Avtech AVC508 Manuel utilisateur

508, 508A_V1.2

Please read instructions thoroughly before operation and retain it for future reference.

HIGH QUALITY

HIGH QUALITY Color Dome Camera

Color Dome Camera

User

User’

’s Manual

s Manual

152

CAUTION:

To reduce the risk of electric shock, do not expose this apparatus to rain or moisture.

Only operate this apparatus from the type of power source indicated on the label.

Our company shall not be liable for any damages arising out of any improper use, even if we have been advised of the

possibility of such damages.

CAUTION

RISK OF ELECTRIC SHOCK

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert

the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure

that may be of sufficient magnitude to constitute a risk of electric shock to persons.

This exclamation point within an equilateral triangle is intended to alert the user to the

presence of important operating and maintenance (servicing) instructions in the literature

accompanying the appliance.

CE Mark

This apparatus is manufactured to comply with the radio interference.

Our company does not warrant that this manual will be uninterrupted or error-free. We

reserve the right to revise or remove any content in this manual at any time.



Crystal & Clear Image

Crystal & Clear Image :

1/3" Sony Color Super HAD CCD

Sony Color Super HAD CCD image sensor to provide superior pictures



High Resolution

High Resolution :

Excellent picture quality with 480 TV lines



Satisfied Min. Illumination

Satisfied Min. Illumination :

1 / F2.0 for high resolution models



With Sensitive Microphone (Optional)

With Sensitive Microphone (Optional)

Built in Auto Electronic Shutter

Signal-to-noise ratio more than 48dB

P.1

This series of color camera employs 1/3" Sony Color Super HAD CCD image sensor which

provides extremely long life and high reliability. Besides the built-in sensitive microphone

(optional), it also increases the quality of surveillance.

PRODUCT OVERVIEW

FEATURES

P.2

PACKAGE CONTENTS

Color Dome Camera * 1 ……………………………..……………..

User’s Manual * 1 …………………………………………….…..…

Power and Video * 1 ……………………………….……………….

Power and Video / Audio Cable * 1 ……………………………….

P.4

CONNECTIONS

CONNECTIONS_

__Without Audio Model

1. Power Cable

Power Cable:

Connect to an external 12V DC regulated adapter.

2. Video Output Connector

Video Output Connector:

Connect to monitor with a 75Ωcoaxial cable.

Supplies the video output signals.

P.3

1. Power Cable

Power Cable:

Connect to an external 12V DC regulated adapter.

2. Video Output Connector

Video Output Connector:

Connect to monitor with a 75Ωcoaxial cable.

Supplies the video output signals.

3. Audio Output Connector:

Audio Output Connector:

Connect to the AUDIO IN connector of the

recording device.

CONNECTIONS

CONNECTIONS_

__With Audio Model

Note:

Please use correct power adaptor, DC12V (regulated), to operate this unit. The power tolerance of this unit

is DC12V ± 10%, over maximum DC 12V power input will damage this unit.

Note:

Please use correct power adaptor, DC12V (regulated), to operate this unit. The power tolerance of

this unit is DC12V ± 10%, over maximum DC 12V power input will damage this unit.

SPECIFICATION

P.5

87.5(Ø) x 83(H)

YES

Color Rolling Suppress

92°

Lens Angle

f3.6mm / F2.0

Lens

High Resolution without Audio

YES

Audio

1.0Vp-p composite, 75Ω

Video Output

1/60 to 1/100,000 second (NTSC); 1/50 to 1/100,000 second (PAL)

Electronic Shutter

AES

Iris Mode

100 mA ±10%

Current Consumption

AUTO

Gain Control

BLC

High Resolution with Audio

MODEL

1Lux / F2.0

480 TV lines

768(H)x494(V) <NTSC> / 752(H)x582(V) <PAL>

1/3" SONY Color Super HAD CCD image sensor

186g

88(Ø) x 83(H)

DC12V ±10% regulate

Power Source

Dimension (mm)

Net Weight

ATW

White Balance

More than 48dB (AGC off)

S/N Ratio

Min. Illumination

Resolution

Number of Pixels

Pick up Element
