AXIOMTEK TBOX324-894-GND Manuel utilisateur

4 9416N324030E

Ver ion A1 May 2018

Printed in Taiwan

DRAM Installation

Step 1 Make sure system power is off. Loosen the lateral cover

screws to remove the cover as shown.

Step 2 Loosen the lateral screws as shown.

Step 3 Pull out the front bezel and the internal bracket as shown.

Step 4 Remove the DRAM cover by loosening the screws. Install

DRAM and then stick the thermal pad on it.

Step 5 Secure the DRAM cover by fastening the screws, and then

install the internal bracket and the front bezel. Fasten the

lateral screws as shown to complete the installation.

tBOX324-894-GND Quick Installation Guide

9416N324030E 1

Ver ion A1 May 2018

Printed in Taiwan

Checklist

Standard Accessories Optional Accessories

tBOX324-894-GND series

System U

nit

SATA Drive (HDD or SSD)



Quick I

nstallation

uide x 1



PCI Express Mini Card



CD x 1 (w/

Driver & Manual)



Remote Switch C

able



Foot Pad x 4



M12 LAN C



Screws

ack



Wireless

odule



Wall

ount

Bracket

x 1



M12

ower

able



SATA Drive

Key x 2



RAM

Thermal

Pad x 4



onnector

Note: Please contact your local supplier immediately if any of the above-

mentioned items is missing or damaged.

Dimensions

tBOX324-894-GND series

tBOX324-894 Transportation Fanless mbedded System

2 9416N324030E

Ver ion A1 May 2018

Printed in Taiwan

I/O Outlets

Front View

Rear View

Power Input explanation:

▲24VDC-in marine application (TB: + G -)

▲110VDC-in railway application (M12: DC IN)

▲12/24VDC-in vehicle application (TB: + - ACC)

9416N324030E 1

Ver ion A1 May 2018

Printed in Taiwan

Hardware Installation

SATA drive and CFast Installation

Step 1 Make sure system power is off. Loosen the screws of the

SATA drive tray and then pull out the tray as shown.

Step 2 Slide an HDD into the tray as shown in the picture. Insert

screws into each side of the SATA drive through the

corresponding holes and fasten the screws firmly.

Step 3 Insert the SATA drive and then the CFast into their slots

respectively, as shown in the pictures

Step 4 Secure CFast and SATA drive by fastening all of the screws

tightly to complete the installation.

Mini PCIe module and SIM card Installation

Step 1 Make sure system power is off. Loosen the lateral cover

screws to remove the cover as shown.

Step 2 Install the SIM card or Mini PCIe module and fasten screws.

Notice the signal support type of the mini card slot when

installing the card. Fasten screws.
