red-Green-Blue
STROBE: Flash 7 Colors
FADE: Fade through 16 colors.
Short run time. (high battery draw)
SMOOTH: Fade Red-Green-Blue.
Long run time. (low battery draw)
Page 4 of 4
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
OUTDOOR USE
- Although Fixture is weatherproof and safe for outdoor use, NONE of the charging components are.
ALL CHARGING ACTIVITY MUST BE PERFORMED IN A DRY INDOOR ENVIRONMENT.
-Protect Fixture from excessive moisture. Do not leave outside in rainy, stormy weather.
STORAGE
- Recommended that lamp is stored during winter months or when not in use for long periods.
-Completely dry all components then store in a cool, dry area. NOTE: When lamp is returned to
service, follow first time set up procedure outlined in STEP 1.
FCC INSTRUCTION:
Caution: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equip-
ment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
Battery Operating Environment:
Charging: 32°F to 113°F (Temps below 32° reduce capacity and battery life.)
Discharge: 6.8 °F to 122°F
Long Term Storage: -4°F to 77°F (Charge every 3 months during storage period)
