Avalon Bay 100B Manuel utilisateur

http://www.avalon-bay.com Customer Care Number: 1-844-528-2566

Food Sealer

(100B)

Avalon Bay Food Sealer Product Guide

http://www.avalon-bay.com

Introduction

Thank you for buying this top quality food sealer.

Before using your food sealer, please read this manual carefully.

Incorrect operation can result in serious damage or injury.

Need to Contact Us?

WEBSITE:

http://www.avalon-bay.com

SUPPORT EMAIL ADDRESS:

[email protected]

TELEPHONE NUMBER:

1-844-528-2566

Thank You for Choosing the Avalon Bay Food Sealer

Please read this manual thoroughly and follow all instructions and safety guidelines. With proper

care and maintenance, this appliance will provide you with many years of trouble-free use.

For future reference, we recommend you attach a copy of your sales receipt below and record the

following information, located on the manufacturer’s nameplate on the rear of the unit. You will

need this information if it becomes necessary to contact the manufacturer for service inquiries.

Date of Purchase:

Serial Number:

Model Number:

Avalon Bay Food Sealer Product Guide

http://www.avalon-bay.com

Contents

Introduction .................................................................................................................................................. 2

Need to Contact Us? ........................................................................................................................ 2

Product Specifications................................................................................................................................... 3

Important Safety Precautions ....................................................................................................................... 4

Key Features of Your New Food Sealer......................................................................................................... 5

Main Parts of Your New Food Sealer ............................................................................................................ 6

How to Make Custom Sized Bags.................................................................................................................. 8

How to Vacuum Seal with the Vacuum Bags ................................................................................................ 9

How to Use the Seal Button........................................................................................................................ 10

Care and Cleaning ....................................................................................................................................... 11

Troubleshooting.......................................................................................................................................... 12

Service Instructions..................................................................................................................................... 14

Limited Manufacturer’s Warranty .............................................................................................................. 15

Warranty Terms ............................................................................................................................. 15

Product Specifications

VOLTAGE:

110V

WATTAGE:

140W

DIMENSIONS:

10” x 6” x 2”

VACUUM DEGREE:

-0.4 ~ 0.60 bar

Avalon Bay Food Sealer Product Guide

http://www.avalon-bay.com

Important Safety Precautions

Read and fully understand all instructions and warnings prior to using

this machine. Your safety is most important!

Danger

•Read the instructions carefully.

•Do not allow the appliance to be used as a toy.

•This appliance should not be operated by children.

•Do not operate the appliance with a damaged power cord or plug.

•Do not use the appliance on a wet or hot surface, or near a heat source.

•Always use the appliance on a level surface.

•Do not immerse any part of the appliance, power cord, or plug into water or other liquid.

•To disconnect, unplug the power cord from the electrical outlet. Do not disconnect by pulling

on the cord. Always unplug the appliance before cleaning and when not in use.

•Do not operate the appliance if it malfunctions or is in any way damaged. If the cord or the

machine is damaged, please return it to our service department for proper service, replacement,

or repair.

•Close supervision is required when this product is used near children.

•This appliance is not for commercial use. If sealing more than 20 bags continuously, wait at least

25 minutes before resuming use of your appliance.

•Keep the upper lid of the appliance unlocked when not use.

This appliance is for HOUSEHOLD USE ONLY.

Do not attempt to service this product. Service should be performed

by an authorized service representative.

Caution

A short power supply cord is provided to reduce the risk resulting from becoming entangled in or

tripping over a longer cord. Extension cords are not prohibited from being used when care is exercised

in their use. When an extension cord is used, the marked electrical rating of the extension cord shall be

no less than the marked electrical rating of the appliance. The longer cord shall be arranged so that it

does not drape over the counter top or table top where it is capable of being tripped over, snagged, or

pulled on unintentionally, especially by children.

Avalon Bay Food Sealer Product Guide

http://www.avalon-bay.com

Key Features of Your New Food Sealer

•Most compact design ever.

•Wide sealing line prevents air leakage and keeps high vacuum degree for a longer time.

•Press the left and right side of lid at the same time to vacuum.

•Press the button in the middle to release/open the lid after vacuuming and sealing.

•Pre-seal the vacuum bag any time when vacuuming.

•Sealing width: MAX 8 inches.

Avalon Bay Food Sealer Product Guide

http://www.avalon-bay.com

Main Parts of Your New Food Sealer

Avalon Bay Food Sealer Product Guide

http://www.avalon-bay.com

LID

Press the left and right side at the same time to vacuum and seal.

RELEASE BUTTON

When vacuuming and sealing are done, press this button to release and open lid, then bag

can be taken out.

SEAL BUTTON

Is used when pre-sealing is needed. When is vacuuming delicate foods, or foods with liquid,

press this button with your thumb while pressing the lid, to stop vacuuming and seal the bag

immediately.

INDICATOR LIGHT

1. When the machine is vacuuming, the blue indicator light is on.

2. When the machine is sealing, the blue indicator light blinks.

SEALING BAR

Do not tear the high temperature resistant tape away.

SEALING FOAM RING

Make sure the open end of bag is inside this area when vacuuming.

CIRCUIT SWITCH

When the lid touches this switch, the machine starts to vacuum. Please do not touch this

switch when the lid is open.

SEALING FOAM

SEALING SILICONE

POWER CORD STORAGE

Avalon Bay Food Sealer Product Guide

http://www.avalon-bay.com

How to Make Custom Sized Bags

•Pull enough bag material to hold the item to be vacuum packaged, plus two inches (2”). With a

pair of scissors or sharp knife, cut desired bag length from bag roll. Make sure to cut in a

straight line. Plug in power cord.

•Open lid. Place one end of cut bag onto sealing bar. Please make sure this end is not on or

inside the sealing foam ring area.

•Close lid by pressing down on both sides. Now keep pressing until the light goes off, or you can

use your left thumb to press the “SEAL” button to make an instant sealing.

•The machine is sealing the bag when the blue indicator light blinks.

•Once completed, the indicator light will turn off. Stop applying manual pressure, and press the

“RELEASE” button to open the lid. The custom sized bag is now ready for vacuum sealing.

CAUTION: Make sure you give the appliance time to cool down. Wait

at least 20 seconds between seals. Under very heavy usage, appliance

will shut off automatically to prevent overheating. If it does, wait 25

minutes to allow appliance to cool off.

Avalon Bay Food Sealer Product Guide

http://www.avalon-bay.com

How to Vacuum Seal with the Vacuum Bags

•Place the item(s) to be sealed into the pre-cut or custom sized bag. Leave at least two inches

(2”) between the contents and the top of the bag to allow for bag contraction.

•Open lid and place the open end of the bag down into the vacuum chamber.

•Close lid by pressing down on both sides. Keep pressing both sides of the lid to vacuum and

seal.

•Once the indicator light has turned off, press the “RELEASE” button to open lid and take out the

bag with food well packed.

Avalon Bay Food Sealer Product Guide

http://www.avalon-bay.com

How to Use the Seal Button

This button is used when vacuum packing delicate food, or food with liquid, or in any other cases that

pre-sealing is needed. While the machine is vacuuming the bag, press this button with your left thumb

while your hands are still pressing both sides of lid. Then the machine stops vacuumizing and starts

sealing, at this time, the blue indicator light blinks. When the light goes off, take your hands off the lid

and the pre-sealing is done.
