Aurora AU650MA Manuel utilisateur
AU650MA
Model No.
1-800-327-8508
USA Only
1-310-793-5650
International
Email: [email protected]
For more information, please visit us at:
www.auroracorp.com
Shredder User Manual
Please read these operating instructions before using the unit.
™
3ENGLISH
WARNING:SAFETY INSTRUCTIONS, READ BEFORE USING!
Read instructions before use.
Avoid touching the document
feed opening with hands.
Product is not intended for use by
children (product is not a toy).
Do not insert foreign objects into
the paper entry slot.
Do not spray or keep any
aerosol products in or around the
shredder.
Keep loose clothing or jewelry
away from the paper entry slot.
Avoid getting hair near the
paper entry slot.
•AlwaysturntheshredderoffandunplugthepowercordfromtheACoutletwhen
notinuse,beforecleaning,moving,oremptyingthewastebasket.
•RISKOFFIRE.Neveruseanypetroleumbasedorflammableoilsorlubricants in or
around the machine as some oils can combust causing serious injury.
•NEVER dispose of flammable chemicals or materials that have come into contact with flammable
chemicals (for example, nail polish, acetone and gasoline) in the shredder basket.
•Nevershredlargepaperclips,windoworinsulatedenvelopes,continuousforms,
newsprint,boundpages(forexample:notepads,checkbooks,magazines,etc...),
transparencies,laminateddocuments,cardboard,anyitemswithadhesives,hard
materialsorplastic(exceptCreditCards).
•A socket-outlet should be near the equipment and be easily accessible.
•Never let the wastebasket become full. This will lead to shredded material being pulled back up into
the shredder and cause jams.
•Never place the shredder near water or any heat source.
•Do not use the shredder if the power cord is damaged in any way.
•Do not attempt to service this product yourself as doing so may expose you to sharp cutting blades
and/or electricity and will void the manufacturer's warranty.
•Never try to clean or clear the shredder blade.
•Never shred beyond the specified sheet capacity. This may result in extensive damage to the machine.
4ENGLISH
OPERATION
INSTALLATION
PaperShredder
OperatingInstructions
Installation
Operation
Maintenance
Troubleshooting
Service Center
Limited Warranty
*ONEFOLDEDSHEETOFPAPEREQUATESTO2SHEETSOFPAPER
Heavier paper, humidity or other than rated voltage may reduce shredding capacity.
Sheet Capacity
Paper Shred Size
Paper Entry Width
Credit Card Capacity
Duty Cycle
Voltage
6 Sheets of 20 lb. bond paper*
0.16 in. x 0.47 in. pieces
4 mm x 12 mm pieces
8.7 in / 220 mm
1 at a time
2 min. on / 30 min. off
120V~60Hz / 3.0 A
1. This model includes a built-in safety interlock mechanism, which requires the shredder to be correctly
mounted on to the included wastebasket. Located on the back center of the shredder, next to the
power cord, there is a curved flap-like shape that must FIT OVER THE OUTSIDE matching ridge
of the wastebasket. (FIGURE 1) THE SHREDDER WILL NOT OPERATE UNLESS IT IS PROPERLY
MOUNTED AS PICTURED.
2. A socket-outlet should be near the equipment and be easily accessible.
3. Connect the power cord to any standard 120 volt AC outlet.
Micro-cut shredders have very sharp exposed blades on the underside.
Use care when mounting the shredder on the wastebasket.
!Caution:
FIGURE1
5ENGLISH
OPERATION
ControlSwitch
Using the switch located on the unit, select one of the following settings by sliding the switch either left
or right. (FIGURE 2)
I AUTO/ON:
This setting allows the shredder to be automatically started by insert-
ing paper into the feed slot. Always feed the paper in as straight
as possible. When the paper has passed through, the shredder will
automatically stop.
READY:The green LED light indicates the shredder in “On” and
ready for use.
O OFF:
This setting turns off all features of the shredder. For safety reasons,
we recommend that you leave the shredder in the “Off” position
whenever the shredder is unattended or not in use.
R REV(REVERSE):
In the unlikely event of a paper jam, the reverse setting can be used
to help clear the cutters of paper that did not pass through. Never
attempt to clear a jam by using the reverse function until you have
emptied the wastebasket.
CONTINUED NEXT PAGE
FIGURE2
6ENGLISH
NOTE:
•Always turn off and unplug the shredder when not in use.
•This shredder will shred staples and small paper clips. It is recommended that you remove paper
clips whenever possible to extend the lifespan of your shredder.
OPERATION
CONTINUED NEXT PAGE
Paper/CreditCardEntry:
ShredSafe™ technology is an added safety feature incorporated in this particular
model. It is a new technology where the shredder is able to detect forced entry and
automatically cuts the power off, preventing further shredding.
To begin shredding, locate the control switch on the unit and select the “Auto” mode. The Green LED
light indicates the shredder is “On” and ready to use. Press the designated “PUSH OPEN” area on the
handle of the cover to open and expose the paper feed slot (FIGURE 3). Thecoverwillclickinto
apresetpositionwherethe“SHREDDERSTATUS”linemustalignwiththe“READY”
setting.
FIGURE3
READY:
TheshredderiscurrentlyonSTANDBYandreadytooperatewhenpaperisinserted.
With the feed slot now exposed, you can shred sheets of paper or 1 credit card per pass.
DISABLED:
The safety feature has been activated. All power to the SHREDDER
IS CURRENTLY SHUT OFF AND WILL NOT OPERATE until the cover
is returned to the “READY” setting. The cover has been opened
beyond the safe position (FIGURE 4).
AFTERUSE:
When shredding is completed, you can press the designated “PUSH
CLOSE” area on the cover to tilt shut the paper feed slot (FIGURE 5). It is
recommended to have the paper feed slot closed when shredder is not
in use to prevent any objects from accidentally getting into the feed slot.
FIGURE4
FIGURE5
7ENGLISH
•Only shred credit cards by feeding them vertically into the middle of the entry, releasing when
shredding begins. Never feed more than one credit card at a time.
OPERATION
•PowerOn:
The Green LED light indicates the shredder is “On”
and ready to operate when paper is inserted.
•Overheat:
The Red LED light indicates the shredder has shred continuously beyond the maximum running time
and overheating, the unit will automatically shut off. If this happens, switch the shredder Off for 30
minutes or longer before resuming normal operation.
LEDStatusIndicators:
Overheat/
PowerOn
8ENGLISH
MAINTENANCE
Warning:Failuretoproperlymaintainyourshredderwillvoidthewarranty.
Oil the shredder blades every month with basic vegetable, cooking oil or shredder oil. Follow oiling
procedure below (FIGURE 6). It helps to keep the shredder blades operating well over many years of
use.
Oilingprocedure:
1. Turn off shredder.
2. Apply shredder oil across paper entry.
3. Turn shredder in reverse mode for 3~5 seconds.
Note:lubricatingoilisNOTincluded.
• Donotsprayorkeepanyaerosolproducts
inoraroundshredder.
• DONOTUSECANNEDAIRONSHREDDER.
CLEANING:
• ALWAYS UNPLUG THE SHREDDER BEFORE CLEANING!
• Only clean the shredder by carefully wiping the unit with a dry soft cloth or towel.
• Do not clean or immerse shredder in water. Having the unit wet may result in damage or malfunction to
the electrical components. If the shredder happens to get wet, be sure to completely dry the unit immedi-
ately with a cloth or towel.
• Never use anything flammable to clean the shredder. This may result in serious injury or damage to the product.
FIGURE6
Shredder
Oil
DONOTUSE
AEROSOLPRODUCTS!
!Caution:
9ENGLISH
TROUBLESHOOTING
If there is a problem with your shredder, check below for the symptoms and steps to resolve. If you
continue to have problems, contact customer support at our Service Center 1-800-327-8508. DO
NOT ATTEMPT TO REPAIR BY OPENING THE SHREDDER HEAD. This will completely void the
product warranty.
Theshredderdoesnotworkatall.
1)Make sure the unit is pluggedin and that the outlet is in good working order.
2) Overheatingwithextendeduse: In the event that the shredder has shred continuously
beyond the maximum running time and overheated, the unit will automatically shut off. If this hap-
pens, switchtheshredderOfffor30minutes or longer before resuming normal operation.
3) Make sure the shredder head is correctly seated onto the included
wastebasket, with all the words and icons facing towards you.
The head unit is particularly designed to work only with the
integrated wastebasket. Aurora shredders are equipped with a
safety interlocking mechanism, which prevents the shredder from
working when the head unit is lifted, removed, or accidentally
knocked over. The shredder will not function unless the head unit is
properly mounted as pictured. (FIGURE 7)
4) BesureNOTtoopenthecoverbeyondthepresetposition, otherwise the ShredSafe™
feature will be activated and the shredder will be inoperable. The “SHREDDER STATUS” indication line
must align with the “READY” setting.
5) If using a plastic bag to line the wastebasket, please remove it. This may cause the shredder not to
operate properly.
6) The activation sensor of the shredder is located near the center of the feed slot. Be sure to feed
directly into the center area to activate the machine (especially applies to smaller pieces of paper
or credit cards).
Theshredderrunsin“Rev(Reverse)”modebutnotin“Auto(On)”mode.
While in “Auto” mode, the motor will not start running until paper is inserted into the feed slot. Set
the unit to “Auto” and insert paper to shred. The sensor that activates the shredder in Auto mode
CONTINUED NEXT PAGE
Coverovertilt
Disabledposition
Readyposition
FIGURE7
10 ENGLISH
TROUBLESHOOTING
is located directly in the center of the slot. If the paper you are inserting is narrow, it may not be activat-
ing the optical sensor. It is also possible that the feed slot has become blocked with paper. Insert an
index card or any rigid sheet of cardstock (old greeting card or folded file folder), directly in the center
of the feed slot, while applying force to help push the jammed paper through. This will usually clear any
paper blockage.
Howtoclearapaperjamintheshredder.
1) Switch the shredder over into Reverse (REV) mode. While in Reverse, the shredder will back up and
loosen the jammed paper. If required, you may need to tug and remove several sheets to effectively
clear the machine. When jammed paper is loosened or removed, switch back to the Auto-On mode
to continue shredding. Repeat steps if needed.
2) With stubborn situations where the reverse function does not help, you may loosen the jammed
paper with shredder oil (cooking oil is acceptable, nothing aerosol). Start by drizzling oil into the
feed slot where the paper is jammed. Let it soak for about 30 minutes to completely saturate. Return
the shredder back to Auto-Onmode. Ifrequired,anindexcardorarigidsheetof
cardstock(oldgreetingcardorfoldedfilefolder)canbefedintotheshredderto
helppushthejammedpaperthrough.
Theshredderisconstantlyrunningwhilein“Auto(On)”mode.
1) It is possible that the activation sensor, which starts the shredder, has become blocked with paper.
Insert an index card or any rigid sheet of cardstock (old greeting card or folded file folder), directly
in the center of the feed slot, while applying force to help push the jammed paper through. This will
usually clear any paper blocking the activation sensor and feed entry.
2) The activation sensor is being triggered by dust, debris, or oil. A cotton swab may be
used to clean the sensor. DO NOT USE CANNED AIR. The activation sensor of the shredder is
located around the center of the feed entry.
Usethickpaperstockorgreeting
cardtopushthejamthrough
Table des matières
Autres manuels Aurora destructeur de papier
Aurora
Aurora ShredSafe AU1050XA Manuel utilisateur
Aurora
Aurora AS1023CD Manuel utilisateur
Aurora
Aurora ShredSafe AU614XB Manuel utilisateur
Aurora
Aurora AU1275MA Manuel utilisateur
Aurora
Aurora ShredSafe AU740XA Manuel utilisateur
Aurora
Aurora AU1050XE Manuel utilisateur
Aurora
Aurora ShredSafe AU1014XA Manuel utilisateur
Aurora
Aurora AS120CM Manuel utilisateur
Aurora
Aurora JamFree AU1045XA Manuel utilisateur
Aurora
Aurora AU1230XA Manuel utilisateur
Aurora
Aurora AS1540CD Manuel utilisateur
Aurora
Aurora AU2442XA Manuel utilisateur
Aurora
Aurora JamFree AU1235XA Manuel utilisateur
Aurora
Aurora JamFree ShredSafe AU1040XA Manuel utilisateur
Aurora
Aurora AU1460XA Manuel utilisateur
Aurora
Aurora AU808MA Manuel utilisateur
Aurora
Aurora AU2025XA Manuel utilisateur
Aurora
Aurora AU608MB Manuel utilisateur
Aurora
Aurora AS1018CD Manuel utilisateur
Aurora
Aurora ShredSafe WM1245XA Manuel utilisateur
Manuels destructeur de papier populaires d'autres marques
Swingline
Swingline STACK-AND-SHRED200X&200XL 60X Mode d’emploi
GBC
GBC ShredMaster CC055 Manuel utilisateur
UNITED OFFICE
UNITED OFFICE UAV 190 A1 Manuel utilisateur
UNITED OFFICE
UNITED OFFICE UAV 190 A1 Manuel utilisateur
Rexel
Rexel Optimum AutoFeed+ 45X Manuel utilisateur
Martin Yale
Martin Yale 227284S1 Manuel utilisateur
