AVer SF2012H series Manuel utilisateur

1

1. Connects the IP camera to switch/hub and power on first.

2. Make sure the IP camera is in factory default setting. Please refer to IP camera’s

user manual for resetting factory default.

3. The switch/hub is that connects with IP camera and DVR/NVR, please turn off

DHCP function if switch/hub has enabled before.

AVer DVR/NVR can connect up to 4 IP cameras through the LAN network connection and without any

configuration.

The following lists are supported DVR, NVR, and IP camera:

DVR

4/8/16CH EH Nano/Nano+series

NVR

EXR6004 mini

IP Camera

SF2012H series, SF2111H series

1. For 4/8/16CH EH Nano/Nano+ series DVR, please do the pre-configuration on the channel that is

going to connect the IP camera.

2. Power on the DVR unit and login the DVR system. Next, select Setup >> Camera in preview

mode.

3. In Camera setting, select the channel that wants to connect IP camera and mark the Enable to

enable the channel, then, select the camera Input is IP camera. Then, click OK to save the

configuration.

AVer DVR/NVR

+

SF2012H/SF2111H series IP Cameras

Quick Installation Guide

2

4. After pre-configuration completed, turn the DVR unit power off.

EXR6004 mini please skip the step 1~4.

The 4/8/16CH EH Nano/Nano+DVR only support first 4 channels for IP camera

connection.

5. Please refer to figure to connect all devices or components. In figure, we use the EXR6004 min

and SF2012H IP camera as an example.

6. After connecting all devices or components, power on the IP camera first.

7. Next, power on the DVR/NVR unit. Then, DVR/NVR will start to search and detect the SF2012H

series/SF2111H series IP camera on your LAN network.

8. When user sees the video on surveillance monitor, it means DVR/NVR and IP camera has

completed connection.

© 2012 AVer Information Inc. All rights reserved.
