Avenview SPLIT-HDM2-T4K-4 Manuel utilisateur
VIDEO WALLS VIDEO PROCESSORS
VIDEO MATRIX SWITCHES
EXTENDERS SPLITTERS WIRELESS
CABLES & ACCESSORIES
Control Your Video...
1x4 HDMI TRUE 4K@60 SPLITTER
W/ EDID & HD Support
© 2015Avenview Inc. All rights reserved.
The contents of this document are provided in connection with Avenview Inc. (“Avenview”) products. Avenview makes no representations or
warranties with respect to the accuracy or completeness of the contents of this publication and reserves the right to make changes to specifications
and product descriptions at any time without notice. No license, whether express, implied, or otherwise, to any intellectual property rights is granted
by this publication. Except as set forth in Avenview Standard Terms and Conditions of Sale, Avenview assumes no liability whatsoever, and claims any
express or implied warranty, relating to its products are is strictly prohibited.
Model #: SPLIT-HDM2-T4K-4/8
Military Residential
Medical Aviation
Education Industrial
Corporate House Of Worship
www.avenview.com
Product Application & Market Sectors
www.avenview.com Page 3
TABLE OF CONTENTS
1. GETTING STARTED ..........................................................................................................................1
1.1 IMPORTANT SAFEGUARDS..............................................................................................................1
1.2 SAFETY INSTRUCTIONS ..................................................................................................................1
1.3 REGULATORY NOTICES FEDERAL COMMUNICATIONS COMMISSION (FCC) ........................... 2
2. INTRODUCTION ..............................................................................................................................3
2.1 PACKAGE CONTENTS .....................................................................................................................4
2.2 BEFORE INSTALLATION...................................................................................................................4
2.2 CABLE SPECIFICATION ....................................................................................................................5
2.3 APPLICATION DIAGRAM..................................................................................................................6
2.4 PANEL DESCRIPTION.......................................................................................................................7
......................................................................7
2.4.1 INPUT PANEL (SPLIT-HDM2-T4K-4) BACK PANEL
2.4.2 INPUT PANEL (SPLIT-HDM2-T4K-4) FRONT PANEL .....................................................................7
3. INSTALLATION (SPLIT-HDM2-T4K-4)..............................................................................................8
4 GENERAL TROUBLESHOOTING..................................................................................................... 9
5. SPECIFICATIONS ...............................................................................................................................10
www.avenview.com Page 1
SECTION 1: GETTING STARTED
1.1 IMPORTANT SAFEGUARDS
Please read all of these instructions carefully before you use the device. Save this manual for future reference.
What the warranty does not cover
•Any product, on which the serial number has been defaced, modified or removed.
•Damage, deterioration or malfunction resulting from:
•Accident, misuse, neglect, fire, water, lightning, or other acts of nature, unauthorized product modification, or failure to
follow instructions supplied with the product.
•Repair or attempted repair by anyone not authorized by us.
•Any damage of the product due to shipment.
•Removal or installation of the product.
•External causes to the product, such as electric power fluctuation or failure.
•Use of supplies or parts not meeting our specifications.
•Normal wear and tear.
•Any other causes which does not relate to a product defect.
•Removal, installation, and set-up service charges.
1.2 SAFETY INSTRUCTIONS
The SPLIT-HDM2-T4K-4 4/8Port HDMI Splitter has been tested for conformance to safety regulations and requirements, and
has been certified for international use. However, like all electronic equipments, the SPLIT-HDM2-T4K-4 should be used with
care. Read the following safety instructions to protect yourself from possible injury and to minimize the risk of damage to the
unit.
!Do not dismantle the housing or modify the module.
!Dismantling the housing or modifying the module may result in electrical shock or burn.
!Refer all servicing to qualified service personnel.
!Do not attempt to service this product yourself as opening or removing housing may expose you to dangerous voltage
or other hazards
!Keep the module away from liquids.
!Spillage into the housing may result in fire, electrical shock, or equipment damage. If an object or liquid falls or spills on
to the housing, unplug the module immediately.
!Have the module checked by a qualified service engineer before using it again.
!Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device before cleaning.
1. GETTING STARTED
www.avenview.com Page 2
1.3 REGULATORY NOTICES FEDERAL COMMUNICATIONS COMMISSION (FCC)
This equipment has been tested and found to comply with Part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation.
Any changes or modifications made to this equipment may void the user’s authority to operate this equipment.
Warning symbols Description
ONLY USE THE PROVIDED POWER CABLE OR POWER
ADAPTER SUPPLIED. DO NOT TAMPER WITH THE
ELECTRICAL PARTS. THIS MAY RESULT IN ELECTRICAL
SHOCK OR BURN.
DO NOT TAMPER WITH THE UNIT. DOING SO WILL
VOID THE WARRANTY AND CONTINUED USE OF THE
PRODUCT.
THE VIDEO BOARDS ARE VERY SENSITIVE TO STATIC.
PLEASE ENSURE IF RACK MOUNTED OR INSTALLED ON A
SURFACE, IT SHOULD BE IN A GROUNDED ENVIROMENT.
www.avenview.com Page 3
2. INTRODUCTION
The Avenview SPLIT-HDM2-T4K-4 4/8 port HDMI Splitter can support the new industry of video signals 4K@60 and
UHD. This device allows the INPUT (source as 4K GPU graphic card or UHD Digital Player) to be duplicated onto 4
4K@60 or UHD displays. Supporting both video and audio signal simultaneously reproducing the same quality via HDMI
cable with EDID management.
Video Signals: 4K@60 HDR(4:2:0 10bits) / (4:4:4 8bits), 4K@30, UHD, 3D, Deep Color, and 1080p 24-bit color depth.
Audio Signals: DTS-HD Master Audio, Dolby TrueHD Dolby Digital,DTS, DVD-Audio, LPCM, SACD, MPCM
The SPLIT-HDM2-T4K-4 includes one unit: 4 Port SPLITTER with one(1) HDMI Input that can be up to 5m (16ft) and four(4)
output ports which allows the user to extend over HDMI cable video and audio up to 5m (16ft).
- INPUT: HDMI 2.0 /DVI 1.0 support
- INPUT 4K@60 HDR(4:2:0 10bits) / (4:4:4 8bits), 4K@30, UHD, 3D, Deep Color, and 1080p 24-bit color depth;
- HDCP 2.2 Compliance;
- COLOR SPACE: xvYCC, x.v.Color & Deep Color;
- VIDEO RESOLUTIONS: 480i@60Hz, 480p@60Hz, 576i@50Hz, 576p@50Hz, 720p@50/60Hz/3D,
1080i@50/60Hz,1080p @ 24Hz /50/60Hz/3D, ULTRA HD (3840x2160)@24/30/60Hz 4K (4096x2160)@24/30/60Hz
- PC RESOLUTIONS: 640x480@60Hz, 800x600@60Hz, 1024x768@60Hz, 1280x720@60Hz,
- 1280x768@60Hz, 1280x960@60Hz, 1280x1024@60Hz, 1360x768@60Hz, 1366x768@60Hz, 1400x1050@60Hz,
1600x900@60Hz,1680x1050@60Hz, 1920x1080@60Hz 1920x1200@60Hz ULTRA HD
(3840x2160)@24/30/60Hz 4K (4096x2160)@24/30/60Hz
- FREQUENCY RANGE: 25MHz~600MHz
- LINK TRANSMISSION: Up to 18Gbps (600MHz)
- DISTANCE: Up to 5meters (16ft) w 24AWG High Speed Ethernet HDMI Cable
- EDID: Multi mode selection & EDID learning from Display
- FIRMWARE: Update by mini USB connector
- PLUG & PLAY
NOTE: HDR- (High-dynamic-range imaging)
www.avenview.com Page 4
2.1 PACKAGE CONTENTS
Before you start the installation of the splitter, please check the package contents.
1SPLIT-HDM2-T4K-4 X 1
4
POWER ADAPTER 5V 2A X1
USER’S MANUAL X 1
2.2 BEFORE INSTALLATION
•Put the product in a level and stable location. If the product falls, it may cause damage or malfunction to components
within the casing.
•Do not place the product in temperatures under 0˚C or over 50˚C. High humidity may also cause the unit to malfunction.
•Use the DC power adapter with correct specifications supplied with the unit. If the improper power supply is used, this
may result in malfunction of the unit and may cause fire.
•Do not twist or pull by force the ends of the HDMI cable. It can cause malfunction.
2
3Mounting Brackets X 2
www.avenview.com Page 5
2.2 CABLE SPECIFICATION
We highly recommend achieving best results with our SPLIT-HDM2-T4K-4 you acquire a high quality 26 or 24 AWG HDMI
cable with the below specifications to maintain signal integrity and distances.
Features
•Full UHD 4K/ 60 to 18Gbps High Speed at up to 48 Bit
Deep Color
•UHD 4K/60 to 10.2 Gbps High Speed Deep Color up to 50ft
(Active Series), 25ft Passive
•Full HD Up to 1080p/60 up to 75ft
•True Professional grade heavy-duty 24 or 26 gauge oxygen-
free construction
•ProGrip connector utilizes up to 16 lbs of retention force to
help keep connector in place
•SureLength length indicators on the connector heads make
•it easy to organize for installations
•Available in 7 colors for easy cable identification
•Up to 32 audio channels and 21:9 aspect ratio
•Simultaneous delivery of dual video and audio streams
to multiple users
•Pro Grade Triple Shielding with 2x 100% coverage and 85%
Premium Tinned Copper Braid construction
•Ethernet Capable
•3D Ready
•Supports Deep Color and x.v. Color (Up to 48 Bit)
•5.1/7.1 Lossless Dolby TrueHD and DTS-HD Surround Sound
•Audio Return Channel & Lip-sync
•ATC Certified
•99.9% High Purity Copper Center Conductor
•Molded 24k Gold Plated HDMI male connectors on each end
•X-tra Flex CL3 rated jacket for easy installation
•RoHS Certified
•Lifetime Warranty
www.avenview.com Page 6
2.3 APPLICATION DIAGRAM
www.avenview.com Page 7
2.4 PANEL DESCRIPTION
2.4.1 INPUT PANEL (SPLIT-HDM2-T4K-4) Front Panel
1. LED INDICATOR:Illuminates RED when the supplied 5V 2A power adapter is plugged into AC wall outlet.
2. LED INDICATOR: When the source is connected to the unit and processing.
2.4.2 INPUT PANEL (SPLIT-HDM2-T4K-4) RearPanel
3. HDMI INPUT:HDMI Type B Female Connector for connecting HDMI compilant source.
4. HDMI OUTPUT: 1-4 port HDMI Type B Female Connector for connecting HDMI compilant display monitor.
1
2
34567
5.MINI USB :USB Type B Female Connector for Manufacturer Firmware upgrade.(Official use only).
6.EDID MODE: 0-F The 15 mode dial allows the user to easily sync between source, unit and display timings.
0 - F/W update mode
1 - EDID Ultra-HD(4K/UHD@60) - 24bit 2D & 7.1ch audio
2 - EDID Ultra-HD(4K/UHD@60) - 24bit 2D & 2ch audio
3 - EDID Ultra-HD(4K/UHD@30) - 24bit 2D & 7.1ch audio
4 - EDID Ultra-HD(4K/UHD@30) - 24bit 2D & 2ch audio
5 - EDID Full-HD(1080p@60) - 24bit 2D & 7.1ch audio
6 - EDID Full-HD(1080p@60) - 24bit 2D & 2ch audio
7 - EDID Full-HD(1080p@60) - 24bit 3D & 7.1ch audio
8 - EDID Full-HD(1080p@60) - 24bit 3D & 2ch audio
9 - EDID Full-HD(1080p@60) - 36bit 2D & 7.1ch audio
A - EDID Full-HD(1080p@60) - 36bit 2D & 2ch audio
B- EDID HD(1080p@30)/1080i@60/720p@60)-24bit 2D & LPCM7.1ch/Dolby Digital
C - EDID HD(1080p@30/1080i@60/720p@60) - 24bit 2D & 2ch audio
D - Auto EDID analysis learning mode
E - Learn EDID from output1(DEFAULT)
F - Learn EDID from output 4
7.POWER JACK:Power Soucre connection
