LCD SCREEN

Using the Machine Setting Mode Key

Press to change the default machine settings (needle stop position, embroidery speed, opening

display, etc.). To display the different settings screens, press for “Sewing settings”, for

“General settings” or for “Embroidery settings”.

Sewing settings

aSelect whether to use the sewing speed controller to determine the zigzag width (see page 104).

bMake adjustments to character or decorative stitch patterns (see page 153).

cAdjust the presser foot height. (Select the height of the presser foot when the presser foot is raised.)

dAdjust the presser foot pressure. (The higher the number, the greater the pressure will be. Set the pressure at “3” for

normal sewing.)

eSelect whether “1-01 Straight stitch (Left)” or “1-03 Straight stitch (Middle)” is the utility stitch that is automatically

selected when the machine is turned on.

fChange the height of the presser foot when sewing is stopped when the pivot setting is selected (see page 72).

Adjust the presser foot to one of the three heights (3.2 mm, 5.0 mm and 7.5 mm).

gChange the height of the presser foot when the machine is set to free motion sewing mode (see page 105).

hWhen set to “ON”, the thickness of the fabric is automatically detected by an internal sensor while sewing. This

enables the fabric to be fed smoothly (see pages 64 and 73).

Memo

• Press or to display a different settings screen.

LCD SCREEN

Getting Ready

General settings

aSelect the needle stop position (the needle position when the machine is not operating) to be up or down. Select the

down position when using the pivot key.

bSelect the operation of the “Needle Position - Stitch Placement” button from the following two sequences (see page

74).

Each press of the “Needle Position - Stitch Placement” button:

“ON” – raises the needle, stops it at a nearly lowered position, then lowers it

“OFF” – raises the needle, then lowers it

cChange the brightness of the Needle Area and Work Area Lights.

dChange the speaker volume.

eChange the shape of the pointer when a USB mouse is used (see page 25).

fTurn both the upper and bobbin thread sensor “ON” or “OFF”. If it is turned “OFF”, the machine can be used without

thread.

gSelect the length of time until the screen saver appears. A setting between “OFF” (0) and “60” minutes can be set in

1-minute increments.

hChange the image of the screen saver (see page 25).

iSelect the initial screen that is displayed when the machine is turned on (see page 28).

jUse when running an application.

kChange the display language (see page 29).

lDisplay the total number of stitches sewn on this machine, which is a reminder to take your machine in for regular

servicing. (Contact your authorized retailer for details.)

mThe “No.” is the number for the embroidery and sewing machine.

nDisplay the program version. “Version 1” shows the program version of the LCD panel, “Version 2” shows the

program version of the machine.

CAUTION

• If “Upper and Bobbin Thread Sensor” is set to

“OFF”, remove the upper thread. If the

machine is used with the upper thread

threaded, the machine will not be able to

detect if the thread has become tangled.

Continuing to use the machine with tangled

thread may cause damage.

Memo

• The latest version of software is installed in your machine. Check with your local authorized Baby Lock

retailer or at “www.babylock.com” for available updates (see page 331).

LCD SCREEN

Embroidery settings

aSelect from among 14 embroidery frame displays (see page 230).

bChange the thread color display on the embroidery screen; thread number, color name (see page 229).

cWhen the thread number “#123” is selected, select from six thread brands (see page 229).

dAdjust the maximum embroidery speed setting (see page 229).

eAdjust the upper thread tension for embroidering (see page 225).

fSelect the height of the embroidery foot “W” during embroidering (see page 197).

gChange the display units (mm/inch).

hChange the initial mode of the display (embroidery/embroidery edit).

iChange the color of the background for the embroidery display area (see page 30).

jChange the color of the background for the thumbnail area (see page 30).

kAdjust the distance between the pattern and the basting stitching (see page 293).

lAdjust the distance between the appliqué pattern and the outline (see page 294).

2 - 3

Main parts

Basics of Disassembly

Basics

1 Removal of Top cover unit assy

1. Remove the top cover unit assy. 1.

→Refer to 3 - 3 "Disassembly of Top cover unit assy".

2 Removal of Accessory table assy

1. Remove the accessory table assy. 1.

→Refer to 3 - 4 "Disassembly of Accessory table assy".

3 Removal of Needle plate B assy

1. Remove the needle plate cover 1from the needle plate B assy. 2.

2. Remove the needle plate B assy. 2.

→Refer to 3 - 4 "Disassembly of Needle plate B assy".

4 Removal of Free arm cover

1. Remove the screw 1, and then remove the free arm cover 1.

2 - 4

Main parts

Basics of Disassembly

5 Removal of Free arm front cover assy

1. Remove the screw 1and the screw 2.

2. Remove the hook 1and the 2 hooks 2, and then remove the free arm

front cover assy. 3.

→Refer to 3 - 5 "Disassembly of Free arm front cover assy".

6 Removal of Base plate cover

1. Remove the 2 screws 1.

2. Remove the 4 hooks 1, and then remove the base plate cover 2.

2 - 5

Main parts

Basics of Disassembly

Basics

7 Removal of Face plate assy

1. Remove the face plate screw cap 1.

*Key point

• Remove the face plate screw cap 1by using the pin or etc.

2. Open the face plate connector cover 2.

3. Remove the 2 screws 1, and then remove the face plate assy. 3.

→Refer to 3 - 6 "Disassembly of Face plate assy".

8 Removal of Front thread guard cover

1. Remove the screw cap 1.

*Key point

• Remove the screw cap 1by using the pin or etc.

2. Remove the screw 1, and then remove the front thread guard cover 2.

2 - 6

Basics of Disassembly

Main parts

9 Removal of Belt cover

1. Remove the upper cover cap 1.

*Key point

• Remove it while inserting flat-blade screwdriver. in the position

of the right figure.

2. Remove the 2 screws 1, and then remove the belt cover 2.

*Key point

• Remove the hooks (7 locations) from the front cover assy., the

rear cover assy. and the connector cover 3.

→Refer to 3 - 7 "Disassembly of Belt cover".

2 - 7

Main parts

Basics of Disassembly

Basics

10 Removal of Bobbin winder (upper cover assy)

1. Remove the connector 1from the main PCB assy..

2. Remove the 3 screw caps 2from the bobbin winder (upper cover assy.)

*Key point

• Remove the screw cap 2by using the pin or etc.

3. Remove the 6 screws 1, and then remove the bobbin winder (upper cover

assy.) 3.

→Refer to 3 - 22 "Bobbin winder unit".

11 Removal of Ground plate B

1. Remove the screw 1and the screw 2, and then remove the ground plate

B 1.
