Instruction Manual
VWR®CONTROLLER VACUUM VC100
Version01 Issue 3/ 10/2023
2
Legal address of Manufacturer
United States
VWR International LLC
100 Matsonford Rd
Radnor, PA 19087
+1 800-932-5000
www.vwr.com
Country of Origin
China
3
Table of Contents
1. SAFETY PRECAUTIONS...............................................................................................4
2. PRODUCT OVERVIEW .................................................................................................5
2.1 SCOPE OF APPLICATION............................................................................................................ 5
2.2 TECHNICAL PARAMETERS .........................................................................................................5
2.3 COMPONENTS ....................................................................................................................... 6
3. OPERATING INSTRUCTIONS..................................................................................... 7
3.1 OPEN-PACKAGE INSPECTION .................................................................................................... 7
3.2 OPERATION............................................................................................................................8
4. MAINTENANCE............................................................................................................ 15
5. FAILURE DIAGNOSIS .................................................................................................16
6. WARRANTY POLICY ..................................................................................................17
4
1. Safety Precautions
Caution!
•Please carefully read the manual before operating the product, and
observe the specifications on safe operation.
•Ensure that only trained staff operates this product.
Ground protection for safety!
•Ensure that the power socket has been properly grounded before
operating the product
•Ensure that the label indicated the correct voltage before connecting the device to
power supply.
•Ensure good working environment free of explosive, hazardous and inflammable
substances. This product is intended for indoor use only.
•The instrument should be placed in a low humidity, well ventilated, less dust, water
free environment without the perpendicular incidence of sunshine and intense light
source. The environment should be free of corrosive gases or strong magnetic
interference, and far away from heating gas, fire and all other heat sources.
•Ensure that the instrument and its accessories are free of any potential defects.
•Ensure that the instrument is secured tightly and standard accessories supplied by
the manufacturers only should be used.
•Wear proper protective equipment while operating this instrument to prevent the
potential dangerous circumstances with the risk of splashing/ release of toxic or
inflammable gases.
•The power cable must be kept away from the surface of heating module rather than
shield the device.
•Please prevent water from splashing on the electrical elements of the product.
•The power supply is fully disconnected only if the power plug is pulled out.
•Before assembly, disassembly, cleaning or maintenance, the main power plug must
be pulled out.
•Ensure the vacuum pump’s power is not more than the maximum power output
by the instrument.
5
2. Product overview
2.1 Scope of application
•The instrument is designed for the application environments with
dedicated independent power supply, such as schools, laboratories and factories.
It is applied to control the vacuum level of the vacuum system with gas as the
medium in the environments, under the circumstance as below.
•Ensure that the voltage fluctuation does not exceed normal value by ±10%.
•Ensure to place the instrument at 30cm away from the wall and at least 10cms
away from any other instruments.
•The product is not intended for use in residential areas.
>300mm
>100mm
Fig. 2.1
2.2 Technical parameters
Setting range of vacuum
1- 1000mbar
Determination range of
vacuum degree
1- 1000mbar
Control operation mode
Single-point control operation mode, program
operation mode
Control program
Can save up to 5 programs.
Each program contains five-step control (vacuum
degree and timing can be set).
Setting mode
Touch screen setting
Display screen
5-inch TFT
Sensor overload pressure
1500mbar
Connecting t u b e interface
diameter
6.2mm
6
Materials in co n t ac t wi t h
steam
PTFE, PP, silica gel and ceramics
Steam temperature
5℃-40℃
External
WxDxH
dimension
189mm×207mm×193mm
Weight
4.0kg
Input power supply
AC110—240V, 50Hz/60Hz
Working temperature
10℃-40℃ , ≤80%RH ，the altitude does not exceed
2000 meters
Pollution levels
2
Input power
600W
Maximum output power
500W (220V), 300W(110V)
2.3 Components
Three-in-one switch
Touch screen
Air vent
Power
socket
Fig. 2.3.1
Fig. 2.3.2
Name
Description
Touch screen
Setting parameters and displaying settings and
operation information
Three-in-one
Unit power input, with a switch controlling the
Pump interface
Communication
Load interface
interface
output
7
switch
power supply to the entire unit.
Communication
interface
Communication
Pump interface
Connects the vacuum pump
Air vent
Connects with air or inertia gas if necessary.
Load interface
Connects the load, such as revolving evaporator.
Power output
socket
Provides power supply to vacuum pump.
Table 2
3. Operating instructions
3.1 Open-package inspection
Open-package inspection aims to confirm the completeness of associated parts. The
packing list is given below.
Name
Qty.
Main unit
1
Power line
1
Operating Instructions
1
Table 3
If you find any damage on the packing, please specify the damage after receipt. If you
find any internal damage after unpacking, please contact your local supplier or
manufacturer.
Note:
If you find any visible damage on the product, please don’t connect the
product to power supply.
8
3.2 Operation
3.2.1 Instrument preparation
•The instrument should be place on a stable surface and well ventilated without any
flammables or explosives.
•Ensure that the label indicated the correct voltage before connecting the device to
power supply.
•Ensure that the power socket is grounded properly.
•Connects the lines of the instrument, vacuum pump and load properly.
•Connects the power cable of the vacuum pump to the instrument and turn ON the
vacuum pump switch.
•Connect the power cable of the instrument properly, and turn ON the Power switch.
3.2.2. Startup interface description
Fig. 3.2.1
Button name
Function introduction
VENT
Gently touch VENT to vent air and lift it to stop
venting.
PROGRAM
Choose the control mode and set the control pressure
value and running time.
SETTINGS
Set the delay time to open and close the pump
and valve, set the local atmospheric pressure, adjust
the
pressure sensor calibration parameters.
START
Gently touch it to start the control program, with the
9
icon changed to
the control program.
, gently touch it again to stop
Table 4
Note:
‘PROGRAM’ and ‘SETTINGS’ buttons cannot be operated if the control
program starts.
10
3.2.3. Instrument configuration
Gently touch the "SETTINGS" button to pop up the password soft
keyboard, enter the password (the default initial password is 6666), then
press “enter” key, confirm the password is correct and then pop up the
setting interface, as shown in the figure below.
Fig. 3.2.2
Name
Function introduction
Pump Delay(ms)
The delay time after opening or closing the vacuum
pump.
Valve Delay(ms)
The delay time after opening or closing the solenoid
valve (inside the instrument).
K B
Pressure sensor calibration parameters
P0(mbar)
Local atmospheric pressure value
Reset
Restore the factory settings
Table 5
After setting, click “OK” key to return to the startup interface.
Note:
Before clicking the “ Reset” button, record the pressure sensor calibration
parameters (K and B). After restoring the default setting, write (K and
B) into the instrument, otherwise the pressure measurement accuracy will
be adversely affected.
,
