baby express be free Manuel utilisateur
User's Guide
be free Wearable Breast Pump
Please read this user's guide carefully before using
Pump motor
Silicone Flange x2
(24mm and 27mm)
Diaphragm
Connector
Silicone valve x2
Bra Extender
USB Cable
Collection Cup
Description of Package Contents
Please check the quantity of the content before use. If there is any missing part, please contact the seller
Free silicone ring (under motor) x2
Note : Pump motor is not water proof. Do not wash with water or have it come in contact with any liquid.
Power indication
Power button
Mode change
Suction Level indicator
Suction reduce button
Suction increase button
Power button : Press to on / off
Power indication : Green light indicates power on, when plugged in, battery fully charged
Mode change : Blinking 'suction level indicator'; stimulation mode. Non-blinking 'suction level
indicator'; expression mode
Suction increase/reduce button : increase/reduce suction level (total 5 levels)
Red light indicates low battery (left about 20mins pump time)
Note
The appliance will turn off automatically after 20mins of operation
The appliance comes with a memory mode and will start from last used mode/suction level
Full charge takes about 2.5 hours. Avoid over charging.
Power adaptor excluded. Compatible with Output 5V 1A .
Operation Panel
Charging port
(Micro USB)
Assembly Sequence
Put the diaphragm on top of the connector.
Insert the silicone valve at the bottom of the connector.
Take note of the direction inserted.
Hold the top of the connector, align the ears on the
connector with the collection cup then fit it in.
Tip: inserting it upside down is easier.
Fit the silicone flange onto the collection cup and ensure it
is properly sealed.
Sit the pump motor onto the collection cup.
Put the assembled pump firmly onto your
breast. Ensure that the nipple is aligned in the
centre. Keep the pump upright at all times.
Tip: Pump has a memory function. It will enter
the last working mode when turned on.
Use the bra extender with your nursing bra to
fit the pump. Ensure that the pump sits firmly
on your breast.
Tip: Use the bra extender to prevent
damaging your bra by over stretching it.
Wearing the pump
Note
Please avoid over pumping to avoid breast injuries. Please seek medical advice if breast becomes
painful because of using the breast pump.
To have a smooth milk pumping session, please set the suction level according to your personal
preference.
Please off the power before stopping use.
All function of this product are described in the user's guide.
Always check the breast pumps and components for wear and damager before use. Replace if
necessary.
Breast pump parts are recommended to be washed and sterilised before and after every use.
Do not use this product for other intentions not indicated in this guide.
Cleaning and milk storage
Note
Ensure the opening on the silicone flange is
aligned on top to prevent leaking.
To pour out pumped milk, remove motor to
reveal top opening and pour.
Tip: do not attempt to dismantle the pump or
open the flange to pour out the milk
Before use, please clean and sterilise the accessories. After use, clean the accessories as well, and
keep them dry. Please note that motor and power adapter cannot be washed or sterilised.
When cleaning the silicone parts, please be gentle. If damaged, it will affect the suction.
Take apart accessories when cleaning and sterilising. Allow accessories to cool for 20 mins before
assembling to avoid damage.
All of BE Free pump parts can be steamed, boiled and UV steriilised. Unless otherwise indicated.
Pump motor, especially the bottom, should be wiped with damp cloth regularly.
