AVAPOW
Multi-function car jump starter
-User Manual-
Model: A27 EN
Friendly Tips:
Please read carefully the instruc-
tion manual so that you can be
familiar with the product more
conveniently and quickly!Please
use product correctly based on the
instruction manual.
Perhaps there is small difference
between the picture and the actual
product,so please turn to the
actual product for detail informa-
tion.
01
What's in the box
Specifications
AVAPOW jump starter x1
Intelligent battery clamps with starter cable x1
High quality type-C charging cable x1
User-friendly manual x1
Storage bag x1
Model number
Capacity
EC5 output
USB1 output
USB2 output
Wireless charging output
Type-C input
Micro input
Charging time
LED light power
Working temperature
Dimension (LxWxH）
80.66Wh
A27
12V/2500A maximum starting power (max.)
5V/3A, 9V/2A, 12V/1.5A
5V/2.1A
5W/7.5W/10W MAX
5V/2A, 9V/2A
5V/2A
5-8 Hours
White: 1W
-20 ℃~+60 ℃ / -4℉~+140℉
209*107*56.4mm
03
Product diagrams
Accessories
Power button
USB1: 5V/3A, 9V/2A, 12V/1.5A
USB2: 5V/2.1A
Micro input: 5V/2A
Type-C input: 5V/2A, 9V/2A
LED display
Wireless charging
EC5 jump start output
LED light
Light button
Intelligent battery clamps with starter cable High quality type-C
charging cable
1
2
3
4
5
6
7
8
9
10
1
10
4
23
59
6
78
04
LED display
Wireless charging
EC5 jump start output
LED light
Light button
Charge the Jump Starter battery
LED display
Charging with an AC adapter (Note:AC adapter
is not included).
1.Connect the battery input with Type-C cable.
2.Connect the Type-C cable to AC adapter.
3.Plug the AC adapter into a power source.
AC adapter
Input
Type-C cable
100
Press the power button,the LED display shows as follows:
Show available battery
05
How to Jump Start Your Vehicle
This unit is designed for jump starting 12V car batteries only and rated for
gasoline engines up to 8 liters and diesel engines up to 8 liters. Do not
attempt to jump start vehicles with a higher battery rating, or different
voltage.If the vehicle isn't started immediately, please wait for 1 minute to
allow device to cool down. Do not try to restart the vehicle after three
consecutive attempts as this may damage the unit. Check your vehicle for
other possible reasons why it can't be restarted.
First step: Second step: Third step: Fourth step:
Press the power
button to turn on
it,check the
battery shown on
the LED
display,then plug
jumper cable into
battery pack
outlet.
Connect the
jumper clamp to
car battery,red
clamp to
positive,black
clamp to negative
pole of car battery.
Turn on the car
engine to start
car.
Pull the plug of
battery terminal
from jump starter
and remove
clamps from auto
battery.
Operating instructions
06
Jumper Clamp Indicator Instruction
Input low
voltage
protection
14.0V±0.5V
17.5V±0.5V
When the power of the jump starter is too
low, after connecting the starter and the
car，the " " symbol is on, the buzzer
sounds once every 1 second, and the
current voltage of the starter power is
displayed.
Input high
voltage
protection
Short
circuit
protection
Support
Support
Reverse
connection
protection
Support
When the red/black clips of the wire clip is
reversely connected to the car battery
(battery voltage ≥0.8V), the " "symbol is on,
the " "symbol flashes, the buzzer sounds
once every 1 second.
Multi-frequency
protection
Work instruction
Support
Support
Standby
instruction
Car battery
voltage
detection
8 times
When working normally, display the voltage
of the current jump starter.
When the wire clip is only connected to the
car battery (the car battery voltage needs to
be ≥8V), the" " symbol is on, and the
current car battery voltage is displayed.
Item Technical
parameters Instruction
When the car voltage is too high, after
connecting the starter and the car,the "
" character flashes and the buzzer beeps for
a long time.
When the red and black clips are
short-circuited in the standby state,
the " "symbol is on, the " "symbol
flashes,the buzzer sounds once every 1
second.
When start up to 8 times continuously,the
" "symbol flashes.
The" " symbol circulate instructions
from left to right.
07
How to charge a mobile phone or digital
products?
Operating instructions:
With powerful capacity and two USB output ports (one is USB Quick
Charge-5V/3A,9V/2A,12V/1.5A), it can full charge your smart phones and
tablets up to 75% faster than a standard charger. It also provides wireless
charging function (5W/7.5W/10W MAX), making it’s more convenient to
charge your wireless charging phones! You can charge three devices at
the same time.
① ② ③ ① ② ③
Press the power button-->con-
nect the phone and power
bank output port-->charging
Press the power button-->put
the phone on wireless
charging area-->charging
08
LED flashlight
sos
Short press the Light Button to turn on the flashlight.The battery capacity
indicator lights up.Short press the light button again to scroll through the
lighting,Strobe,SOS.Short press again to turn off the flashlight.The
flashlight offers more than 35 hours of continuous use when fully charged.
Lighting Strobe light SOS off
Press the Light
Button shortly
Press the Light
Button shortly
Press the Light
Button shortly
Press the Light
Button shortly
LED Flashlight Light Button
09
Warranty Exemption
Safety Warning
1. Never short circuit the jump starter by connecting the Red and Black
clamps.
2. Do not disassemble the jump starter.
3. If you find swelling,leakage or odor,please stop using the jump starter
immediately.
4. Please use this starter at normal temperature and keep away from
humid,hot and fire places.
5. Do not start the vehicle continuously.There should be at least 30
seconds to 1 minute between two starts.
6. When the battery power is less than 10%,do not use the jump starter
otherwise the device will be damaged.
7. Before first use please charge it for 3 hours or more.
8. If the positive clamp of the starting power was incorrectly connected to
the negative poles of the car battery,the product comes with relevant
protective measures to avoid personal injury and property damage.
1. The product has been incorrectly operated or damaged due to the
following irresistible reasons (such as flood,fire,earthquake,
lightning,etc).
2. The product has been repaired,disassembled or modified by
non-manufacturer or non-manufacturer authorized technicians.
3. The problem caused by wrong charger does not match the product.
4. Beyond the product warranty period(24-month).
Note:
- For the first use, please make sure to fully charge before use.
- In normal use, please confirm that the unit has at least 50% power
before use.
