Autronica AutroGuard Retro Manuel utilisateur

utronica Fire And Security AS

AutroGuard Retro

Used as spare part replacement for

AutroSafe detectors

, ,

AutroGuard Retro used as spare part replacement for AutroSafe detectors_eng , Doc-1016807-1, 2024-01-09,

Autronica Fire and Security

This publication, or parts thereof, may

not be reproduced in any form, by any

method, for any purpose.

Autronica Fire and Security AS and its

subsidiaries assume no responsibility

for any errors that may appear in the

publication, or for damages arising from

the information in it. No information in

this publication should be regarded as a

warranty made by Autronica Fire and

Security AS. The information in this

publication may be updated without

notice.

Product names mentioned in this

publication may be trademarks. They

are used only for identification.

E-1676

This product contains static-sensitive devices. Avoid any electrostatic discharge.

The WEEE Directive

When the marking below is shown on the

product and/or its literature, it means that

the product should not be disposed with

other household wastes at the end of its

life cycle. During waste treatment, disposal

and collection, please separate the

product from other types of wastes and

recycle it responsibly to promote the

sustainable reuse of material resources.

This product should not be mixed with

other commercial wastes for disposal.

Table of Contents

, , AutroGuard Retro used as spare part replacement for AutroSafe detectors_eng , Doc-1016807-1, 2024-01-09,

Autronica Fire and Security AS

Page 3

Table of Contents

1. Introduction......................................................................2

1.1 Replacement and Compatibility ........................................................ 2

1.2 Lifetime of AutroGuard Retro ............................................................ 3

1.3 The Manual ....................................................................................... 3

1.4 Target Audience ................................................................................ 3

1.5 Downloading Technical Documents .................................................. 3

2. Replacing AutroSafe detectors installed in

standalone bases ..................................................................4

3. Replacing AutroSafe detectors installed in conduit

boxes......................................................................................5

4. Replacing AutroSafe detectors installed in

ventilation duct adapters ......................................................6

5. Situations where AutroGuard Retro is not suitable

as spare part..........................................................................7

Introduction

AutroGuard Retro used as spare part replacement for AutroSafe detectors_eng , Doc-1016807-1, 2024-01-09,

Autronica Fire and Security

Page 2

1. Introduction

1.1 Replacement and Compatibility

AutroGuard Retro is a 1:1 replacement for all AutroSafe detectors

when replaced with the matching AutroGuard Retro variant. When

used with the panel versions below there is no need to change the

base, update the firmware or change the configuration.

AutroGuard Retro is compatible with:

AutroSafe 3 version 3.6 and higher

AutroSafe 4 all versions

Autroprime all versions

AutroSafe Detector

AutroGuard Retro Spare part variant

116-BDH-200

116-BDH-200/SPARE

116-BDH-300

116-BDH-300/SPARE

116-BDH-500

116-BDH-500/SPARE

116-BDH-500/EX 116-BDH-500/EX/SPARE

116-BDH-500/N

116-BDH-500/N/SPARE

116-BHH-200

116-BHH-200/SPARE

116-BHH-220

116-BHH-220/SPARE

116-BHH-300 116-BHH-300/SPARE

116-BHH-320

116-BHH-320/SPARE

116-BHH-500

116-BHH-500/SPARE

116-BHH-500/EX

116-BHH-500/EX/SPARE

116-BHH-500/N 116-BHH-500/N/SPARE

116-BHH-500/S

116-BHH-500/S/SPARE

116-BHH-500/S/EX

116-BHH-500/S/EX/SPARE

116-BHH-500/S/N

116-BHH-500/S/N/SPARE

116-BHH-520 116-BHH-520/SPARE

116-BHH-520/EX

116-BHH-520/EX/SPARE

116-BHH-520/N

116-BHH-520/N/SPARE

Introduction

AutroGuard Retro used as spare part replacement for AutroSafe detectors_eng , Doc-1016807-1, 2024-01-09,

Autronica Fire and Security

Page 3

1.2 Lifetime of AutroGuard Retro

Autronica Fire and Security follow the same strategy for AutroSafe

detectors as for most other products, that is minimum 10 years of

service and spare parts availability.

AutroGuard Retro is a spare part for AutroSafe detectors, we will as

minimum provide spare parts until 2033. There is no current plan for

end of life of AutroGuard Retro.

NOTE:

Autronica reserves the right to supply a technological equivalent

product based on the general technological market development and

raw component availability to maintain the service period.

1.3 The Manual

Ensure that this manual is read and understood before

installing/operating/maintaining the equipment.

1.4 Target Audience

The handbook is intended to be used by project engineers and

qualified service and technical personnel who are responsible for the

installation, commissioning and maintenance.

1.5 Downloading Technical Documents

All relevant technical documents can be downloaded from the

Autronica product web at www.product.autronicafire.com/products

Replacing AutroSafe detectors installed in standalone bases

AutroGuard Retro used as spare part replacement for AutroSafe detectors_eng , Doc-1016807-1, 2024-01-09,

Autronica Fire and Security

Page 4

2. Replacing AutroSafe detectors

installed in standalone bases

BWA-100 Standard base

BWA-101 Base with microswitch

BWA-100/X1 Base with BBR-52 sounder
