Axis T8129 Manuel utilisateur
USER GUIDE
ENGLISH DEUTSCH ITALIANO ESPAÑOL
FRAN
Ç
AIS
AXIS T8129 PoE Extender
Electromagnetic Compatibility (EMC)
This equipment generates, uses and can radiate
radio frequency energy and, if not installed and
used in accordance with the instructions, may
cause harmful interference to radio
communications. However, there is no
guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful
interference to radio or television reception,
which can be determined by turning the
equipment off and on, the user is encouraged to
try to correct the interference by one or more of
the following measures: Re-orient or relocate
the receiving antenna. Increase the separation
between the equipment and receiver. Connect
the equipment to an outlet on a different circuit
to the receiver. Consult your dealer or an
experienced radio/TV technician for help.
Shielded (STP) network cables must be used with
this unit to ensure compliance with EMC
standards.
CLASS B USA:
This equipment has been tested using a shielded
network cable (STP) and found to comply with
the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses and
can radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful interference to
radio communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning
the equipment off and on, the user is
encouraged to try to correct the interference by
one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment
and receiver.
Connect the equipment into an outlet on a
circuit different from that to which the receiver
is connected.
Consult the dealer or an experienced radio/TV
technician for help.
Equipment Modifications
This equipment must be installed and used in
strict accordance with the instructions given in
the user documentation. This equipment
contains no user-serviceable components.
Unauthorized equipment changes or
modifications will invalidate all applicable
regulatory certifications and approvals.
Liability
Every care has been taken in the preparation of
this document. Please inform your local Axis
office of any inaccuracies or omissions. Axis
Communications AB cannot be held responsible
for any technical or typographical errors and
reserves the right to make changes to the
product and documentation without prior
notice. Axis Communications AB makes no
warranty of any kind with regard to the material
contained within this document, including, but
not limited to, the implied warranties of
merchantability and fitness for a particular
purpose. Axis Communications AB shall not be
liable nor responsible for incidental or
consequential damages in connection with the
furnishing, performance or use of this material.
RoHS
This product complies with both the
European RoHS directive, 2002/95/EC,
and the Chinese RoHS regulations,
ACPEIP.
WEEE Directive
The European Union has enacted a
Directive 2002/96/EC on Waste
Electrical and Electronic Equipment
(WEEE Directive). This directive is
applicable in the European Union member
states.
The WEEE marking on this product (see right) or
its documentation indicates that the product
must not be disposed of together with
household waste. To prevent possible harm to
human health and/or the environment, the
product must be disposed of in an approved and
environmentally safe recycling process. For
further information on how to dispose of this
product correctly, contact the product supplier,
or the local authority responsible for waste
disposal in your area.
Business users should contact the product
supplier for information on how to dispose of
this product correctly. This product should not
be mixed with other commercial waste. For more
information, visit www.axis.com/techsup/.
Support
Should you require any technical assistance,
please contact your Axis reseller. If your
questions cannot be answered immediately, your
reseller will forward your queries through the
appropriate channels to ensure a rapid response.
If you are connected to the Internet, you can:
• download user documentation and firmware
updates
• find answers to problems in the FAQ database.
Search by product, category, phrases.
• report problems to Axis support by logging in
to your private support area.
AXIS T8129 PoE Extender Page 5
ENGLISH
AXIS T8129 PoE Extender User Guide
Hardware overview
PoE extender
Network connector
LED indicators
Camera
PoE extender
Switch
Midspan
Max 100 m (328 ft.) Max 100 m
Page 6 AXIS T8129 PoE Extender
Technical Specifications
Item Specifications
Model AXIS T8129 PoE Extender
Data rate 10/100 Mbps half/full duplex
Connectors Shielded RJ-45, EIA 568A and 568B
Network cables Shielded category 5 (or higher)
Display and
indicators
LED indicators are located on the RJ-45 connector
Power indicator: PoE enabled (Green)
Network indicator: Link/activity (Yellow)
Compliance IEEE 802.3af, IEEE 802.3at, RoHS, WEEE, CE
Mounting Wall or shelf
Environment Indoor
Approvals FCC part 15, Class B with FTP cabling, EN 55022 Class B
(Emissions), EN 55024 (Immunity)
Operating
conditions
-10 °C to 50 °C (14 °F to 122 °F)
Humidity max. 85% RH (non-condensing)
Storage -40 °C to 74 °C (-40 °F to 165 °F)
Dimension
(HxWxD)
105 x 40 x 22 mm (4.1” x 1.6” x 0.9”)
Weight 45 g (1.6 oz.)
AXIS T8129 PoE Extender Page 7
ENGLISH
Maximum Distances for Power Sources
Multiple PoE extenders can be connected every 100 meters to obtain
greater distances. The actual figures depend on operating conditions.
The range is over 24 AWG or heavier Cat-5e or Cat-6 cable except
where specified.
Examples for low-power PoE cameras (that are PoE Class 1, or require
under 6 watts):
• AXIS M11 Network Camera Series
• AXIS 221 Network Camera
• AXIS M30 Network Camera Series
• AXIS M31-R/-VE Network Camera Series
• AXIS M32 Network Camera Series
• AXIS P33 Network Cameras (indoor models)
• AXIS 212 PTZ/-V Network Camera
PoE Source
PoE switch or Axis 15 W
midspan (802.3at) PoE+ switch (802.3at) Axis 30 W midspan
(802.3at)
300 m (984 ft.) 400 m (1312 ft.) 400 m (1312 ft.)
Page 8 AXIS T8129 PoE Extender
Examples for medium power PoE cameras that are PoE Class 1 or 2, or
require under 12 watts:
• AXIS M1054 Network Camera
• AXIS P13 Network Cameras (indoor models)
• AXIS Q16 Network Cameras (indoor models)
• AXIS Q1755 Network Camera
• AXIS Q19 Network Camera Series
• AXIS P33 Network Cameras (outdoor models)
PoE Source
PoE switch or
Axis 15 W midspan
(802.3at)
PoE+ switch (802.3at) Axis 30 W midspan
(802.3at)
200 m (656 ft.) 200 m (656 ft.) 300 m (984 ft.)
AXIS T8129 PoE Extender Page 9
ENGLISH
Examples for full power PoE or PoE+ cameras that are PoE 802.3af
class 3 that require more than 12 watts, or 802.3at compliant:
• AXIS P13-E Network Cameras
• AXIS Q16-E Network Cameras
• AXIS Q1755-E Network Camera
• AXIS P55 Network Camera Series
• AXIS Q60 Network Cameras (indoor models)
Examples for Custom High PoE cameras:
• AXIS Q60-E Network Cameras
*use 23AWG or heavier cable (typically Cat 6)
PoE Source
PoE switch or
Axis 15 W midspan
(802.3at)
PoE+ switch (802.3at) Axis 30 W midspan
(802.3at)
not applicable not applicable 200 m (656 ft.)*
PoE Source
PoE switch or
Axis 15 W midspan
(802.3at)
PoE+ switch (802.3at) Axis 30 W midspan
(802.3at)
not applicable not applicable 200 m (656 ft.)*
(together
with Axis 60 W
midspan)
