O’Dive sensor

Complete instruction manual

Updated on 09/07/2020

Download of the O’Dive ONE or O’Dive TEK app is required

https://www.o-dive.com

O’Dive instruction manual Updated on 09/07/2020

WARNING

O’Dive (ONE or TEK) is a connected acoustic sensor that allows the measure of the

decompression adequacy to the diver’s practice.

The features of the service imply practicing diving in a club or individually. O'Dive is not a

medical device and does not provide medical advice.

Any advice or other items available in our service are intended solely for general information

purposes. They are not intended to serve as a reference or to substitute professional medical

advice based on the personal situation of the user.

Azoth Systems disclaims any responsibility for actions taken by the user because of advice and

information provided by the service. In particular, if the user has not consulted a medical

doctor and does not have a medical certificate authorizing him to practice diving.

Direction of use

For a given set of dive parameters (depth, duration and decompression stops), it is recognized

by the scientific community that a decompression procedure resulting in no or a few

microbubbles is renowned safe.

The O'Dive solution assists the diver to help him adapt and improve his practice, limiting his

bubble level, and therefore increasing his diving safety level.

The sensor measures the microbubble rate in the diver venous system following a dive.

Combined to the diving parameters, these measurements allow the calculation of the quality

of the decompression procedure used.

If the procedure is not optimal, the O'Dive app put at the diver's disposal a simulator allowing

him to visualize the effects of several actions to improve the quality of his procedure while

making progress in his practice.

By using regularly O’Dive technology, the diver will improve his self-understanding. He will

therefore be more likely to wisely adjust his decompression procedures and diving practice.

Decompression sickness (DCS) are intrinsically related to the dissolved gas charge in the

diver's body. The O'Dive solution is designed to help the diver advance his practice by better

understanding the effects of decompression. It does not claim in any case, even when the

quality index is 100%, that no risk of DCS is incurred by the diver. Zero risk does not exist.

The only way to avoid exposure to DCS is not to dive.

O’Dive instruction manual Updated on 09/07/2020
3

Table of contents

WARNING ...................................................................................................................................2
Direction of use ..........................................................................................................................2
O’DIVE Perimeter and usage restriction ....................................................................................3
O’Dive ONE.............................................................................................................................3
O’Dive TEK ..............................................................................................................................4
O’Dive ONE & TEK ..................................................................................................................4
Step-by-step guide for using O’Dive...........................................................................................5
Step 1 –Charging the sensor..................................................................................................5
Step 2 –Downloading the O’Dive app ...................................................................................5
Step 3 –Taking in hand the sensor ........................................................................................6
Step 6 –Validating and synchronizing measurements ..........................................................9
Step 7 –Evaluating your procedures .....................................................................................9
Support - Contact .....................................................................................................................10
Legal Notice..............................................................................................................................10

O’DIVE Perimeter and usage restriction

O’Dive ONE

O’Dive ONE allows for analyses of open-circuit dives with Air or Nitrox as bottom gas, with or
without use of oxygen enriched mixtures for decompression stops.
Multi-level dives can be handled, as long as the maximum depth is below 60m. The algorithm
will consider an equivalent square profile, based on the parameters input by the diver in the
app: maximum depth, total duration and actual decompression duration provided by the dive

O’Dive instruction manual Updated on 09/07/2020

computer. The additional stops eventually performed by the diver are taken into

consideration to evaluate their benefit on the exposure severity.

Repetitive and multiple dives - i.e. with a surface interval below 12 hours –can be analysed

(for example: cruise with several dive per day). The residual gas load is considered as long as

the diver is using the same computer for all his dives.

Sawtooth profiles and inadequate ascending speed cannot be detected with the manual

input mode offered by O’Dive One. Therefore, the results provided to the diver do not

consider these additional risk factors.

O’Dive TEK

O’Dive TEK allows for analyses of open-circuit and closed-circuit with Air or Trimix as bottom

gas, with or without use of oxygen enriched mixtures for decompression stops.

In any case, the nature of gases breathed at the bottom (diluent for CCR and bottom mix for

OCR) or during the stops (PpO2 for CCR and gas switch for OCR) as well as the computer GF

settings (GFLow/GFHigh) must be input in the app.

Incorrectly input fields can lead to results that don’t reflect the actual quality of the

decompression.

Repetitive dives - i.e. with a surface interval below 12 hours –cannot be analysed.

Sawtooth profiles cannot be detected. Therefore, the results provided to the diver do not

consider this additional risk factor.

Inadequate ascending speed are however taken into consideration in the results provided to

the diver, whether they are manually input or deducted from the analysis of the computer

data.

O’Dive ONE & TEK

Two parameters input modes are available:

•Manual input: it is only to be used for square profiles or equated to square –i.e.

profiles whose bottom depth change amplitude is low compared to the maximum

depth reached (+/-5m), for example a wreck dive; the diver has to input all the fields

required to characterized the exposure severity, among which the descending speed,

the ascending speed to the first stop and the stops durations.

•Import mode: it allows a finer analysis of the actual profile based on the data stored

on the dive computer ; the multi-level dives are handled as long as the maximum

depth is below 120m (60m for O’Dive ONE); the additional stops eventually

performed by the diver are taken into consideration to evaluate their benefit on the

exposure severity.

It is now possible to read the dive profile from the dive sheet.

O’Dive instruction manual Updated on 09/07/2020

Step-by-step guide for using O’Dive

Step 1 –Charging the sensor

Before each use of the sensor, it is important to charge it in order to have the necessary

autonomy to the realization of your measurements.

IMPORTANT: It is strongly advised to make sure that the sensor is properly charging before

leaving it on its charging base, in order to avoid discharging and deterioration of the battery.

• Connect the induction charger to the provided 220V-60Hz adapter or to a USB port.

• Position the sensor on the charger, face with markings in contact with the induction charger.

When the sensor is in the right position, the sensor LED will flash in green, indicating that the

sensor is charging. If the battery is full enough, the LED will flash rapidly 5 times, then slowly

2 times, and will stop.

• If the sensor LED does not flash in green, adjust the sensor position on the charger.

• If the sensor LED is flashing in red, remove the sensor from the charging base, then put it

back and adjust the sensor position on the charger.

• If the sensor starts (vibration + blue flashing), remove the sensor from the charging base and

turn it off, then put it back and adjust its position on the charging base.

• At the end of the charge (maximum duration of 6 hours), the LED will stop. Your sensor is

then ready to be used.

Step 2 –Downloading the O’Dive app

The sensor is operating with the O’Dive ONE & O’Dive TEK apps, available on the Apple Store

and on Google Play.

Once the app is installed, you can use your sensor.

O’Dive instruction manual Updated on 09/07/2020

Step 3 –Taking in hand the sensor

Starting the sensor

To start the sensor, press for 1 second the button located

on its top. The sensor vibrates and the LED will flash

rapidly in blue (1 flash per second for 90 seconds) signaling

the possibility of pairing a phone.

A red flashing LED indicates a low battery level. In this

case, the sensor has to be charged as soon as possible.

(see step 1).

Turning the sensor off

There are 3 ways you can turn off your sensor:

- Press the on/off button

for 3 seconds (the flashing

LED stops and the sensor

vibrates)

- Disable the WIFI

connection on your

smartphone

- Place the sensor on the

induction charging station

(see step 1)

Technical Characteristics

Weight

Less than 0,5kg

Sensor dimensions (L x W x H)

78,8 x 73,5 x 34,6 mm

Doppler frequency

2MHz

Endurance

3H continuous wave

Battery

LiPo (Lithium Polymère) rechargeable

Battery power

7,4V –600mAh

Recharge

Induction –2A

Wireless connection

Wi-Fi

Operation temperature range

0°C –40°C

Storage temperature range

-35°C –65°C

Humidity

35% - 85% RH

Conformity

The sensor can be cleaned with a damp cloth after use.

button

+ LED

O’Dive instruction manual Updated on 09/07/2020

Step 4 –Registering / Logging in

-Before using the sensor, you need to create an account on the app.

-Open the app and click on the button Register. If someone is already logged in, click

on the name on the top right corner of the home page to join the section ‘My account’

and click on the button Register.

-Follow the steps.

-If you want to import your dives’ profiles from Subsurface, fill in your Subsurface

email address and password.

-In case you always use the same sensor, fill the field ‘Sensor number’ (you can scan the

QR code on the tag, type the number with the keyboard, or select the sensor Wi-Fi -

on Android only).

-Do not forget to accept the Terms of Use (TOU).

If you already have an account, go to Log in and fill in your email address and password.

Step 5 –Taking measurements

Measurements must be undertaken after diving, when the rate of gas microbubbles in the

blood is potentially the highest.

Four measurements (each 20 seconds long) will be carried out:

•30 minutes following the dive*: one under the left clavicle then one under the right clavicle;

• 60 minutes after the dive:one under the left clavicle then one under the right clavicle.

*For dives with a helium fraction higher as the nitrogen one, we recommend to perform the

first series of measurements as soon as possible after surfacing, without, however, making

additional efforts due to precipitation.

IMPORTANT: It is strongly advised to watch the tutorial on the app to fully understand how

to position the sensor. An incorrect sensor positioning under the clavicle will result in bad

measurements and, therefore, an impossibility to analyze the signals. Please practice

positioning of the sensor in front of a mirror before making measurements after your dives.

O’Dive instruction manual Updated on 09/07/2020

Before any measurement, make sure that your name is displayed on the top right corner of

the screen. If it is not the case, click on the other name to join the section ‘My account’ and

-Select New measurement: the app creates a new dive and requests you to start your

sensor.

-Check that the proposed sensor number is matching your device. If not, click on

Change sensor, fill the sensor number (see step 4) and validate. Start the measurement

again by clicking New measurement then Use current dive.

-When the sensor number is correct, start your sensor (see step 3), then click Connect

on the app. The sensor will now pair with your smartphone via Wi-Fi. Important: data

sharing via Wi-Fi needs to be deactivated.

-When the pairing is done, the LED starts flashing in green, the Start button becomes

accessible, and the battery pictogram on the top right corner of the screen gets

activated.

-Follow the app’s steps to perform the two measurements.

-Before starting the recording, a screen allows you to check the correct positioning of

the sensor using a spectrogram.

Recommendations:

- The visual objective is to obtain a periodic yellow-red signal whose height and

length will be as large as possible.

- To confirm the positioning, stand still for a few seconds and breathe deeply.

- Apply moderate pressure so as not to "chase" the gel off the sides of the sensor.

Correct positioning:

Excellent positioning:

Incorrect positioning:

-When you have found the correct positioning, press Start to launch the measurement.

From this point on:

oDo not try to "improve" the signal by moving the sensor.

oBreathe very deeply without forcing, following the sinusoid.

oDo not make any arm or shoulder movements and do not cause muscle

contraction.

O’Dive instruction manual Updated on 09/07/2020

-If the measurement is unsatisfactory, the application will prompt you to repeat the

measurement. Make sure that the sensor is correctly positioned and that you follow

the instructions given (no talking, relaxed arm, forced breathing).

-At the end of a series of two measurements (left then right), the sensor switches off

automatically.

-To perform the second series of measurements (30 minutes after the first one), select

New measurement, press Use current dive so that all measurements are related to the

same dive.

Step 6 –Validating and synchronizing measurements

Once the measurements are done, you must input your dive parameters and synchronize your

data with Azoth Systems’ server to get your results.

Note: synchronization of the data requires a connection to a Wi-Fi or a 4G network.

Input your dive parameters

-Go to My results. Select your dive under the ‘Pending’ tab. You can then either import

the dive profile or do a manual input.

For importing the profile, click on Import data then Import from a dive computer

(works only with Shearwater), Import from Suunto cloud or Import from Subsurface

cloud and select the corresponding dive. Then, fill in the fields left in blank and validate.

For a manual input*, input your dive parameters and validate.

*Reminder: Manual input of the dive parameters is reserved for square dives (see

O’DIVE Perimeter and usage restriction). Only the O'Dive ONE sensor can process

multilevel dives using an equivalent square profile approach for Air/Nitrox mixes.

Synchronize your data on the server

-Once your parameters are input, go to the section My results and click on Synchronize

on the top right corner of the screen. The dive and the related measurements are sent

to our server to be analyzed and are now listed under the ‘Dives’ tab.

-In case there are still some dives under the ‘Pending’ tab with the pictogram ⓘ, you

must input the dive parameters and synchronize one more time.

Step 7 –Evaluating your procedures

A few minutes after the dive, you will receive an email notification indicating that your dive

has been analyzed. This recommendation is presented as a graph evaluating the level of

adequacy of your decompression procedure to your diving practice.

-Go to the section My results and click on Synchronize. You will be able to see on the

graph if your decompression procedure is optimal, perfectible or to be changed.

O’Dive instruction manual Updated on 09/07/2020

-A simulation tool is available to help you see the potential benefits of several factors

on the quality of your decompression procedure. To use this tool, select the dive that

you want to simulate and change one or several of the proposed factors to improve

your procedure quality.

Support - Contact

We are looking forward to hearing from you regarding the quality, functionalities or use of

this product.

We are committed to reply to you without delay:

[email protected]

Legal Notice

This product and its battery pack cannot be discarded in the domestic

waste. They require separate collection. Ensure that you dispose of your

O’Dive electronic product and batteries in a sensible and considerate

manner, at a collective recycling point. This valorization of your electrical

waste contributes to protect the environment and your health.

Autres manuels pour O'Dive

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Azoth Systems Instrument de plongée

Azoth Systems

Azoth Systems O'Dive ODYSSEY Manuel utilisateur

Manuels Instrument de plongée populaires d'autres marques

Sherwood

Sherwood Amphos Manuel utilisateur

Zeagle

Zeagle N2ition Manuel utilisateur

Tusa

Tusa Q 1203 CE Mode d’emploi

Sherwood Scuba

Sherwood Scuba Insight Instructions de montage

SUBMERSIBLE SYSTEMS

SUBMERSIBLE SYSTEMS Spare Air 600 Manuel utilisateur

OCEANS

OCEANS S1 Supersonic Manuel utilisateur

heinrichs weikamp

heinrichs weikamp OSTC 2 Manuel utilisateur

Omer

Omer SP2 Manuel utilisateur

Scott

Scott PRO-PAK Manuel utilisateur

Apeks

Apeks BLACK SAPPHIRE Manuel utilisateur

Waterproof

Waterproof DRYSUIT Manuel utilisateur

Dräger

Dräger PAS AirPack 1 Manuel utilisateur

Dive Lab

Dive Lab KIRBY MORGAN KMB 18 Manuel utilisateur

Ratio Computers

Ratio Computers iDive Manuel utilisateur

Oceanic

Oceanic PROPLUS X Manuel utilisateur

CFA

CFA MSA G1 Manuel utilisateur

Genesis

Genesis Centauri Manuel utilisateur

TREND

TREND GAUGE/60 Manuel utilisateur
