AV-0017-MUW Rv000
User Manual aSmart Lite aSL.1503
2
·Manual Mode, the heating system will start operating when the room temperature is lower or equal to the set point temperature.
To set the desired temperature press the up and down arrows keys.
·Automatic Mode, it works in a similar way to manual mode, but in this case it operates according to the timing set in the
heating submenu within the home menu. To access to the heating submenu, press MENU , and with the up and down
keys you will set the 1st, 2nd and 3rd cycles, as well as the day, the set point temperature and the timeslot. To pass
from one field to another one, use the use the right and left arrows keys.
You will be able to know room temperature of your house and adjust both the operation mode and the desired temperature
through the phone. (See aSmart Lite through the phone).
ALARMS
Intruder Alarm
To activate the alarm, press ALARM . The waiting time until the alarm activation will not begin to count down if the system still
detects any movement. Once this time has finished, whenever someone goes into the house they must press ALARM and enter
the 4 digit pass code to deactivate the alarm.
Before putting into operation the alarm, we would recommend that you program and set its operation configuration. To do so,
access to the menu MENU and using the up and down arrows keys select the alarms function.
In the alarms submenu, within the intrusion option, you can configure the following aspects:
·Sensitivity, this is very useful in cases when aSmart Lite is installed near a source of heat or cold, or where there are pets
which could occasionally cause false alarms. The default setting is the maximum sensitivity/range (10). This sensitivity can
be reduced to 0, this means that the sensor would have to be triggered various times before the alarm is activated.
·Seconds in wait, this is the time that you will have to leave the house. This is also the time that you will have to deactivate
the alarm when you go into the house.
·Internal siren, this allows you to disable the siren function inside the house. To do so, use the up and down arrows
keys.
Fire Alarm
To activate or deactivate the fire alarm access to the home menu MENU and using the up and down arrows keys you
will select the alarms function, and then within the alarms submenu the fire option. To activate or deactivate this alarm use
the up and down arrows keys.
Power failure alarm
To activate or deactivate the power failure alarm access to the home menu MENU and using the up and down arrows
keys you will select the alarms function, and then within the alarms submenu the power
To activate or deactivate this alarm use the up and down arrows keys.
By means of this alarm aSmart Lite system alerts you when there is a power failure in your house. It also alerts you when the
power supply is restored.
Warning telephones
In the alarms menu, you can set the telephone numbers that you would like aSmart Lite to call in the event of an alarm (your
mobile, the telephone number of a neighbor, or a family member).
According to current legislation, emergency calls are not allowed; aSmart Lite will call to residential telephone numbers
aSmart Lite will call to the first telephone number previously set, and in the event the telephone line it is not connected or there
is no network coverage it will call the next one, the same way up to a maximum of 5 times. When you receive the call, the
system will send "intrusion alarm", "fire alarm" or "power failure alarm" depending on the alarm event.
In case of an intrusion by pressping (#) icon on your telephone, aSmart Lite will provide you with a list of options:"Change
mode, "Listening mode", "Talking mode", "Disable Warnings" (see aSmart Lite through your telephone). If you want to disable
your pending alerts to the previously selected numbers you select the option "Disable Warnings" (option 4). In any other alarm
situation, by pressping (#), aSmart Lite will provide you with a unique option "Disable Warnings" (option 4).
MESSAGES RECORDER
aSmart Lite includes a recorder, useful for leaving recorded messages for a family member to access later. It operates in a
similar way to a conventional recorder.
To record a message, press the MENS key and then REC . To record more messages, simply repeat the operation.
A blinking green light will show you that there are unread messages. If the recorder contains read messages the green light
will remain on. By pressing the MENS key you directly access to the messages menu and by pressing the OK key you will
be able key to play them, by pressing the DEL key you will delete them.
The time and date when they were recorded will be displayed on the screen. To move from one message to another, use the
right and left arrows keys.
ANSWERING MACHINE
The answering machine menu is composed of 3 submenus: Number of rings, Ring volume and Outgoing messages.
In order to ensure correct operation of the answering machine, it will be necessary to configure the number of rings before
your answering machine picks up in the same way it will necessary to record the outgoing message you would like to use.
When the answering machine of your telephone service provider's is enabled, the number of rings of the aSmart Lite answering
machine should be set below the number of rings configured for your telephone service provider's or the answering machine
of your telephone service provider's is should be disabled.
You can adjust the ring volume to the sound level of the aSmart Lite telephone ring.
In the Outgoing message option, press MENU key and then press REC key to record your greeting message
(e.g.: you have called 666.22.33.44 please leave your message after the tone, thank you)
You can listen to the message you have recorded by pressing MENU key.
