AVProConnect AC-DA18-UHD Manuel utilisateur
pg. 1
AVProConnect ~ 3518 N Casco Ave. Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~
User)Manual)
AC-DA18-UHD)
A!full!4K60!4:2:0!(Up!to!14GBPS)!
Distribution!Amplifier!with!advanced!EDID!management!
*Available!in!1x2,!1x4,!and!1x8
AC-DA18-UHD)
Introduction
AC-DA18-UHD is an 18GBPS, full bandwidth HDMI2.0a (HDR) with
HDCP2.2 eight-way HDMI splitter. Functionally, distributes the input HDMI
signal to four identical HDMI outputs. These four outputs are synchronized.
AC-DA18-UHD has the ability of pre-emphasis and equalization. Multiple
cascaded AC-DA18-UHD achieves long distance transmission of HDMI
signal of more than 15 meters even in 4K (HDR) resolution.
The outstanding and proprietary clock jitter cleaner enable this splitter to out
preform the competition when in cascading mode no matter the signal is 4K or
1080P.
AC-DA18-UHD offers solutions for usage as a component of digital HDMI
distributions and entertainment systems also UHDTV/4K retail and general
show sites. Use in conjunction with UHDTV, UHD Projector, STB, UHD-BD,
UHD Media Player and in environment where noise, space and security are
concerns. Fits perfectly in data center control rooms, information distribution
premises, conference and presentation rooms, school educational facilities
and corporate training environments.
AC-DA18-UHD)
pg. 2
AVProConnect ~ 3518 N Casco Ave. Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~
Contents
HDMI Splitter ......................................................................................................... 2
Product Overview .................................................................................................. 4
Features ................................................................................................................ 4
Package Contents ................................................................................................. 6
Connections and Operations ................................................................................ 6
Specifications ........................................................................................................ 6
Panel Descriptions ................................................................................................ 7-8
Typical Application ................................................................................................... 15
Maintenance ......................................................................................................... 11
Product Service ..................................................................................................... 11
Mail-In Service ...................................................................................................... 12
Warranty ................................................................................................................ 12
Warranty Limits And Exclusions ........................................................................... 13
AC-DA18-UHD)
pg. 3
AVProConnect ~ 3518 N Casco Ave. Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~
Full 4K 60 (4:2:0) HDMI Splitter
& Distribution Amplifier
■Product Overview ( Model Number: AC-DA18-UHD)
■
Features
lEasy to Use: Install in seconds, no need for setting.
lDistribution: One HDMI input, four identical HDMI outputs.
lSupports up to 18GBPS with resolutions of 4K60, 4K30, 1080p, 1080i,
720p and other standard Video formats, PAL and NTSC.
lCustomer can configure EDID function to enable the best compatibility.
lSupports HDCP2.2
lHDMI 2.0(a) w/ HDR.
lMounting ears are included for easy fixation on wall, furniture or ceiling.
?Notice
AVProConnect reserves the right to make changes in the hardware, packaging
and any accompanying documentation without prior written notice.
AC-DA18-UHD)
pg. 4
AVProConnect ~ 3518 N Casco Ave. Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~
Warning
To reduce the risk of fire, electric shock or product damage:
1. Do not expose this apparatus
to rain, moisture, dripping or
splashing and that no objects
filled with liquids, such as vases,
shall be placed on the apparatus.
6. Clean this apparatus
only with dry cloth.
2. Do not install or place this unit
in a bookcase, built-in cabinet or
in another confined space.
Ensure the unit is well ventilated.
3. To pr e ven t ris k of el e ct r ic
shock or fire hazard due to
overheating, do not obstruct
the unit’s ventilation openings
with newspapers, tablecloths,
curtains, and similar items.
4. Do not install near any heat
sources such as radiators, heat
registers, stoves, or other
apparatus (including amplifiers)
that produce heat.
5. Do not place sources of naked
flames, such as lighted candles,
on the unit.
7. Unplug this apparatus
during lightning storms or
when unused for long
periods of time.
8. Protect the power cord
from being walked on or
pinched particularly at
plugs.
9. Only use attachments /
accessories specified by
the manufacturer.
10. Refer all servicing to
qualified service
personnel.
AC-DA18-UHD)
pg. 5
AVProConnect ~ 3518 N Casco Ave. Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~
■
Package Contents
·Main unit. P/N: AC-DA18-UHD
·12VDC Power Supply.
·Operating Instructions. (Digital @ www.avproconnect.com)
·Mounting Ears
■
Connections and Operations
1) Connect the HDMI input source into AC-DA18-UHD
2) Connect the HDMI output equipment (Displays) into AC-DA18-UHD
3) Insert the DC side of 12V power supply into AC-DA18-UHD and then
connect the AC side of the Power supply into the wall outlet.
4) Plugging in the unit automatically powers up the device.
&NOTE: Insert / Extract cables gently.
■
Specifications
Operating Temperature Range -5 to +35°C (-41 to +95 °F)
Operating Humidity Range 5 to 90 % RH (no condensation)
Video Amplifier Bandwidth Up to 14.0 GBPS
Input Video Signal 0.5-1.0 volts p-p
Input DDC Signal 5 volts p-p (TTL)
HDCP version HDCP2.2 /HDCP1.4
Maximum Format Support 4K60Hz 4:2:0
AC-DA18-UHD)
pg. 6
AVProConnect ~ 3518 N Casco Ave. Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~
Other Video Formats
Supported
VESA: 640x480, 800x600, 1024x768,
1280x1024, 1600x1200, 1920x1200
DTV/HDTV:
480i/576i/480p/576p/720p/1080i/1080p/4K
Output Video HDMI 2.0, HDCP 2.2, HDR Compatible
Power Consumption 6 Watts (max.)
Power Supply 12V DC/3A
Dimensions 150mm (W) x 81mm (H) x 25mm (D)
Mass 0.5 KGS
■
Panel Descriptions
Front Panel
Activity Display (Front):
a) When Power is applied all lights flash RED and the machine begins
to function. If no devices are plugged in, you can verify power by
looking inside the vent on the right side of the unit.
b) When the INPUT device is plugged in, the light blink RED while
“handshaking” is occurring, and goes SOLID once communication is
complete and signal is good.
c) When a sink (display) is plugged into an OUTPUT, the
corresponding light blinks RED until the “handshake” is complete.
Once the connection is made the OUTPUT lights will go SOLID (If a
sink or display is plugged in).
AC-DA18-UHD)
pg. 7
AVProConnect ~ 3518 N Casco Ave. Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~
Back Panel
①Power input.
②HDMI input.
③HDMI outputs (x8).
Device Top Cover
Device cover is labeled for DIP Switch (EDID setting) and ISP mini USB port
and for easy HDMI port recognition especially useful when Mounting Ears are
used for fixation.
&NOTE: DIP Switch EDID setting index on next page.
AC-DA18-UHD)
pg. 8
AVProConnect ~ 3518 N Casco Ave. Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~
EDID Settings: The AC-DA18-UHD uses a dual rotary style switch to house more EDID’s
and allow for future expansion. The dual rotary switches can be located on the side of the
device, and each rotary is representative of a number in the desired setting, (Left
Rotary=DIGIT ONE, Right Rotary=DIGIT TWO). The default mode is “00” which is both
rotary switches pointed to “0”, in this mode the device copies the EDID from the sink (display)
plugged into OUTPUT 1. Custom EDID settings are below.
EDID ROTARY Settings:
00: EDID COPY (See NOTE 1)
01: 1080P_2CH(PCM)
02: 1080P_6CH
03: 1080P_8CH
04: 1080P_3D_2CH(PCM)
05: 1080P_3D_6CH
06: 1080P_3D_8CH
07: 4K30Hz_3D_2CH(PCM)
08: 4K30Hz_3D_6CH
09: 4K30Hz_3D_8CH
10: 4K60Hz(Y420)_3D_2CH(PCM)
11: 4K60Hz(Y420)_3D_6CH
12: 4K60Hz(Y420)_3D_8CH
13: 4K60Hz_3D_2CH(PCM)
14: 4K60Hz_3D_6CH
15: 4K60Hz_3D_8CH
16: 1080P_2CH(PCM)_HDR
17: 1080P_6CH_HDR
18: 1080P_8CH_HDR
19: 1080P_3D_2CH(PCM)_HDR
20: 1080P_3D_6CH_HDR
21: 1080P_3D_8CH_HDR
22: 4K30Hz_3D_2CH(PCM)_HDR
23: 4K30Hz_3D_6CH_HDR
24: 4K30Hz_3D_8CH_HDR
25: 4K60Hz(Y420)_3D_2CH(PCM)_HDR
26: 4K60Hz(Y420)_3D_6CH_HDR
27: 4K60Hz(Y420)_3D_8CH_HDR
28: 4K60Hz_3D_2CH(PCM)_HDR
29: 4K60Hz_3D_6CH_HDR
30: 4K60Hz_3D_8CH_HDR
31: Cascading Mode (See NOTE 2)
AC-DA18-UHD)
pg. 9
AVProConnect ~ 3518 N Casco Ave. Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~
EDID Setting Cont. (Notes):
Note1: EDID Copy mode: EDID will be copied from sink on OUTPUT 1.
The AC-DA18-UHD is set this way by default for maximum “Plug & Play”
Compatibility. If you change sink (Display) plugged into OUTPUT 1, please
follow the steps below if you wish to use the new sink’s EDID.
1. Start with power off
2. Set ROTARY SWITCHES to ‘00’.
3. Power on the unit
4. Power on the source device and connect the HDMI input port.
Note2:Cascading mode (Ideal for larger installations) Cascade mode does
not react to the EDID from the sink device. It sends the signal that you put in,
out. This is ideal for linking multiple units together. The method below is an
ideal way to use this function effectively.
To use cascading mode:
1. Start with power off
2. Fix an EDID on the FIRST unit in the series from the list above
(4K60, 4K30, 1080P, etc…)
3. Set the ROTARY SWITCHES on all subsequent units to “31”
4. Connect the source device
5. Power up the system
AC-DA18-UHD)
pg. 10
AVProConnect ~ 3518 N Casco Ave. Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~
