Aurender X100L Manuel utilisateur

X100L / X100S

High Resolution Music Server and Player

User Guide

New features and improvements are regularly implemented through upgrades via the Internet.

Details of the latest upgrades can be found in the online version of the user guide at

www.aurender.com

12 Fl. Ace High-End Tower 8, 84 Gasan Digital 1-ro, Geumchoen-gu, Seoul 153-797, Korea

Tel: +82-8668-7516 Fax: +82 31 728 8537

Table of Contents

Page

Warranty 3

Box Contents 3

Instructions 3

Positioning 3

Front Panel 4

Rear Panel 4

Quick Start 5

1. Connections 5

iPad Application Installation and Set Up

3. Selecting the Aurender Music Server 5

4. Entering passcode 5

5. Manually Checking for Upgrades 6

6. Setting Time and Language to iPad settings 7

7. Scan all files using the Scanner menu 7

8. Copying files to the Aurender 8

Aurender iPad Application 9

Technical Specifications 13

* iPad is a trademark of Apple Inc. 2

Two Year Warranty

The warranty period for Aurender Music Servers is two years including parts and labor. The warranty is

non-transferable and excludes damage due to (i) normal wear and tear, (ii) abuse, misuse, or neglect, (iii)

repair, attempted repair, or any modifications by anyone not authorized by TVLogic or its distributors. After

inspection, TVLogic will at its discretion repair, adjust or replace the product free of charge. Users are

responsible for shipping the products to TVLogic or an authorized service center, and Widealab will pay for

return shipping provided the repair is under warranty. Aurender Music Servers are automatically registered

when first logged onto the Internet. Only the serial number, date and IP address are recorded for warranty

purposes.

For any technical support issues, please contact support@aurender.com

iPad, Wireless Router, Internet, D/A Converter, Cables

The iPad is the user interface for Aurender Music Servers and a wireless router is needed to connect the

iPad to the Aurender Music Server. An Internet connection is needed to update software and for remote

support, if needed. A digital-to-analog converter is needed to convert digital signal to an analog signal.

Box Contents

Aurender X100 AC Power Cord

Instructions

Please read the instructions carefully before setting up the Aurender Music Server.

1. Be careful not to drop the device to avoid internal damage.

2. Do not disassemble the device.

3. Keep magnetic materials away from Aurender to prevent data damage.

4. Do not expose device to oil, dust, water, high humidity, or smoke.

5. Keep ventilation openings free from obstruction.

6. When cleaning, use only a soft cloth. Keep out of contact with water or other liquids.

7. All servicing must be performed by a qualified technician, or the warranty will be voided.

8. Unplug power cord during severe lightning or when unused for a long period of time.

9. Unplug the device from the outlet only after completely turning off the unit.

10. Always turn the power off before connecting or disconnecting any cables.

Please note that hard drives can break down. It is important to back up your music collection periodically to

a separate memory device. In the event of drive failure, TVLogic is not responsible for any loss of data. The

drive manufacturers will only replace faulty drives under warranty and do not compensate to any loss of

data.

Positioning

1. Place your device on a flat, horizontal, and stable surface.

2. Keep away from heat sources, such as radiators.

3. Do not stack other products on top of the Aurender.

4. Allow space around the device for ventilation.

5. Do not place inside an enclosed cabinet. 3

Front Panel

1. On/Off/Standby - In the default mode, pressing will power the unit on and completely off. In the Standby

mode, pressing the front panel button will put the unit into standby, and the unit will turn on instantly. In

standby mode, to turn the unit off completely, keep the front panel power button depressed until the

button light begins to flash and then release. Flashing will stop when the unit is off. To switch to the

Standby mode, go to the Server Menu under Settings of theAurender iPad application. Scroll to the

bottom to find the Standby On/Off button.

2. Display Menu - Press to cycle through 2 display options: Song Information and Playlist. Songs from

playlists may be selected using the four buttons on the right side of the front panel display. Use buttons

4 and 5 to scroll between playlists and button 2 to select a playlist. After the playlist is selected, press

button 2 again to start playback. Once the playlist is selected, buttons 4 and 5 buttons can be used to

select songs within the selected playlist. To see the Device Information Display, please keep the button

depressed for about three seconds until the display blinks, release the button and wait. The Device

Information Display with details about Server name, LAN/Wi-Fi status, IP address, and other details will

appear. To return to the normal display, press the button again.

3. Play/Pause - Press to start or stop playback.

4. Play Next - Press to skip to the next track.

5. Play Previous - Press to skip to the previous track.

6. AMOLED Display –To set display mode options, please go to Settings of the Aurender iPadApp.

Rear Panel

1. USB Audio Class 2.0 Output - Connect to the USB input of a USB compatible digital-to-analog

converter.

2. Gigabit Ethernet port - To connect to home networks and NAS devices. The Ethernet cable should be

connected to the network router before turning on the Aurender.

3. USB 2.0 data ports - For copying from external USB memory devices.

4. AC Power Switch - Press top to turn on, bottom to turn off. The rear panel power switch should be used,

only after the unit has been turned off completely. Abnormal shutdown or using the rear panel power

button while the unit is in operation or standby can cause the system to to into check mode. In this case,

a message will appear on the display stating that the unit is checking the system.

5. AC Power Socket - Connect to a power outlet with AC Power cord.

Quick Start

1. Connections

Connect the AC power cord to the AC socket on the rear panel (5) and power main using grounded

sockets and plugs. Do not turn on the power.

Use an Ethernet cable to connect the Ethernet port on the rear panel (2) to the router. The router

should be connected to the Internet and computer, in order to receive updates and conveniently

transfer files.

Connect the USB digital output on the rear panel (1) and connect it to a DA converter or an amplifier

with a USB digital audio input.

Always make sure that all devices are grounded before making any connections. This should be done

by connecting the power cords using grounded plugs and grounded sockets. In addition, all devices

should be turned off. If the devices are not grounded, a voltage potential difference between devices

can cause a voltage surge through the digital cable that can weaken and eventually damage sensitive

circuits in D/A converters and other devices.

2. iPad Application Installation and Set Up

Using the iPad, go to the App Store and type Aurender in the search window. Install the Aurender

application. The Aurender supports WAV, FLAC, Apple Lossless (ALAC), AIFF, APE and other formats.

3. Selecting the Aurender Music Server

Open the Aurender application and the Aurender Music Server will be shown on the Server menu. The

Aurender must be connected to the Internet and iPad.

Select the Aurender Music Server by tapping its name.

If no server is listed, tap Add Server at the bottom of the window and a window will appear asking for

the IP address. The IP address can be found by pressing the Display Mode button on the front panel

(top left) and keeping it depressed until the front display changes. Release the button. Find the IP

address and enter. To return the display to the normal mode, press the Display Mode button again.

4. Enter Passcode

Please enter the Passcode shown on the front display of the Aurender.

5. Manually Checking for Upgrades

Check for the newest version of the firmware and Upgrade to the new version, if needed.

After upgrading, the Aurender will reboot automatically. At this time, the iPad application needs to be

closed and restarted in order to be upgraded also.

6. Setting Time and Language to iPad settings

Time and Language can be set by using the menu at the bottom of the Server tab.

Aurender’s time and language should be set to the iPad time and language settings.

7. Scan all files using the Scanner menu.

Scanning will continue in the background, even when songs are selected and played. Please note that it

can take hours to scan large libraries.

After scanning is done, a pop up window will appear stating that the database is being downloaded. If

the download fails to finish or gets stuck, please move closer to the wireless router and press Update

song database. The time to download the database varies according to song database size and wireless

connection speed between the wireless router and the iPad. It can be a few seconds or a few minutes.

Note : When new files are added, the Aurender needs to scan the HDD and make a new database.

When the song database is updated after scanning, the iPad needs to download it. So, even though one

song is added to the 50,000 songs database, the iPad needs to download whole database, but it should

take less than a minute.

8. Copying Files to the Aurender

There are three ways to copy files to the Aurender’s HDD.

1. Use the Ethernet connection to copy files to the Aurender using a PC or Mac.

2. Connect a USB memory to the USB port on the rear panel.

Note : After song files are copied to Aurender, new songs will appear, only after the files are scanned and

the song database transferred to the iPad application. Files will be scanned automatically one minute after

additions or changes to the files.

PC Users

1. Press the Windows + R on your keyboard (START -> RUN).

2. Type in two back slashes (\\) and the IP address of the Aurender. (For example: \\192.168.1.171). The

Aurender IP address can be found in NAS under SETTINGS on the iPad application.

3. Click OK and a window will appear with a folder labeled ‘hdd1’. Open the folder.

4. A popup window will ask for a Username and Password. They can be found in NAS under SETTINGS in

the iPad application.

5. Drag and drop files in to hdd1 or in its sub-folders.

6. Sub-folders may be created, renamed, or deleted. To add a sub-folder, right click on the white space

and go to New -> Folder.

Note: Importing large libraries can take a very long time, so importing files in batches is recommended.

Mac Users

1. Locate the Finder menu bar at the top of your desktop.

2. Click GO -> CONNECT TO SERVER from the navigation bar.

3. Type in ‘smb://’ followed by your Aurender’s IP address. (For example: smb://192.168.1.171) The IP

address can be found in the iPad application under SETTINGS -> NAS.

4. Click Connect and a window will appear with a folder labeled ‘hdd1’. Open the folder.

5. A popup window will ask for a Username and Password. They can be found in the iPad application under

SETTINGS -> NAS.

Note: If the Aurender is connected through a Gigabit network, the transfer speed will be roughly 50MB/sec.

It could take 5-6 hours to copy 1TB of files. We recommend copying files in batches. The Aurender is able

to play back music and copy files simultaneously

Copying from USB Memory Devices

Insert a USB memory device already loaded with songs into USB port on the rear panel. In a moment, the

front display will show ‘USB Copying’. When all files have been copied, the display will blink ‘USB Copying

Done’. If the folder names are the same as the categories in the Aurender second row (All, Classic, Jazz,

Pop, Local), then the files will go into the respective folders. If the folder names are not the same, then the

files will go into Etc.

Copying from USB CD-ROM Drives

Connect a USB CD-ROM Drive to the USB ports and the Aurender will automatically rip the CD to the HDD

and tag songs with information from an internet database. The quality of conversion is as good as EAC and

other leading conversion software. However, please be advised that the song metadata on Internet

databases are often incorrect and need to be checked and edited.

It is much easier to edit song metadata using a PC or Mac. When using a leading converting software such

as dbPoweramp or Exact Audio Copy, there is no loss of data when files are converted from CDs to

uncompressed or lossless format. This is because the original data and the recorded data are compared

until they are exactly the same.

Aurender iPad Application

1. Browser Buttons - The top row buttons categorize songs according to the metadata of the the song file.

Tap Song, Artist, Album, Genre, Composer, or Conductor to browse through songs according to the file

meta tags. Or tap Folder to browse folders. Five of the second row buttons categorize songs according

to the folders on the Aurender Hard Drive. Excluding the “All”and “Misc”buttons, the other buttons are

named according to the folder name. The folder names may be changed by the user by changing the

folder name and enclosing it with square brackets - [foldername].

Since the X100L has two hard drives, five folders on each of the HDDs will be shown in the second row

browser buttons.To see the other set of five browser buttons for the other hard drive, swipe the

second row browser buttons to the left or right.

2. Smart Search Window –Type in artists, albums, genres, composers, conductors or file names and the

search results will appear as you type. To search numbers, an asterix(*) or a question mark(?) needs to

be added after the number you are searching for in order to get a valid search result.

3. Settings Icon - Press to open Settings menu

4. Quick Scroll Bar - For faster navigation, just tap a number or letter to jump to content starting with that

number or letter.

5. Contents Window - Scroll through content by flicking up or down. For faster navigation, use the quick

scroll bar on the right hand side. Just tap and scroll to jump to content starting with that number or letter.

6. Queue Window -Press any song in the contents window to add it to the queue. If you want to play a

song immediately, add it to a playlist, or find similar songs, long press the song in the contents window

and pop-up menu with these options will appear. Expand the Queue window by flicking the contents

window to the right. There will be a Consume button on the bottom. Consume On will delete songs from

the queue as they are played. To clear all songs from the queue except for the currently playing song,

long press the CLEAR button on the bottom and a “Clear all except for currently playing song”will

appear.

7. Edit Playlist Window –Press the Edit Playlist bar to expand. To edit playlists, press the blue arrow next

to the playlist name.

8. Song Information Window –To expand, flick the contents window to the right.

Playback Functions

Queue –To add songs to the queue, tap a song in the Contents Window and it will be added to the queue.

The selected song will be marked with a small arrow. Subsequently selected songs will be added to the end

of the queue. For the full queue view, flick the Contents window to the right. This will also reveal an Edit

button. To return the Song Contents window to original size, flick the screen to the left.

Instant Play - To instantly play a song, tap on the left hand margin of the song you want to play. An arrow

will appear next to the song title. The selected song will appear below the song that was last played.

Deleting songs from queue - Lightly flick the song title to the left or right, then tap.

Clearing the queue - Simply tap at the bottom of the queue. All songs will be deleted except for the

song that is currently playing.

To completely empty the queue, pause the current song, then tap once or tap twice.

Editing the queue - Swipe the contents-view pane to the right for the full queue view and tap edit. To

rearrange the order of play, locate the 3 horizontal stripes to the right of the song title. Touch and hold the

stripes and drag up or down.

Playback Controls

Other playback options - For more options, touch and hold the title of a song in the Contents window and

a blue pop-up screen will appear with Play Now, Add to Next, Replace Queue and Add to End menus.

Play Now- Selected songs are added to the queue to be played right now.

Add to Next –Selected songs are added to the queue to be played after the current song

Replace Queue –Clears current queue and replaces queue with selected songs

Add to End –Selected songs are added to the end of the queue.

The touch and hold function also works for specific artist, album, genre, composer, conductor, index bar, or

even categories. 500 is the maximum number of songs possible in a queue or playlist. Only the first 500

songs will be added, if the selection contains more than 500 songs.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Aurender Lecteur MP3

Aurender

Aurender S10 Manuel utilisateur

Manuels Lecteur MP3 populaires d'autres marques

Blaupunkt

Blaupunkt Compact Drive MP3 Manuel utilisateur

Memorex

Memorex MMP9008 - 8GB USB 2.0 Manuel utilisateur

Meizu Electronic Technology

Meizu Electronic Technology E5 Manuel utilisateur

Naxa

Naxa NMV-173NX Manuel utilisateur

Philips

Philips PSA250 Manuel utilisateur

Zipy

Zipy go! Waving Manuel utilisateur

Sylvania

Sylvania SMPK4068 Manuel utilisateur

Sony

Sony NW-MS7 - Memory Stick Walkman Manuel utilisateur

Irradio

Irradio RF-42UC Manuel utilisateur

NABAIJI

NABAIJI SWIM MUSIC 100 Manuel utilisateur

Laser

Laser MP3-A9-4GB Manuel utilisateur

Samsung

Samsung YP-T7F Manuel utilisateur

Savant

Savant SMS-1001-00 Guide de référence rapide

Trevi

Trevi XP 71 BT Manuel utilisateur

AGPtek

AGPtek C2 Manuel utilisateur

MobiBlu

MobiBlu DAH-1500i Manuel utilisateur

Denver

Denver MPS-201 Manuel utilisateur

Steren

Steren MP3-002 Manuel utilisateur
