B-Tech Mountlogic BT10 Manuel utilisateur
BT10
HI-LOGIC PLUS™SPEAKER FLOOR STANDS
INSTALLATION GUIDE & PARTS LIST
This Pack Contains 2 Speaker Stands
B-TECH AUDIO VIDEO MOUNTS
www.btechavmounts.com
CONTENTS
INSTALLATION TOOLS REQUIRED
FEATURES
Crosshead
screwdriver
Installation Safety Notes.....................................................................................................................2
Parts List.............................................................................................................................................4
Installation Instructions.......................................................................................................................6
Product Dimensions..........................................................................................................................11
B-Tech Contact Details.....................................................................................................................12
PLEASE KEEP THIS FOR FUTURE REFERENCE
4mm Hex Key
(Supplied)
REG DESIGN NO: 3003354
●Designed for home cinema speakers up to 10kg (22lbs)
●Die-cast base for greater stability, esoteric performance
and to curb unwanted vibration
●Adjustment height: 660mm (26”) – 1200mm (47.2”)
●Suitable for speakers with single point, dual point
and keyhole fixings
●Alternative speaker clamp supplied for speakers
without fixing holes
●Comprehensive mounting kit included
●Integrated cable management with
speaker cable pull-through wire
●Simple assembly and speaker mounting
●This pack contains 2 floor stands
BT10
PARTS LIST
4
Suitable for loads
up to
10kg (22lbs)
TUBE ASSEMBLY
1
2
3
45
6
7
8
9
CLAMP ASSEMBLY 10
5
PLEASE KEEP THIS FOR FUTURE REFERENCE
14
12
ABC
D E
11
13
REF PART NAME QTY
1 TUBE ASSEMBLY 2
2 HEIGHT ADJUSTMENT COLLAR 2
3 FLOOR BASE 2
4 M22 NUT 2
5 RUBBER FEET 6
6 M6 X 25mm HEX SCREW 2
7 CLAMP BRACKET 2
8 SPEAKER CLAMP 4
9 M6 x 60mm SCREW 4
10 FOAM PAD 4
11 DUAL POINT SPEAKER FIXING 2
12 SINGLE POINT SPEAKER FIXING 2
13 SPEAKER CABLE PULL-THROUGH WIRE 1
14 4mm HEX KEY (FOR PART 6) 1
INTERFACE KIT
A M5 X 12mm SCREW 4
B M6 X 12mm SCREW 4
C ¼” X ½” UNC SCREW 4
D ¼” X ½” UNC SCREW (FOR PART E) 2
E THUMB WHEEL (FOR PART D) 2
6
INSTALLATION INSTRUCTIONS
1Attach tube to the floor base.
2
3
4
1
3
4
1
7
2Stick the rubber feet to the bottom of the floor base.
3
5
5
3
8
3i. Feed the pull-through wire through the hole at the top of the tube down
to the floor base.
ii. Attach the speaker cable to the top of the pull-through wire, then pull the
cable all the way through the tube.
13
SPEAKER
CABLE
SPEAKER
CABLE
1
3
13
13
9
4Choose an adaptor for the speaker.
Speaker Clamp
Horizontal dual point fixing
Vertical dual point fixing
11
6
6
11
611
1
614
14
14
C
B
A
C
B
A
A
B
C
14
6
1
12
12
6
Single point fixing
D
E
14
6
1
11
6
11
Keyhole fixing
10
8
7
1
11
6
6
8
1
7
10
5Loosen the height adjustment collar, adjust height then retighten.
2
11
BT10
PRODUCT DIMENSIONS
THESE INSTRUCTIONS ARE INTENDED AS A GUIDE ONLY AND B-TECH ACCEPTS NO
LIABILITY FOR THE ACCURACY OF THE INFORMATION CONTAINED IN THIS DOCUMENT.
68mm
2.7"
FLOOR BASE DUAL ADAPTOR
56mm
2.2"
20mm
0.8"
26mm
1"
O6.5mm
0.3"
SINGLE ADAPTOR
ADJUSTABLE CLAMP
10mm
0.4" 12mm
0.5"
1200mm
47.2"MAX
660mm
26"MIN
O18mm
(0.7")
O23mm
(0.9")
90mm
3.5"
165mm
6.5"MAX
90mm
3.5"MIN
O8mm
0.3"
290mm
11.4"
300mm
11.8"
86mm
3.4"
