Auriol 101166-14-01 Manuel utilisateur
IAN 101166 IAN 101166
OWIM GmbH & Co. KG
Stiftsbergstraße 1
D-74167 Neckarsulm
Model No.: 101166-14-01/101166-14-02/
101166-14-03/101166-14-04/101166-14-05/
101166-14-06/101166-14- 07/101166-14-08
Version: 07/2014
done by Mukade Technical Documentation
page size: 6cm x 12cm
WRISTWATCH
Operation and safety notes
MONTRE
Instructions d‘utilisation et consignes de
sécurité
HORLOGE
Bedienings- en veiligheidsinstructies
3
101166_14_Auriol_BE_NL_02.indb 1-2 23/7/14 11:40 am
GB/IE Page 5
FR/BE Page 19
NL/BE Pagina 34
101166_14_Auriol_BE_NL_02.indb 3 23/7/14 11:40 am
3
WATER RESISIT
PM
101166-14-01/101166-14-06
12
11
10
9
8
4
3
2
1
FR
101166-14-02
6
8
3 10
5
11
14
2
4
1
13
1
8
6
9
3 5
2
4
7
7
12
101166_14_Auriol_BE_NL_02.indb 3 23/7/14 11:40 am
4
60
55
25
50
20
45
40
05
15
35
10
30
PM
FR
101166-14-03/101166-14-04 /
101166-14-05
6
8
1
7
11
14
2
4
312 13
5 10
PM
WATER RESISIT
/
/UP
101166-14-07/101166-14-08
8
4
2
6
179
3 5
101166_14_Auriol_BE_NL_02.indb 4 23/7/14 11:40 am
5 GB/IE
WRISTWATCH
§Proper use
The wrist watch displays the time and date. It also
has an alarm and can be used as a stopwatch. The
product is not intended for commercial use.
§Description of parts
1Day of the week display field
2START button
3Time field
4RESET button
5Second field / ”A” “P” “H” indicator
6MODE button
7Alarm symbol
8LIGHT button
9Hour signal symbol
10 Minute hand
11 Crown
12 Second hand
13 Hour hand
14 1st position
101166_14_Auriol_BE_NL_02.indb 5 23/7/14 11:40 am
6 GB/IE
General Safety Instructions
KEEP ALL THE SAFETY ADVICE AND
INSTRUCTIONS IN A SAFE PLACE FOR FUTURE
REFERENCE!
DANGER TO LIFE AND RISK
OF ACCIDENTS FOR
INFANTS AND CHILDREN!
Never leave children unattended with the
packaging material. Packaging material can
cause suffocation.
DANGER TO LIFE!
Batteries can be swallowed, which can prove
fatal. Consult a doctor immediately if anyone
swallows a battery.
Never take the product apart on any account.
Improper repairs could cause considerable
danger for the user. Only let qualified people
carry out any repairs.
Battery Safety
Information
CAUTION! RISK OF
EXPLOSION! Never recharge the
batteries.
Have a spent battery removed from the
instrument immediately. There is an increased
risk of leakage.
101166_14_Auriol_BE_NL_02.indb 6 23/7/14 11:40 am
7 GB/IE
Batteries must not be disposed of in household
waste.
Consumers are under a legal obligation to
dispose of batteries in the proper way.
Keep the battery out of the reach of children,
do not dispose of the battery in fire, do not
short-circuit it, and do not take it apart.
Failure to observe these instructions may result
in the battery discharging beyond its end
voltage, which poses a risk of leakage. If the
battery in your instrument has leaked, have it
removed immediately to prevent damage to the
instrument.
Avoid contact with skin, eyes and mucous
membrane. In the event of contact with battery
acid, rinse the affected area with plenty of
water and /or consult a doctor.
§Water resistance
This watch is water-resistant up to
3 bar in accordance with DIN 8310.
Do not press any buttons if the watch comes into
contact with water.
3 bar water
resistant
101166_14_Auriol_BE_NL_02.indb 7 23/7/14 11:40 am
8 GB/IE
§Replacing the battery
Note: Have batteries changed in a specialist
shop.
Have any repairs or battery replacements
carried out by a suitably experienced specialist
in order to avoid damaging the insides of the
watch.
§Operation
Press the MODE button 6to set the desired
mode:
For model 01-06: Time mode > Stop watch >
Alarm > Setting the time > Time mode.
For model 07-08: Time mode > Alarm mode >
Stop mode > Setting the time > Time mode.
For model 02-05: Press RESET button 4
to display Alarm, Press START button 2to
display Date.
§Setting the time and date
Press the MODE button 63 times to enter
Setting the time mode:
For model 01, 06-08:
1. The second field 5flash in the display.
2. Press the START button 2to set the second
field 5to 0.
3. Press the RESET button 4to confirm your
setting. The hour field flashes in the display.
101166_14_Auriol_BE_NL_02.indb 8 23/7/14 11:40 am
9 GB/IE
4. Press the START button 2to set the desired
value.
5. Press the RESET button 4to confirm your
setting. The minute field flashes in the display.
6. Press the START button 2to set the desired
value.
7. Press the RESET button 4to confirm your
setting. The month field flashes in the display.
8. Press the START button 2to set the desired
value.
9. Press the RESET button 4to confirm your
setting. The date field flashes in the display.
10. Press the START button 2to set the desired
value.
For model 02-05:
1. The second field 5and the day of the week
field 1flash in the display.
2. Press the START button 2to set the second
field 5to 0.
3. Press the RESET button 4to confirm your
setting. The minute field flashes in the display.
4. Press the START button 2to set the desired
value.
5. Press the RESET button
4
to confirm your setting.
The hour and week field flashes in the display.
6. Press the START button 2to set the desired
value.
7. Press the RESET button 4to confirm your
setting. The date field flashes in the display.
8. Press the START button 2to set the desired
value.
101166_14_Auriol_BE_NL_02.indb 9 23/7/14 11:40 am
10 GB/IE
9. Press the RESET button 4to confirm your
setting. The month field flashes in the display.
10. Press the START button 2to set the desired
value.
For all models:
11. Press the RESET button 4to set the day of the
week 1field. The names of the days of the
week are shortened as follows:
MO = Monday
TU = Tuesday
WE = Wednesday
TH = Thursday
FR = Friday
SA = Saturday
SU = Sunday
12. Press the START button 2to set the days of
the week.
13. Press the MODE button 6to enter the default
display.
Note: For model 01-06: Pay attention to the
symbols ”A” “P” “H” indicator 5in the display
when setting the hour value. A and P (A = a.m. /
P = p.m.) are used for the 12-hour time format. H is
used for the 24-hour format. Press the START button
2to set the desired value and format. Press the
RESET button 4to confirm your setting.
Note: For model 07-08: Press START button 2to
select 12/24 H format.
101166_14_Auriol_BE_NL_02.indb 10 23/7/14 11:40 am
