Badger Basket 97851 Guide de configuration rapide

Metal and Bamboo Multi-Bin

Storage Cubby

Assembly and Use Instructions. Adult Assembly Required.

Read all instructions before use. This manual is part of the product

and must be saved for future reference.

VERSION CODE*:

1.0/0421/TG

* Model and Version numbers are needed

if replacement parts are requested

MODEL NUMBER*:

97851 -

Charcoal/Natural

Badger Basket®, PO Box 227, Edgar, WI 54426-0227 USA • Web: www.badgerbasket.com

U.S. Based Customer Service Toll-Free (Mon-Thurs 7:00 AM-4:00 PM CST): 1-800-236-1310

Phone: 715-352-2311 • Fax: 715-352-3163

FOR REPLACEMENT PARTS:

http://www.badgerbasket.com/parts

•Assembly Videos available on YouTube

•

ASSEMBLY TIPS! Review the entire manual before beginning. Leave hardware slightly loose

during assembly and then go back and tighten fully at the end. If using a power screwdriver,

keep torque setting low and go slow to prevent damage to the product.

BEFORE YOU BEGIN ASSEMBLY:

Check all parts and hardware. If anything is missing

or not satisfactory, please DO NOT call the store

or return the product to them. Please go online to:

http://www.badgerbasket.com/parts

Most problems are resolved

without you needing to leave home.

When emailing or calling us, please have this

instruction manual, your product model number,

and your Version Code ready.

Your Model Number is: 97851

Your Version Code is: 1.0/0421/TG

CARE INSTRUCTIONS:

Metal pieces can be wiped clean with a damp cloth and mild soap and dry thoroughly.

Periodically inspect the product to ensure all the parts remain tight.

WARNING

ADULT ASSEMBLY REQUIRED

DUE TO THE PRESENCE OF SMALL PARTS AND SHARP

POINTS DURING ASSEMBLY, KEEP OUT OF REACH OF

CHILDREN UNTIL ASSEMBLY IS COMPLETE.

READ ALL INSTRUCTIONS before use of this product.

Keep instructions for future use. Use only the parts and hardware

provided by Badger Basket®. Do not use the product if it is damaged, broken, or

missing parts. DO NOT allow anyone to climb, sit on, stand on, or play on or inside of this

product. It is not a seat, step stool, or ladder. Periodically check to make sure all the

hardware remains tight. No product is a replacement for adult supervision.

WARNING - FAILURE TO FOLLOW THESE

WARNINGS AND THE INSTRUCTIONS COULD

RESULT IN SERIOUS INJURY OR DEATH

C D

E F

G H

I×16 J K×2

L×2 M N

LEFT METAL SECTION RIGHT METAL SECTION

METAL MIDDLE SHELF METAL TOP

METAL BOTTOM METAL MIDDLE DIVIDER

METAL TOP DIVIDER METAL FRONT

BOLT

ALLEN WRENCH

6×25mm 6×30mm

TOOL REQUIRED

(NOT INCLUDED)

I×4

I×6

For Steps 1 – 3, we suggest leaving the bolts slightly loose. Bolts should be

tightened completely as noted in Step 4.

Open PART A – LEFT METAL SECTION and PART B – RIGHT METAL

SECTION and push together, slide in PART C – METAL

MIDDLE SHELF and fasten bolts

Set the unit onto PART D – METAL TOP and fasten bolts

I×6

Turn the unit over and set onto PART E – METAL BOTTOM and fasten bolts

Slide in PART G – METAL TOP DIVIDER and PART F – METAL MIDDLE DIVIDER

then tighten all bolts completely with PART J – ALLEN WRENCH

Slide in PART H – METAL FRONT

WALL
