PG300

Personal GPS Locator

OWNER’S MANUAL

NOTICES AND SPECIFICATIONS

About GPS System and Location Accuracy

The Global Positioning System (GPS) is operated by the US government, which is solely responsible for its accuracy and

maintenance. The system is subject to changes which could aﬀect the accuracy and performance of all GPS equipment. In

addition, the GPS system itself limits the accuracy of the distance indicated on the device’s display to within approximately

3-5 meters of the actual saved location. For more information about GPS, visit Audiovox Electronics Corporation’s Web site

www.audiovox.com.

About GPS Signals

This device must acquire GPS satellite signals to operate. The device may not be able to acquire signals if located indoors

or near tall obstructions (such as trees or tall buildings). Go to an area free from tall obstructions to use the device. When

the device acquires satellite signals, the GPS satellite ( ) indicator is steady. When it loses satellite signals, or the device

cannot acquire a GPS signal, the GPS satellite ( ) indicator ﬂashes.

This product is designed to provide direction to a saved location. It is not designed as a monitoring device for tall

obstructions, hazardous or weather conditions, or other factors that may aﬀect safety while using this device.

Warning

This handheld device is only intended to be used as a supplemental navigation aide. The user assumes all responsibilities

associated with the use of this product. It must not be used for any purpose requiring precise measurement of location,

direction, distance, or topography. This device should not be used for navigating any aircraft or vehicles. It is the user’s sole

responsibility to exercise proper judgment when using this product under any conditions.

Vehicle Use Notice

Audiovox is committed to safety and responsible use. Do not use this GPS device to navigate while driving a motor vehicle.

Attention to this device while driving can distract the motor vehicle’s operator, creating an unsafe situation. Injury, death,

or property damage may result if the operator fails to adhere to safe driving practices. It is the driver’s sole responsibility

to operate the vehicle in a safe manner. The device should not be mounted in a vehicle in a manner to distract, impair the

view, or in any way interfere with the motor vehicle’s operator or the motor vehicle’s safety features (such as an air bag).

Windshields and vehicle windows integrated with metallic materials, such as defrosters or tinting ﬁlm, can degrade GPS

reception inside a vehicle.

Liability Notice

In no event will Audiovox be liable for any incidental, special, indirect, or consequential damages resulting from the use,

misuse, or inability to use this product or from defects in the product. Some states do not allow the exclusion of incidental or

consequential damages, so the stated limitations may not apply therein.

CONTROLS AND INDICATORS

1. Store/Set ( ) Button - Press to save a setting.

- Press to turn on the backlight. The backlight will remain on for

twenty seconds.

2. Battery ( / ) Indicator - Indicates amount of battery

charge remaining. Displays when the battery is fully

charged. Displays and ﬂickers when battery power is

insuﬃcient.

3. GPS Satellite ( ) Indicator - Steady when GPS signal is

locked. Flashes when acquiring GPS signal.

4. On/Oﬀ/Mode ( ) Button - Press and hold to turn unit on/oﬀ.

- Press to change mode.

- Press to turn on the backlight. The backlight will remain on for

twenty seconds.

5. Direction Arrow ( ) - Points to the North when in Compass

Mode. Points to the stored location when in Location Mode.

6. Units Indicator - Displays time (T), degrees (O), yards (yd), miles

(ml), kilometers (km), or meters (m).

7. Favorite ( ) Indicator - Lit when in Favorite Location Mode.

8. Car ( ) Indicator - Lit when in Car Location Mode.

9. Home ( ) Indicator - Lit when in Home Location Mode.

10. Compass ( ) Indicator - Lit when in Compass Mode.

11. Time ( ) Indicator - Lit when in Time Mode.

12. Data Display Area - Data displayed depends on the mode

selected.

INSTALLING THE BATTERIES

OPERATING THE UNIT

To turn the unit on:

1. Press and hold the On/Oﬀ ( ) switch for three seconds.

2. Wait for the GPS signal to lock. The GPS Satellite ( ) Indicator will be steady when locked. If the GPS signal is not

locked, the time will not display and location modes will not operate.

Note: The GPS signal may not lock when you are indoors. To receive the best signal, use the GPS Locator outdoors. Hold

the unit face up towards the sky. Move away from tall buildings, trees or overhead obstructions.

To turn the unit o:

1. Press the On/Oﬀ ( ) switch. The backlight will light.

2. When the backlight is lit, press and hold the On/Oﬀ ( ) switch for three seconds.

To change mode of operation:

1. Press the Mode ( ) Button to change the mode in the following sequence: Time Mode ( ), Compass Mode ( ),

Home Location ( ), Car Location ( ), Favorite Location ( ).

Before attempting to operate your GPS Locator, install two AAA batteries

(not included) as described below:

1. Using your ﬁnger, slide the battery cover in the direction of the arrow.

2. Install two AAA batteries. Make sure that the proper polarity (+ or -) is

observed.

3. Slide the battery cover back onto the unit until it locks.

SETTING UP THE GPS LOCATOR  DO THIS FIRST

Before using the GPS Locator, to make the device operational, you will have to set the time zone to your location and

calibrate the compass.

Setting Your Time Zone

1. Press the Mode ( ) Button repeatedly until the Time ( ) Indicator appears.

2. Press and hold the Store/Set ( ) Button for three seconds. A number will begin ﬂashing on the display. This indicates

that you are making changes to the time zone.

3. Press the Store/Set ( ) Button to scroll through the numbered choices. See the chart below for the proper number

assigned to your time zone.

4. Once you have selected your time zone, press the Mode ( ) Button to ﬁnish. Your local time will now be displayed.

Time Zone Chart for the USA

Example: If you are in Miami (Eastern Standard Time Zone), the correct setting is - 5.

Standard Time Daylight Time

Eastern Time Zone - 5 - 4

Central Time Zone - 6 - 5

Mountain Time Zone - 7 - 6

Paciﬁc Time Zone - 8 - 7

Alaska Time Zone - 9 - 8

Hawaii - Aleutian Time Zone - 10 - 9

Calibrating the Compass

Note: During calibration, hold the GPS Locator horizontal to the ground with the display facing up.

1. Press the Mode ( ) Button repeatedly until the Compass ( ) Indicator appears.

2. Press and hold the Store/Set ( ) Button for three seconds. A zero in the middle of the display appears.

3. Turn the device three times slowly in one direction around the central point (see diagram below for location). Once the

process is ﬁnished, the compass will display a heading in degrees.

Central Point

Time Mode

In Time Mode, time is displayed in 12-hour (AM/PM) format.

1. Press the Mode ( ) Button repeatedly until the Time ( ) Indicator appears.

Note: If the GPS Satellite ( ) Indicator is ﬂashing, the GPS is not locked and the time can not be displayed.

Compass Mode

In Compass Mode, the Direction Arrow will always point North. The display will show the angle, from 0 to 360 degrees,

between North and the direction the unit is pointed towards.

Note: The digital compass may be aﬀected by large metal objects, such as buildings with metal, power lines, and steel

bridges. Move away from these types of objects when using this unit.

1. Press the Mode ( ) Button repeatedly until the Compass Mode ( ) Indicator appears.

MODES OF OPERATION

Location Mode

The GPS Locator stores and locates up to three diﬀerent locations. They are named Home Location ( ), Car Location ( ),

and Favorite Location ( ). You can switch between locations by pressing the Mode ( ) Button. Although each location

has a designated name (Home, Car, or Favorite), any type of location can be set.

In Location Mode, the Data Display Area displays the horizontal distance between your current location and the stored

location. The Direction Arrow ( ) points towards the stored location.

To set and store a location:

1. You must ﬁrst physically be at the location you want to store.

2. Press the Mode ( ) Button repeatedly until the Home Location ( ), Car Location ( ) or Favorite Location ( )

indicator appears.

3. Once you are in the desired location, make sure that you are connected to the satellite.

4. Press and hold the Store/Set ( ) Button until the location is set. The location has been set when you see a zero on the

display and all the Direction Arrows ( ) around the display are on. This indicates you have “locked-in”that location.

To return to a location:

1. Select the desired location (Home, Car, or Favorite) on the device. At this point, only one direction arrow on the

circumference of the display will light up. This indicates what direction you need to head towards. The digital read out in

the display represents the distance, in either meters or yards, you are from the desired location.

Note: If the GPS Satellite ( ) Indicator is ﬂashing, the GPS is not locked and distance and direction can not be

displayed.

2. Press the Store/Set ( ) Button to change the units of measurement from yards to meters or from miles to kilometers.

Note: If distances are greater than 1,999 meters, the unit will display distances in miles/kilometers.

3. As you follow the arrow and get closer to the location, the digital read out will decrease until it reaches zero, indicating

you are at your desired location.

TROUBLESHOOTING

• If the unit can not be started or used normally, please make sure that the batteries are installed correctly.

• If you are not using your unit for a long period of time, please remove the batteries.

• If you are moving, the time required for GPS positioning may increase. Recommendation: When you start the unit, please

stop in order to reduce this time.

• Do not use or store the unit in a location that is subject to high temperature or humidity (for example, in a closed vehicle

or in direct sunlight) for a long time. The high temperature or humidity may impair the unit’s function.

• If the time information is incorrect, please enter the Time Zone Mode to set the time zone correctly.

• Do not use or store the unit close to equipment that produce strong magnetic ﬁelds (such as electrical products or

magnets). The magnetic materials may make the unit indicate an incorrect direction.

• If new batteries are installed or the direction can not be precisely indicated, please recalibrate the compass.

FCC NOTICE

This device complies with Part 15 of the FCC rules and regulations. Operation is subject to the following conditions:

• The device may not cause harmful interference, and

• The device must accept interference received, including interference that may cause undesired operation.
