awave DSP A10 Manuel utilisateur
Ower s Manual
,
DSP Car Power Amplifiers
A10
D04-MEN124-00
PRODUCT BRIEF INTRODUCTION
[ 1 ]
PRODUCT BRIEF INTRODUCTION
[ 2 ]
1.PRODUCT DESCRIPTION-PRECAUTIONARY NOTES
The DSP is a digital signal processor essential to maximize the acoustic performance of your car audio system.
It consists of a 32-bit DSP processor and 24-bit AD and DA converters.
It can connect to any factory system,even in vehicles featuring featuring an intergrated audio processor,since,thanks to the.
De-equalization function,the DSP will send back a linear signal.
It features selectable High and low level inputs as well as 3.5MM Aux and digital inputs that feed 8 completely variable output
channels. Each output channel has a 31-band equalizer available.it also features a 66-freqency electronic crossover as well as .
BUTTERWORTH or LINKWITZ filters with 6-24dB slopes and a digital time delay line.the user canselect adjustments.
That allow him or her to interact with the DSP through a remote control device called DRC.
WARNING: 1-a PC provided with Windows XP,Windows Vista or Windows 7 operating system,1.5GHz minimum.
Processor speed ,1 GB RAM minimum memory and a graphics card with a minimum resolution.
Of 1024x600 pixels are required to install the software and setup the DSP.
2-Before connecting you DSP, carefully read this manua .Improper connections may cause damage to
The DSP or to the speakers in the car audio system.
2.PACKAGING CONTENTS
- DSP- Signal Interface Processor
- Power supply cable Inputs/speaker output
- 5.0m USB cable
- 4 of 4.0*15 mm/8of 3.0*6mm self-tapping,
Cross-head fixing screws,
OPTIONAL:
- DRC(Digital Remote Control)control panel:
- 5.0 m DRC-AC Link cable
- Control High Level /wifi Input
INDEX
1. PRODUCT DESCRIPTION-PRECAUTIONARY NOTES............................02
2. PACKAGING CONTENTS........................................................................02
3. DSP AND DRC INSTALLATION...............................................................03
4. INPUT SIGNALS ............................................................................................04
5. GUI OPERATION INSTRUCTION........................................................05-06
6. INTERFACE INTRODUCTION .................................................................. 07-10
7. REMOTE INTRODUCTION......................................................................10
8. TECHNICAL FEATURES.........................................................................11
PRODUCT BRIEF INTRODUCTION
[ 3 ]
PRODUCT BRIEF INTRODUCTION
[ 4 ]
3.DSP AND DRC INSTALLATION
External dimensions
How to install
WARNING: do not use aggressive cleaning agents or abrasive cloth to clean the display.Simply use
a soft cotton colth lightly damped with water.
4. INPUT SIGNALS
171
49
COAX IN
LINE OUTPUTS
LINE INPUTS
1 INPUT +
2 INPUT +
3 INPUT +
4 INPUT +
5 INPUT +
6 INPUT +
1 INPUT -
2 INPUT -
3 INPUT -
4 INPUT -
5 INPUT -
6 INPUT -
POWER INPUT
OPTICAL INPUTS
+
+
+
+
+
+
+
+
FUS E
POW ER
SPE AK ER OUT PU T
MOD E ON
POW ER IN PU T
GND
AUTO AC C
CH
1 2 3 4
+ + + +
- - - - 4
56 7 8
+
-
+
-
5
REMOUT
REMIN
CH
+
-
+
-
+12V
BIueTooth
COA X IN
LIN E INP UTS
USB
CONTROL
REMOTE
CONTROL HIGH LEVEL INPUT
OPTICAL
INPUT
LIN E OUT PUT
CH1
CH2
CH3
CH4
CH5
CH6
CH7
CH8
CH9
CH10 C H
123456
++++++
- - - - - -
1 3
2 4
PRODUCT BRIEF INTRODUCTION
[ 5 ]
PRODUCT BRIEF INTRODUCTION
[ 6 ]
5.GUI OPERATION INSTRUCTION
Guide to GUI after installation
1. Double - click icon of DSP-CONTROL
2. Enter the GUI you long for! Now you could tone every signal details as experts do
To bring sound effect on your beloved car to a higher level.If the password has been set,
You need to enter the password.
6.1DSP interface guidance
6. INTERFACE INTRODUCTION
1. Connect(connect to the DSP)
1
6.2 FILE MAIN MENU
RE SET
SS _M/M P0
DG ND
DV DD
XTA LIN /MC LK
XTA LOU T
CL KOU T
MO SI_ M/MP 1
SC L_M/ SCL K
SD A_M/ MIS O
MI SO/ SDA
SC LK/ SCL
MO SI/ ADD R1
SS /AD DR0
SE LFB OO T
DV DD
DG ND
DG ND
DSP A10
PRODUCT BRIEF INTRODUCTION
[ 7 ]
PRODUCT BRIEF INTRODUCTION
[ 8 ]
5. Save as(To save another file setting to PC)
3. Open(To load preset file in PC folder)
4. Save(To save setting to PC)
6. Restore Factory(To save preset file in DSP)
7.Modify Password
8. Write To Device
9. Read From Device
11. Exit
1. INPUT MODE.
To select different input devices.
10. About
2. Language(choose you need language)
CH mode(2CH 4CH 6СH ).
1
2. CHANNAL SETING.
1.2.3.4.5.6
1
2
FL
FR
7.3
3. CROSSOVER X-TPE.
To choose different crossover type, for example select CH selection on 3RD
spot .that would locate CH you want to choose for crossover configuration .
4. CROSSOVER FREQUENCY.
Set frequency of LP/HP individually .
5. GAIN.
0--40dB is optional range for gain control kf every CH.
6. DELAY.
1.Auto configuration(base on 1.5 setting).
2.Manual configuration, change specifications in selected CH manually.
PRODUCT BRIEF INTRODUCTION
[ 9 ]
PRODUCT BRIEF INTRODUCTION
[ 10 ]
7. LP/SLOPE.
1.6dB/oct 12dB/oct 18dB/oct 24dB/oct 30dB/oct
36dB/oct. 42dB/oct 48dB/oct are available.
8. HP/SLOPE.
1.6dB/oct 12dB/oct 18dB/oct 24dB/oct 30dB/oct
36dB/oct.42dB/oct 48dB/oct are available.
10. WRITE.
To Write To Device(POS1-POS8).
9. Filter Model.
To choose different Filter type Linkwitz Bessel Butterworth.
12. X-OVER AND EQ CHARTS.
13. EQ SETTING.
1.Red lines and slopes will change accordingly when
2.EQ all frequency points can be move left or right.For 20Hz-20KHz can be any Regulation.
Q volue=1-12.
HP/LP of crossover and EQ are modified.
11. READ.
To Read From Device(POS1-POS8).
7.REMOTE INTRODUCTION
PRODUCT BRIEF INTRODUCTION
[ 11 ]
8.TECHNICAL FEATURES
POWER SUPPLY
Voltange 9-16VDC
Idling current 1.5A
SIGNAL STAGE
Bandwith @-3 dB 10-20kHz
Hight level input range 3V-15V
S/N ratio Full Power A-
INPUT STAGE
High Level(Speaker) 1.2.3.4.5.6
CONNECTION
From/To Personal Computer 1 x USB/B(1.1/2.0) 5M
CROSSOVER N.5(one each output channel)
Filter Type Full/High/Low Pass /Band Pass
Slope Setting 6/12/18/24/30/42/48 dB
68 steps @ 20- 20kHz
Phase control indepent setting for each channel 0 - 180
Crossover frequency
>100 dB
THD+N VS Power 1% (СH1 CH2 CH3 CH4 СH5 CH6 CH7 CH8 ) 8X50W ATTS
