Audiovox ACC106 Manuel utilisateur
MODEL: ACC106
3-Hour Rechargeable Battery
with Home & Go Power Adapter
for Audiovox PVS69701 7" Portable DVD Player
Instruction Manual
Need More Help?
Please visit online help at
http://www.1800customersupport.com
1.To attach the rechargeable battery pack, slide it in to the corresponding positions on the
back of the unit.
2.Plug the connector from the battery into the DC-IN 9V jack on the side of the main DVD/
screen.
Condition and attention:
• When the battery power is low, the unit will stop operating.
• Do not short-circuit the terminals.
• The battery can only be recharged when the unit is OFF.
• Use only the included AC adapter to recharge the battery pack.
• Detach the rechargeable battery pack when not in use. (Even if the unit is off, it will still use
some power. This can completely discharge the rechargeable battery and cause it to
malfunction.)
• Recharge the battery when you are ready to use it again.
• If the rechargeable battery pack is not going to be used for a long time, discharge it and store
it in a place that is cool, dry and dark.
• While using the rechargeable battery, the air temperature should be between 41 - 95°F (5 -
35°C).
• To maximize the life of the rechargeable battery pack, recharge it at or below room
temperature.
• Never dispose of the rechargeable battery pack in fire or water.
• Do not open the rechargeable battery, refer servicing to qualified personnel.
810-P69795-110
Printed in China
ac adaptor use.pmd 3/23/2006, 5:25 PM1
Using the AC adapter
This unit can also be powered using the included AC adapter.
Charging the battery pack
Charge the rechargeable battery pack before using it for the first time.
When charging the battery, disconnect it from the unit.
USING THE RECHARGEABLE BATTERY PACK
Important:
• If a malfunction occurs, disconnect the plug
from the wall outlet at once.
• When the AC power supply cord is
connected, the power indicator on the AC
adapter will remain on although the unit is
turned off. Disconnect the power cord from
outlet when not in use.
• When the adapter is plugged in, the
apparatus is not completely disconnected
from the main power supply, even when the
power is turned off.
Cautions:
• Use of an incorrect type AC
adapter will damage the unit.
• Turn off the unit before unplugging the AC
adapter from the unit to avoid damage to
the unit.
• To prevent electrical shock, match wide
blade of plug to wide slot and fully insert.
• When the unit is not going to be used for a
long time, disconnect the AC power supply
cord from the AC outlet.
Caution:
• The included AC power supply cord
and AC adapter are for use with your
Audiovox PVS69701 only.
• When the unit is not going to be used
for a long time, disconnect the AC
power supply cord from the AC outlet.
Note:
The rechargeable battery pack only provides
power to the main DVD player/screen. It does
not power the second monitor.
1. To charge the battery, connect the included
AC power adapter to the DC-IN 9V jack on
the battery.
2.When the battery is charging, both the
power light and the charging light will
illuminate.
3.When the battery is finished charging, the
charging light will turn off. Disconnect the
AC power adapter from the battery.
1.Plug the AC adapter into the DC-IN 9-12V
jack on the second screen.
2. Connect the main DVD unit and the second
screen using the DC Line Cord included
with the main unit.
Note:
The battery cannot be
charged when it is
connected to the main unit.
MAIN DVD UNIT SECOND SCREEN
ac adaptor use.pmd 3/23/2006, 5:25 PM2
