AXISQ17Series

AXISQ1785-LENetworkCamera

AXISQ1786-LENetworkCamera

RepaintingInstructions

AXISQ17Series

Impactonwarranty

ThisproductisapprovedforrepaintbyAxis,providedthatyoufollowtheinstructionsinthisdocumentandat

www.axis.com/warranty-implication-when-repainting

Riskswithrepainting

ThereareseveralriskswhendisassemblingorassemblinganAxisproduct.Thereisalwaysacertainyieldlossduringassembly.Training

ofoperatorsandtheuseofcorrecttoolsmediatessomeoftheproblemsbuttheycanneverbefullyavoided.Someoftherisksinclude:

ESDDamage-AlwayshandletheproductinanESDsafeenvironment.EvenifprecautionsaretakenthereisalwaysariskofESD

damage.Thedamagecanremainundetectedandcauseproblemsduringthelifetimeoftheeuipment.

Dustcontamination-Openingacameramayexposethelensandsensortodustorpaint.Dustwillaffecttheopticalperformance.

Lensesneedtobedisassembledinadust-freeenvironment,preferablyacleanroom.

Paintoverspray-Maskingthedifferentcomponentsoftheeuipmentiscritical.Failuretomasksensitiveareascancauseproblems

withassemblingtheeuipment.Anyareasthatarenotpaintedatfactoryorhaveadifferentsurfacetreatmentthantherestofthe

parts(threads,groundandelectricalcontactsurfaces)mustalsobemaskedtoensurefunction.

AXISQ17Series

Howtorepainttheproduct

reparations

•Ifapplicable,disassembletheeuipmentaccordingtotheinstructionsinthisdocument.

•Cleanallpartstoberepaintedthoroughlytoremovegrease,dust,oroil.

•Toensurereassemblyandfunctionalityoftheproduct,maskopeningsforscrews,LEDindicators,ormicrophonesbefore

painting.

retreatmentofparts

Dependingonthepartmaterialandtypeofpaintappliedatfactory,differentpretreatmentshouldbedoneforthenewpaintto

adhereaswellaspossible.Cleanthepartsproperlytoremoveoil,greaseanddust.

Formoreinformationonthematerialsusedintheproduct,seeitsdatasheetatwww.axis.com

Powdercoatedparts-Useaprimer.Alternatively,removetheoriginalpowdercoatingdowntothebasematerial,usingne

sandpaper,andcleanthepartsbeforepainting.

Anodisedandchromatedparts-Useaprimer.

Uncoatedstainlesssteel-Nospecialpretreatmentisneeded,butmakesurethatthesurfaceiscleanbeforepainting.

Plastic-Useaprimer.

Disassembly

1Lid

2Screw

1.Removethescrewandthelidfromthefoot.

AXISQ17Series

Howtorepainttheproduct

1Weathershield

2Holder

3Screw

2.Removetheweathershield.

3.Removetheholderfromtheweathershield.

4.Removethescrewfromtheholder.

1Screw

2Cover

5.Removethescrewsandthememorycardcover.

6.Removethescrewsfromthememorycardcover.

AXISQ17Series

Howtorepainttheproduct

1Screw

2Lockscrew

3opcover

4Pin

5Clamp

6Bottomcover

7.Removethefourscrews,thebottomcover,andthepin.

8.Removetheclamp.

9.Loosenthelockscrewandremovethetopcover.

10.Removethelockscrewfromthetopcover.

Masking

1.Maskallscrewsandscrewholes.

AXISQ17Series

Howtorepainttheproduct

2.Masktheentiretopofthefoot.

3.Masktheentirebottomofthefoot.

4.Maskthebackofthelid.

5.Masktheundersideoftheweatherhsield.

6.Masktheholderasillustratedabove.

7.Masktheinsideofthememorycardcover.

8.Masktheinsideofthearmcovers.

AXISQ17Series

Howtorepainttheproduct

9.Maskthebottomofthefoot.

10.Maskeverythingbetweenthefootandtheballjoint.

11.Maskeverythingbehindthememorycardcover.

12.Masktheslotsfortheweathershield.

13.Maskthefrontofthecamera.

Repainting

1.Applyathinandevenlayerofspraypaintaccordingtotheinstructionsofthepaintmanufacturer.

2.Letthepaintdry.

3.Togetabettercoverageandclearercolor,applyasecondlayerofspraypaint.

4.Whenthepaintisdry,removethemasking.

AXISQ17Series

Howtorepainttheproduct

Reassembly

1Cover

2Washer

3Wedgespacer

1.Placethecoverovertheballjoint.

2.Alignthescrewholeinthewedgespacerwiththeholeinthewasher.

1Clamp

3.Placetheclampoverthecable.

4.Rotatetheclamp180°sothattheopeningfacesup.

AXISQ17Series

Howtorepainttheproduct

1Screw

2Screw

3Cover

4Washer

5Pin

5.Makesurethatthetabonthewasherisintherecessinthecover.

6.Placethepinintherecessinthecover.

7.Attachthecover,thefourscrews,andthelockscrew.Donottightenthescrews.

8.Tightenthefourscrewswith1Nm(0.7lbft)tighteningtorue.

9.Assemblethememorycardcover.

10.Assembletheweathershield.

RepaintingInstructionsVer.M1.6

AXISQ17SeriesDate:November2018

©AxisCommunicationsAB,2018PartNo.T10124109
