August DTV700B Manuel utilisateur
August International Ltd
United Kingdom
Telephone:+44 (0) 845 250 0586
www.augustint.com
7 Inch Digital TV & Media Player
TV NUMERIQUE 7 POUCES et LECTEUR DE MEDIA
7 ZOLL DIGITAL TV & MEDIA PLAYER
TV DIGITALE 7 POLLICI & LETTORE MULTIMEDIALE
TV DIGITAL 7 PULGADA y LECTOR DE MEDIA
DTV700B
Thank you for buying our August TV. You may already be familiar with using
a similar product but please take time to read these instructions carefully. It is
designed to familiarise you with the product’s many features and to ensure
that you get the very best from your purchase.
To ensure your safety and the safety of others, please ensure you read the
Safety Instructions before you use this product.
Please ensure the product and its accessories are disposed in compliance with
WEEE (Waste Electrical and Electronic Equipment) Directive and other
regulations. Please check with your local authority for disposal regulations.
If you need help, please contact our Customer Service:
Telephone: +44 (0) 845 250 0586
Email: [email protected]
Safety
Disposal
Customer Service:
User Manual
Quick Start Guide
DTV700B
It is suggested that you use a roof top aerial when scanning for TV channels
for the first time. If any signal is detected, the channel information will be
saved onto the TV, you may then switch back to the portable antenna
supplied and change your location to find the best place to receive the
signal.
Connect the device to the mains power or use the built-in battery, press and
hold POWER on the device for 3 seconds to turn it on.
When turning on the device for the first time, “Installation” will show,
follow the instructions to select Country and OSD Language, then press
<OK>, the auto search will then start. Once the search has finished, press
< or < to select channels. Press <OK> to open the Sub Menu and
select TV/Radio to switch between Freeview TV and Radio channels.
If you have done the first time installation before, and would like to search
for Digital Freeview channels again, or if you have moved to a different
region and need to scan channels again, press MENU, select “Installation”,
choose the Scan Mode, press <OK> to start the search. Once the search has
finished, press < or < to select channels. Press <OK> to open the
Sub Menu and select TV/Radio to switch between Freeview TV and Radio
channels.
To play video, music, photos or PVR on a SD/MMC card or memory stick,
insert the card or memory stick to the card slot or USB port, press MENU
to select Multimedia, then select “Music”, “Photo”, “Movie” or “PVR”,
press <OK> to enter the list, or press <AUDIO>, <PHOTO> or <VIDEO>
on the remote to enter music, photo or movie list. Select a file and press
<OK> to Play.
▲▼
▲▼
>>
>>
1.
2.
3.
4.
5.
Please note the included portable antenna may only be used in areas where
signal is very strong. As mentioned on the Freeview website, only some
households might be able to use a set top aerial at present. This only applies
if you live in an area with coverage close to a transmitter, but reception
would still be unreliable and they strongly recommend that you use a roof
top aerial for good reception.
The reception will improve along with the progress of the Digital
Switchover Program. Reception may also be affected by various factors
such as how close you are to transmitters, tall buildings, thick walls,
ceilings and weather etc.
For any further queries, please telephone August International Ltd helpline
6.
7.
1. Safety Instructions
2. Accessories
3. Part Names and Functions
4. Connection
5. Unit Operation
6. Recharge the Battery
7.
8. Troubleshooting
9. Warranty
Specifications
1
3
4
9
10
38
39
40
41
-1-
1. Safety Instructions
Maintenance
Please unplug all connection wires before start cleaning this machine.
Storage and Use
v
v
v
v
v
v
v
v
v
v
v
v
v
v
Never expose
the TV set to
moisture,dust
oil or smoke.
v
v
Never put this
machine in
containers that
are unstable as
this may cause
damage.
Never extrude
or chafe this
machine with
sharp objects.
Keep this
machine away
from hot or
cold places.
Working
temperature of
this device is
0 C~50 C,
storage
temperature is
-10 C ~ 60 C.
ﾟﾟ
ﾟﾟ
Keep the TV
set away from
water or damp
environment.
Avoid
dropping or
exposing to
impacts.
Please wipe the
display screen
and buttons with
a softcloth. Only
clean the screen
with professional
LCD TV screen
cleanser.
Never wipe this
machine with an
abrasive cloth,
detergent
powder, alcohol
and benzene etc.
various
propellants or
chemical
cleaning products.
-2-
1.Please do not tune your headphone / earphone at high volumes, otherwise,
it may lead to ear damage.
2.For open-designed earphone, to avoid annoying those close by, please tune
down the volume.
3.In case of any tinnitus, please turn down the volume or stop using this
machine.
4.It is recommended by aurists that the earphones should not be used
continuously for a prolonged period.
For the sake of safety for yourself and others, please do not watch the TV
while driving.
1.Use only the supplied power adaptor with this device. Failure to do so can
cause damage to the device and risk personal injury.
2.For the sake of safety, when you do not intend to use the display, please
switch off the AC adaptor or car adaptor.
A few highlights or dark spots may appear on the LCD screen. It is a very
common phenomenon of active matrix display technology, and does
Alcohol
-3-
Earphones
TV Aerial
User manual
AC/DC adaptor Remote control
2 Accessories.
-4-
1. CH+/CH- button: menu / channel selection
2. Volume+/- button: increase / reduce volume
3. Power button: Press and hold the button for 3 seconds to switch
on the device, press the button to switch off the device
3. Part Names and Functions
3.1 Front
3.2 Back
1
1. Coaxial Aerial Socket
2.
DC-IN Socket
4. Table Stand Lock Switch
Reset
3.
5. Table Stand
6. Mounting Bracket Holes
2
3
1
3
4
6
5
2
S/N: 700B1100001
DTV700B
v
v
DTV700B
-5-
3.3 Top
1.
2
3
.
.
12 3
Menu button
Return button
OK button
-6-
3.5 Remote Control
3.5.1 Remote Button Functions
2
3
13
1
6
7
11
14
18
4
5
9
8
10
12
15
16
17
3.4 Left Side
1. Telescopic Antenna
2. SD/MMC/MS Card Slot
3. USB Port
4. Headphone Socket
5. Power Indicator:
Indicator lights when the power adaptor is plugged
in; Red whilst the battery is charging and green
once the battery is fully charged.
1
2
3
4
5
-7-
1.
2. Egg timer function
3. Mute or unmute
4. Video mode
5. Photo mode
6. Music mode
7. Exit
8. Electronic Program Guide
9. Menu
10. Next track in Music Player mode
11. Previous track in Music Player mode
12.
13.
14.
15.
16.
17.
18.
Power off *
Up / Channel up
Down / Channel down
Left / Volume down
Right / Volume up
OK / Confirm selection
Fast forward a track or video
Fast rewind a track or video
-8-
3.5.2 Use of the Remote Control
Please remove the PVC packaging before using the remote control for the first time.
1.Do not expose the remote control to direct sunlight or very strong/bright light.
2.Do not drop or step on the remote control or subject it to shocks.
3.Keep the remote control away from extreme hot or humid environment.
4.Keep the remote control away from water.
Operating range
1.It may not be possible to operate the
device if there are obstacles between
the remote sensor and device sensor.
2.Use the remote control no further than
5 meters away from the sensor on the TV.
3.The receiving angle range should
be .
Replacing the battery
If the remote control does not function or if the operating range becomes
reduced, replace the old battery with a new one.
Remove the old battery, then insert the new battery into the battery holder
with the + side facing upwards.
a
b
Push back the holder.
+
Lithium battery(CR2025)
30
<5m
v
v
30
DTV700B
*Please note that the device can be switched off using the POWER button
on the TV or Power Off on the remote, it can only be switched on using the
POWER button on the TV.
-9-
4. Connection
4.1 Connecting the power supply
1.Connect the DC output of the AC/DC adaptor to the DC IN 5V socket on
the device.
2.Plug the power adaptor to the AC power socket.
4.2 Connecting the earphones
Connect the earphone plug to the headphone socket on the device.
*Note:
If earphones are used, sound is only transmitted through the earphones, and
no sound is available from the stereo speakers of the device.
Earphones
1
2
*Note:
1.Please ensure proper disposal of used batteries.
2.To prevent leakage of fluid from the lithium battery, remove the battery when
not using the remote control for a long period of time. If the battery leaks fluid,
carefully wipe it out of the battery case, then change to a new lithium battery.
5. Unit Operation
5.1 Initial Installation
After you first switch-on your device, an easy installation menu is displayed
that allows you to set your location preferences and scan for channels:
Item Description
Country Press <◄> or <►> to select country
OSD Language Press <◄> or <►> to select On Screen Display language
Time Zone Press <◄> or <►> to select Time zone
Summer Time Press <◄> or <►> to adjust daylight saving time setting
Scan Mode Press <◄> or <►> to select scan mode
LCN Press <◄> or <►> to adjust Logical Channel
Number Settings
Antenna Power The device can output 5V power from the coaxial
aerial socket, press <◄> or <►> to select Antenna
Power ON if your external aerial takes 5V input via
its coaxial plug.
Key Function
<><>▲▼ Navigate up and down
<◄><►> Set a specific option
<EXIT> Save and return to Main Menu
<OK> Confirm to start the scan
-10-
S/N: 700B1100001
5.2 Channel Scan
In the Installation menu select Auto as the scan mode then press <OK> to start
an automatic channel search.
After the scan has finished, you can start watching any channels which have
been found. If no channels are found, select YES to scan again or NO to return
to the installation window.
5.2.1 Auto Scan
Key Function
<>EXIT During a scan, if channels have already been found,
you can press <EXIT> to abort the rest of the scan
and begin watching the found channels.
Item Description
Bandwidth Press <◄> or <►> to modify bandwidth values
Start Frequency Press <◄> or <►> to modify start frequency values
End Frequency Press <◄> or <►> to modify end frequency values
Key Function
<><>▲▼ Navigate up and down
<◄><►> Modify values
<OK> Confirm to start the scan
5.3 TV/Radio Operation
After you switch the device on, it will automatically return to playing the
channel which was active before the device was turned off. If no channels are
saved in the memory, it will display the installation menu allowing you to rescan.
To open up the Main Menu at any time, you can press the MENU button.
-11- -12-
5.2.2. Manual Scan
In the Installation window, select Manual as the scan mode and press <OK> to
begin a Manual Scan.
-13-
Key Function
Subtitle
Record
TV Sub Menu Function List:
Channel List
Teletext *
Zoom In
Info
EPG
Time Shift
TV/Radio
Favorite
Audio
Key Function
Radio Sub Menu Function List:
Channel List
EPG
TV/Radio
Favorite
Audio
5.3.1. TV Channel List
To access the TV Channel List, press <OK> to display the TV Sub Menu and
then select the TV Channel List option. The channel list shows a list of all the
channels found during the last channel scan.
-14-
*Note: The Teletext function is not available for the UK.
Key Function
<><>▲▼ Navigate menu items
<OK> Confirm choice
<◄><►> Navigate menu items
<>EXIT Return to TV/Radio
For more settings, pressing <OK> whilst watching TV or Radio will bring up
a sub menu.
Use the < > and < > to navigate through the channel list and press <OK> to
switch to the selected channel.
Press <EXIT> to leave the channel list and return to the channel you were
watching.
▲▼
Key Function
<OK> Display TV Sub Menu and confirm the choice
<><>▲▼ Navigate through the Channel List
<EXIT> Leave Channel List window
Table des matières
Autres manuels August Lecteur multimédia
