Ayra Flash 30 LED Manuel utilisateur

Flash 30 LED / Flash 60 LED

LED stroboscope

User manual

The information in this user manual is subject to change at any time without notice.

Version: 1.0 Date of creation and author's initials:02-02-2017 RV Revision date and author's initials: -

Introduction

Thank you for purchasing the Flash 30 or Flash 60 LED. This powerful armature is equipped with strong

bright white 5050 SMD LEDs that yield an enormous amount of light. This device is designed to generate

flashing pulses of light but can also be used statically thanks to advanced technology.

We advise that you read this user manual in its entirety before unpacking the contents of the box so that you

are familiar with all of the functionality that this product has to offer. Please be sure to check that all of the

parts and accessories listed below under 'Box contents' are included in the package. In the event that the

Flash 30 / 60 LED does not function properly or if you have any issues while operating it please remove the

plug from the power socket and contact your dealer for assistance.

Box contents:

- Ayra Flash 30 LED or Flash 60 LED stroboscope

- connection cable from IEC C13 to Schuko 1.5 mm²

- connection cable from IEC C13 to UK plug 1.5 mm²

Please inspect the de ice and the included accessories.

Should you discover that either the device or one or more of the included parts have been damaged or

rendered defective while in transit please contact your dealer directly.

Please note that the pictures in this user manual serve illustrative purposes only and may differ from the

actual product.

The information in this user manual is subject to change at any time without notice.

Version: 1.0 Date of creation and author's initials:02-02-2017 RV Revision date and author's initials: -

Safety instructions

Everyone involved with the installation operation and maintenance of this device must:

- Be qualified

- Be skilled

- Have read the instructions in this user manual

- Be sure that neither the device nor the included accessories are damaged. Should the device or the

included accessories be damaged please contact your dealer for more information.

- Ensure that the device is in good working condition and is safe to operate. Please follow the advice and

instructions as they are described in this user manual.

Damage caused by misuse and/or modifications made to the device are not covered by the warranty.

This device does not contain any parts that can be repaired or replaced by the user. Should maintenance or

repairs be necessary they must be handled by a qualified technician.

The light source of this device is not replaceable. If the light source no longer functions the entire device

needs to be replaced.

Important information regarding safety and health:

- Do not remove any labels or stickers from this device.

- Do not leave any cables lying around.

- The device should not be opened up and any hardware or software that may be present should not be

modified.

- To achieve optimal performance inputs on this device should not be fed with a signal higher than

necessary.

- The device should only be used indoors; contact with water rain and moisture should always be avoided.

Do not place any objects containing liquid on top of the device.

- Remove the device from any nearby flames or heat sources; do not place it near flammable fluids gasses

or objects.

- Disconnect this device from a power source if it will not be used for a longer period of time if maintenance

The information in this user manual is subject to change at any time without notice.

Version: 1.0 Date of creation and author's initials:02-02-2017 RV Revision date and author's initials: -

WARNING!

Keep this de ice away from moisture, water and rain to a oid the chance of electric shocks.

WARNING!

Only connect this de ice to a suitable power socket. This de ice functions on a specific power

oltage. If it is plugged into a power socket with a different oltage, it could result in permanent

damage and e en dangerous situations such as fire or electric shocks.

WARNING!

Be careful when operating this de ice. Touching the wires that are connected to the mains,

inside or outside the de ice, could result in electric shocks.

is necessary or if it needs to be cleaned.

- Do not pull on the cable to remove a connector as it can cause damage.

- Do not use any cables other than the ones described in this manual. Do not use defective cables. Please

contact your dealer if the included or necessary cables do not function properly with this device.

- Only use this device with a stable AC power supply.

- Only use this device with power form a grounded power source.

- In the event that the device is exposed to extreme temperature changes (e.g. transported through a cold

outside environment into a warm indoor environment) it should not be turned on until it has reached room

temperature. This is necessary to prevent moisture from forming in the device which could lead to electric

shocks.

Guidelines and operation of this de ice:

- This device is intended for use by professionals on stage in theatres in clubs and in similar entertainment

locations.

- This device is not suitable for use by children and should always be operated by an adult.

- This device is designed to create light effects for entertainment purposes. It is not suitable for household

illumination.

- This device may only be used in a suitable environment where no damage to the device can occur. Do not

use the device in moist or dusty environments such as:

- indoor swimming pools where chlorine is used

- beaches where there is sand and salt

- outdoors

- indoors in spaces where intense heat sources are present or where it reaches temperature levels

that would be considered uncomfortable for a person

- Avoid impact and collisions during use and transport. Do not transport the device while it is in use. Avoid

using excessive force when installing and operating the device.

- The user should become familiar with the functions of this device before using it.

- Should the device not be used in the manner described in this user manual damages or even injuries could

occur. Ayra cannot be held responsible for any injuries or damages that occur as a result of improper use of

this product.

Storage and transport:

- This product was designed for mobile use. Please only transport the device in the original packaging or in

a flight case with a suitable foam inlay.

- This device was not designed for permanent (24/7) use. The expected lifespan of the device will not be

affected by occasionally turning the device off. Disconnect the device or turn off the power when it is not

actively in use.

- If the device will not be used for a longer period of time it should be disconnected and stored in a dust-free

environment.

- Do not expose the device to extreme temperature differences.

Housing

- Inspect the device's housing frequently and always just before use. Avoid operating the device if there are

large dents or cracks or if screws are missing. Do not use the device if the housing is not in good condition.

Contact your dealer or a qualified technician if you are unsure about the state of the device.

- Check the device and the screws for corrosion. Corrosion must not be present on this device. Contact your

dealer or a qualified technician if you find any corrosion on the screws.

Every power and signal connector should be securely mounted. Do not use the device if the connectors are

not secure.

- Avoid dust and dirt build-up. Clean the device once a month by disconnecting it from the power supply and

wiping it down with a dry or slightly moist cloth. If the device is used frequently the cleaning intervals should

increase.

The information in this user manual is subject to change at any time without notice.

Version: 1.0 Date of creation and author's initials:02-02-2017 RV Revision date and author's initials: -

Symbol explanation:

WEEE: Ensure that this device is disposed of properly. This product falls under the WEEE

(Waste Electrical and Electronic Equipment) directive. The requirements of this directive apply

to all manufacturers and producers of electronic devices in the EU. Do not throw this product

away with regular rubbish. Please contact your local authority for more information about how

to recycle and dispose of these products in your region. By recycling this product in the proper

manner we can work together to ensure that we can continue to enjoy these kinds of

products and still protect the environment as much as possible from pollution.

CE: The CE logo indicates that this product meets the European norms and requirements to

which it must legally conform.

Only suitable for indoor use: this product was only designed for indoor use. The maximum

environmental temperature must not exceed 40 degrees Celsius (104 degrees Fahrenheit).

Contact:

Ayra professional lighting products

Verrijn Stuartweg 18

4462 GE Goes

The Netherlands

Please do not send any products to this correspondence address.

Should you wish to send in a product for repairs or for a refund, please contact your dealer for an RMA

re uest (Return Merchandise Authorisation).

The information in this user manual is subject to change at any time without notice.

Version: 1.0 Date of creation and author's initials:02-02-2017 RV Revision date and author's initials: -

Guidelines and operation of this de ice

1. light output with transparent protective cover

2. tightening knob mounting bracket

3. LED display with menu buttons

4. microphone for sound-controlled operation modes

5. 3-pin XLR DMX input

6. 3-pin XLR DMX output

7. power output for linking multiple armatures (IEC C13)

8. power input with built-in fuse holder (IEC C14)

9. safety eyelet for optional safety cable

10. mounting bracket

11. ventilation slots

Please note: The image on this user manual shows the Flash 60 LED stroboscope. The Flash 30 LED has

the same connections and functions but they are partly located in a different place.

The information in this user manual is subject to change at any time without notice.

Version: 1.0 Date of creation and author's initials:02-02-2017 RV Revision date and author's initials: -

567 8 9

11 11

Operation and mounting

To activate the device plug it into a mains socket. Once it's connected to an active power source it will turn

on automatically.

During calibration ‘AYRA’ will be shown on the display which means the device is not ready to be operated.

Once the device has fully started up it will jump to the last-used mode. Operation modes and other settings

shown on the display can now be adjusted or changed by means of the menu buttons.

Should the device detect a DMX signal it will automatically switch to DMX mode and will display the last-

used address. For new devices this will normally be DMX address 001. Of course you can change the DMX

address via the display using the menu buttons.

Using the display and the menu buttons you can adjust the functions and settings of the device. Press

'Enter' to confirm an adjustment or select a function use ‘Up’ and ‘Down’ to change amounts and ‘Menu’ to

go back to the menu. By holding the ‘Menu’ button down for 2 seconds after saving a specific setting the

device will return to operation mode and adopt the setting. This will also be done after any changes in the

operation mode or DMX address. This operation is not always necessary considering the device

automatically does this after a new setting is confirmed.

The menu contains the following options and functions

display Mode Function

ADDR / A001 DMX address configuration Address A001 … A512

SLAV Slave mode SLAV

F-.00 Standalone stroboscope mode Stroboscope speed: F-.00 – F-.99

F-.00 = static mode

D-.00 Standalone dimmer mode Dimmer level: D-.00 – D-.99

D-.00 = dimmer 0%

SU00 Sound-controlled mode +

sensitivity

Adjustable sensitivity: SU00 - SU99

You'll find an explanation of the various functions below:

ADDR: With this function you can determine the DMX start address of the device. Set it channel 001 and

the device will respond from DMX channel 1. Set it to channel 003 then the device will respond from DMX

channel 3 etc.

SLAV: The master-slave mode is designed to sync multiple devices. A copy of the internal program is sent to

the daisy-chained devices so that each one projects the same effect. The master-slave function works by

means of standard 3-pole XLR cables. The only difference is that the first device in the chain does not

receive DMX input.

F-.00: This function allows you to set the speed of the stroboscope while the device is in standalone mode. It

ranges from 00 to 99 where 00 is static (full-on) mode and 01 to 99 are the increasing flash speeds.

D-.00: This function is to set the intensity of the dimmer while the device is in standalone automatic mode. It

can be combined with the stroboscope speed which ranges from 00 to 99 00 being completely off.

SU00: This mode allows you to determine the sensitivity of the internal microphone. The further the device is

from the speaker the higher the sensitivity of the microphone needs to be so it can react properly to the

music. The microphone is built to handle high sound pressure levels but the louder the signal the higher the

microphone sensitivity level the more difficulty the device will have detecting the beat of the music.

Experiment with the level of sensitivity and distance/positioning of the device to find the best results.

In sound-controlled mode the Flash 30 / 60 LED will flash three times in a row at full output at every trigger

(on the beat).

The information in this user manual is subject to change at any time without notice.

Version: 1.0 Date of creation and author's initials:02-02-2017 RV Revision date and author's initials: -

Operating modes

The following overview is designed to show the differences between the various operation modes that are

supported by the above-mentioned menu functions.

Auto:

In automatic mode (D-.00 and F-.00)the device is set to a fixed speed and will function according to the

preset parameters. The device does not requite input from the built-in microphone master-slave signals or

DMX.

By setting the flashing speed to static (value 00) you can also use the Flash 30 / 60 LED as a static projector

to temporarily light up certain surfaces.

Sound:

The sound-controlled mode uses an internal microphone which detects the music and flashes three times at

full intensity on the beat. This ensures the light effect syncs perfectly with your music.

When no music is detected due to a break in the music or the presence of only high tones the device will not

flash.

Sla e

In Slave mode you can daisy-chain multiple devices of the same type so they all function a specific way.

This way you can coordinate your light show by having multiple separate devices moving the same way

instead of all different directions which can be chaotic. Basically you can connect an unlimited number of

slave devices to a master device but a DMX booster is required in between. Generally speaking you can

connect up to four armatures together without the need for a DMX booster.

Be aware that when you attempt to connect devices of different types and brands they may behave

strangely and you may not get the desired effect because certain functions are linked to the wrong channels.

This is true of DMX lighting of all brands and types.

In case of the FLASH 30 / 60 LED mixing these units in master or slave mode is possible as they share the

same channel values and controls.

DMX

The DMX mode is the most comprehensive way to maintain ultimate control over all the functions this device

has to offer. It enables you to determine exactly how many functions you want to control via the DMX

controller or DMX software.

2CH mode:

CH Function Values

CH1 Dimmer: 0 - 100% 000-255: 0-100%

CH2 Stroboscope speed slow – fast + sound-controlled option 000-007: Stroboscope blackout

008-247: Stroboscope mode slow - fast

248-255: Sound-controlled mode

Power supply

The Flash 30 / 60 LED is equipped with a power input to supply the device with power but also an output to

supply power to other devices which means you won't need power strips or other power distributors.

The power connectors for the Flash 30 / 60 LED have a power capacity of 10A subtracted by the maximum

power consumption of the device. With a small built-in safety margin the output on the Flash 30 / 60 LED

should be fed with a maximum of 9 A.

This is more than enough to supply power to multiple devices of the same type via a single power line.

The information in this user manual is subject to change at any time without notice.

Version: 1.0 Date of creation and author's initials:02-02-2017 RV Revision date and author's initials: -

Bear in mind that the installed fuse in the Flash 30 / 60 LED is designed to only protect the device itself. The

power output is not protected.

Installation and connection requirements

Now that you know how the Flash 30 / 60 LED works it's important to know how to use it correctly and

safely according to the installation and connection requirements.

Make sure the device and connection cables are out of reach of children and that if children are present

they are under adult supervision at all times. Because this device can be used upright or suspended children

could pull on the cables causing the device to fall on top of them. To avoid injury it is important to pay close

attention to the position and/or installation of this device.

Upright use

The Flash 30 / 60 LED is not suitable for use in an upright position unless the mounting bracket is attached

to a stable surface like a floor stand or a metal foot with sturdy materials.

Suspended use (bracket)

If you want to suspend the Flash 30 / 60 LED use the mounting bracket that has already been attached to

the device. Use the tightening knobs to adjust the bracket.

The Flash 30 / 60 armature is already equipped with a hanging bracket and contains holes to mount a

standard G-hook or coupler. You can find standard hooks and/or brackets for 35 or 50mm tubes (truss or

light stand) at your local dealer.

Hardware for mounting the Flash 30 / 60 LED to the wall ceiling or beam is not included. Contact a

specialist if you're not sure which hardware is required for your situation. A wooden beam and stone wall

require different mounting methods.

Should you want to suspend the Flash 30 / 60 LED you will need to attach a safety cable to the armature.

This is not included but is available at your local dealer. The Flash 30 / 60 LED is equipped with an eyelet for

hooking safety cable. Once it's hooked on you can wrap the cable around the truss or light stand and attach

it again by means of the same hook. This ensures the device is secured and prevents it from falling even if

one or both of the brackets should come loose.

Ensure that the safety cable has a load capacity of 10x the weight of the armature and that the device can

not fall farther than 30 cm. You can wrap the safety cable around the truss or light stand several times to

ensure the fall is as short as possible. The shorter the fall the less chance of damage or injury.

Light source

The Flash 30 / 60 LED has powerful LED modules that create an even more powerful effect thanks to a

special lens that bundles the beams together. Never look directly into the lens from at close range as the

human eye can't adjust to the sudden intensity of the beam of light this device produces. It won't result in

permanent damage but it can cause temporary blind spots which may cause disorientation and discomfort.

Cooling

The Flash 30 / 60 LED is not equipped with active cooling by means of fans. Cooling the light source is done

by means of a passive cooling block and ventilation slots in the housing.

Parts and repair

This product does not include spare parts and can not be repaired by the user. All inspections and overall

maintenance should be done by a specialist.

Cleaning and maintenance

Clean the exterior of this device monthly with a dry or slightly damp microfibre cloth. Ensure that the device

is unplugged before cleaning it.

The information in this user manual is subject to change at any time without notice.

Version: 1.0 Date of creation and author's initials:02-02-2017 RV Revision date and author's initials: -

Check if all the screws are intact and secured and tighten or replace them where needed. Check all metal

parts of the device for any signs of corrosion. If corrosion is found the device needs to be checked

thoroughly.

The information in this user manual is subject to change at any time without notice.

Version: 1.0 Date of creation and author's initials:02-02-2017 RV Revision date and author's initials: -

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Ayra Équipement de test

Ayra

Ayra Flash FX LED Manuel utilisateur

Manuels Équipement de test populaires d'autres marques

SMART

SMART KANAAD SBT XTREME 3G Series Manuel utilisateur

Agilent Technologies

Agilent Technologies BERT Serial Manuel utilisateur

Agilent Technologies

Agilent Technologies N3280A Manuel utilisateur

Vernier

Vernier Go Direct Voltage Manuel utilisateur

Lifeloc

Lifeloc R.A.D.A.R. Manuel utilisateur

Fluke

Fluke T5-600 Instructions d'utilisation et d'installation

Mercury

Mercury TSL01 Manuel utilisateur

MAHA

MAHA MBT Series Manuel utilisateur

Fuji Electric

Fuji Electric P-61 Manuel utilisateur

ETC

ETC SealerAtor Manuel utilisateur

Skyfine

Skyfine ETHYWAY V2 Manuel utilisateur

Appion

Appion G5 Twin Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 8159-0112A Manuel utilisateur

BW Technologies

BW Technologies MicroDock II Manuel utilisateur

Sun Nuclear

Sun Nuclear 1027 Manuel utilisateur

Biomark

Biomark HPR LITE READER Manuel utilisateur

Hioki

Hioki 3169-20 Manuel utilisateur

Ashcroft

Ashcroft ATE-100 Manuel utilisateur
