Avalla T-5 Manuel utilisateur
Steam Mop
T-5 T-9 T-20
Read this manual carefully before use and keep it for future
reference. Failure to do so may result in injury, property
damage and may void the warranty.
avalla.com
02 En
Contents
02 Contents
04 Quick start guide: T-5
• Parts guide
05 • Assembly and operation
05 • Accessories
06 Quick start guide: T-9
• Parts guide
07 • Assembly and operation
07 • Accessories
08 Quick start guide: T-20
• Parts guide
09 • Assembly and operation
10 Health and safety
• General safety instructions
• Disposal
12 Troubleshooting
12 Specications
03En
04 En
Quick start guide: T-5
Parts guide
Carpet
glide
Large
brush
Angled
nozzle
Head
adapter
Mop
pad
Focused
scraper
Flat
brush
Window
head Micro
head
Accessory
adapter
Small
brush
Filler
cup
01. Handle
02. Power cable tidy
03. Telescopic extension
04. Telescopic catch
05. Body
06. Power button
07. Filler port
08. Water tank
09. Steam head
10. Carpet glide
01 02
08
05
03
10
04
06
07
09
05En
Assembly and operation Accessories
• Slot the handle over the
telescopic extension and click
into place.
• Slot the telescopic extension
and steam head into the body.
• Attach a mop pad to the
underside of the steam head.
• Openthellerport.Usingthe
llercup,llthewatertankto
themaxline.Closetheller
port.
• For carpet cleaning, clip on the
carpet glide.
• Power on the unit and allow it
to reach temperature.
The body can be detached
from the telescopic extension
and steam head, becoming
a portable and versatile
steam cleaner with a range of
accessories.
Slot the accessory adapter into
the body. The head adapter can
be used with either the micro
head or window head.
The accessory adapter is used
for all brushes, the nozzle and
scraper attachments.
Warning: Make sure the unit
is fully cooled and unplugged
from the mains before swapping
parts. Make sure attachments
are securely locked in place
before use.
06 En
Quick start guide: T-9
Parts guide
Carpet glide
Large
brush
Angled
nozzle
Head
adapter
Mop pad
Focused
scraper
Flat
brush
Window
head Micro
head
Accessory
adapter
Small
brush
01. Handle
02. Power cable tidy
03. Telescopic extension
04. Telescopic catch
05. Body
06. Power button
07. Filler port
08. Water tank (removable)
09. Temperature dial
10. Steam head
11. Carpet glide
01
02
08
05
03
11
04
06
07
09
10
07En
Assembly and operation Accessories
• Slot the handle over the
telescopic extension and click
into place.
• Slot the telescopic extension
and steam head into the body.
• Attach a mop pad to the
underside of the steam head.
• Detach water tank. Open the
llerportandllthewater
tank to the max line. Close the
llerport.
• Adjust the steam temperature
using the temperature dial.
• For carpet cleaning, clip on the
carpet glide.
• Power on the unit and allow it
to reach temperature.
The body can be detached
from the telescopic extension
and steam head, becoming
a portable and versatile
steam cleaner with a range of
accessories.
Slot the accessory adapter into
the body. The head adapter can
be used with either the micro
head or window head.
The accessory adapter is used
for all brushes, the nozzle and
scraper attachments.
Warning: Make sure the unit
is fully cooled and unplugged
from the mains before swapping
parts. Make sure attachments
are securely locked in place
before use.
08 En
Quick start guide: T-20
Parts guide
01. Handle
02. Power button
03. Power cable tidy
04. Body
05. Temperature display
06. Water level window
07. Steam head
08. Filler port
01
02
03
04
05
06
08
07
09En
Assembly and operation
• Ensure the unit is unplugged
from the power supply.
• Slot the handle into the body
and clip into place.
• Attach a mop pad to the
underside of the steam head.
• Openthellerport.Usingthe
llercup,llthewatertankto
themaxline.Closetheller
port.
• For carpet cleaning, clip on the
carpet glide.
• Press the power button once
to turn on to high power. Press
again for max power. Press
once more to power off.
For carpet cleaning, clip on the
carpet glide.
High power mode:
Produces high levels of steam up
to 120ºC
Max power mode:
Produces the maximum amount
of steam for intense cleaning.
Mop pad installation.
10 En
Health and safety
General safety instructions
The following must always be observed for safety
Warning: Danger of scalding. The steam emitted from the appliance is very hot
and may cause scalding. Please use caution when using the appliance.
• This appliance is not intended to be used by children, keep it away from
children. Persons with lack of experience or knowledge, reduced physical,
sensory, or mental capabilities, can use this appliance if they have been given
supervision or instruction concerning use of the appliance in a safe way.
• When in use never turn the appliance over on its side or direct steam toward
people, pets or plants.
• Component parts must only be replaced with identical repair parts.
• The appliance must be disconnected from its power source during servicing,
cleaning or when not in use. Do not use chemicals to clean the appliance.
• Always operate the unit from power outlet of equal voltage, frequency and
ratingasindicatedontheproductidenticationplate.
• Do not operate with wet hands. Be careful not to allow any sources or water,
moisture, or any other liquids to come into contact with any areas of the unit
other than the water tank and steam outlet.
• Do not leave the unit running unattended. Do not unplug the unit while it is in
operation.
• Do not put any objects into the steam nozzle openings. Discontinue use if the
steam nozzle is blocked.
• Do not unplug by pulling on the power cord, use cord as a handle, close a door
on cord, or pull cord around sharp edges or corners. Do not run the appliance
over the cord. Keep the cord away from heated surfaces.
• Do not put objects on the unit, climb or sit on the unit.
• Do not operate the unit if it is dropped, damaged or showing signs of product
malfunction.
• The unit must be installed in accordance with national wiring regulations.
• The appliance must be stored in a manner to prevent mechanical damage.
• Do not place in direct sunlight or near objects that may cause mechanical
vibration or shock.
• Donotusetheappliancewherecombustible/ammablegasesorvapoursare
present.
• Do not use the appliance outdoors, it is designed only for indoor use.
• Do not use for space-heating purposes.
• Do not put hands or feet under the appliance. It gets very hot.
• Do not use on leather, wax-polished furniture, synthetic fabrics, velvet, or other
delicate, steam-sensitive materials.
Symbols from the unit, packaging and instruction manual
Read the
instruction
manual
UK
Conformity
Assessed
European
Conformity
Class I
Construction
(Earthed)
Ingress protection
rating. Resistant
to water splashing
against the
enclosure from any
direction shall have
no harmful effect.
WEEE - Waste
Electrical & Electronic
Equipment. Do not
dispose of Waste
Electrical & Electronic
Equipment in with
domestic rubbish.
