Power Supplies
P3-01AC $147.00
There are two power supplies available;
both provide isolated 24VDC, 5VDC,
and 3.3 VDC to the Productivity3000
bases.
The P3-01AC input power supply requires
power from an external 100–240 VAC
source.
The P3-01DC input power supply
requires power from an external 24–48
VDC source.
No Power Budgeting
No power budgeting is required with
either power supply. Any combination of
I/O modules may be installed in any slots
without power budget considerations.
P3-01AC
Terminal Block Specifications
Number of Positions 4 Screw Terminals
Pitch 0.3 inch (7.62 mm)
Wire Range 22–14 AWG (0.324 to 2.08 sq. mm) Solid Conductor
22–14 AWG (0.324 to 2.08 sq. mm) Stranded Conductor
3/64 inch (1.2 mm) insulation maximum
Screw Driver Width 1/4 inch (6.5mm) maximum
Screw Size M3 size
Screw Torque 7–9 inch-pounds (0.882 - 1.02 N·m)
P3-01AC User Specifications
Input Voltage Range (Tolerance) 100 to 240 VAC (-15% / +10%)
Rated Operating Frequency 50 to 60 Hz with ± 5% tolerance
Maximum Input Power 72W
Cold Start Inrush Current 12A 3mS
Maximum Inrush Current (Hot Start) 12A 3mS
Input Fuse Protection (Internal) Micro fuse 250V, 2A, slow blow
Non-replaceable
Efficiency 83%
Output
24VDC @ 1.4 A (±10%)
5VDC @ 2.1 A (±5%)
3.3 VDC @ 6.1 A (±5%)
Maximum Output Power 57W Combined
Heat Dissipation 17W
Isolated User 24VDC Output None
Output Protection for Over Current,
Over Voltage, and Over Temperature
Self resetting for all three voltage outputs
to base
Under Input Voltage Lock-out 55–65 VAC
Over Input Voltage Lock-out 265–280 VAC
Input Transient Protection Varistor, plus input choke and filter
Operating Design Life 10 years at full load at 40°C ambient and
5 years at 60°C ambient
P3-01AC General Specifications
Operating Temperature 0°C– 60°C (32°F–140°F),
Storage Temperature -20ºC–70ºC (-4ºF–158ºF)
Humidity 5 to 95% (non-condensing)
Environmental Air No corrosive gases permitted
Vibration IEC60068-2-6 (Test Fc)
Shock IEC60068-2-27 (Test Ea)
Enclosure Type Open equipment
Voltage Withstand
(dielectric) 1900 VDC applied for 2s
Insulation Resistance >10MV@ 500VDC
Module Location Power supply slot in any local, expansion, or remote
base in a Productivity3000®System.
Weight 345g (12.1 oz)
Agency Approvals UL508 file E157382, Canada & USA
UL1604 file E200031, Canada & USA
CE (EN61131-2*)
This equipment is suitable for use in Class 1,
Division 2, Groups A, B, C and D or non-hazardous
locations only.
Hot-Swapping Information
Note: This device cannot be Hot Swapped.
IMPORTANT!
WARNING: Explosion hazard – Substitution of components may
impair suitability for Class I, Division 2.
*Meets EMC and Safety requirements. See the Declaration of Conformity for details.
