AudioRange OTE 1000 Guide de démarrage rapide
Wireless TV Headphones
AudioRange OTE 1000
Easy Setup Guide
This device is intended for home and personal use only.
Keep the device dry and away from water. Water may damage the device.
Do not open the unit or battery. Opening the battery compartment violates this products
warranty.
The Wireless TV Speakers uses a lithium ion battery. Do not burn or place used
batteries/device in household trash.
Do not pull on cord to unplug this device, doing so may damage the cord.
Device should not be used if damaged or malfunctioning.
Make sure device is unplugged when cleaning.
Consult your doctor or physician when using this device around medical equipment such as
a pacemaker.
WARNING: Consult your doctor or physician if you have a pacemaker before using
Please read these safety instructions carefully before using your the Audiorange OTE-1000
Important Safety Instructions
Plug AC adapter into dock and place
headphones on dock to begin charging.
A blue LED will flash as the headphones
charge.
Allow up to 2 hours to charge.
2H Charge
Set-up Preparations
Locate Audio Connections on the
back or side of your TV.
AC Adapter
on back panel
If you are using RCA connections
please start with STEP 1a.
If you are using Optical connection
please start with STEP 1b.
if you are using the 3.5mm
headphone connection please
start with STEP 1a.
TV
STEP 1a:
Turn on TV.
There are two options for using
the 3.5mm/RCA cable depending
on your TVs connections.
Option 1: Plug the red/white RCA
cables into the matching ports on
the TV. Then plug the 3.5mm
in-line jack into the dock.
Option 2: Plug the 3.5mm in-line
jack into the TV. Then plug the
red/white RCA cables into the
matching ports on the dock.
Installation using
ANALOG Outputs
OR
TV TV
STEP 2a
On the side of the dock there is
a switch for ANALOG or DIGITAL.
Slide the switch to ANALOG.
STEP 3a
Remove headphones from the dock
and hold the power button for 3
seconds to turn the headphones on.
After 3-7 seconds you should begin to
hear audio.
STEP 4a
You have successfully setup your Audiorange
OTE-1000.
If you cannot hear any sound:
Increase the volume on your headphone
Increase the volume on the TV
Check that your TV’s audio settings are set to
external speaker
IMPORTANT: If you cannot
access your TV’s audio
settings, please refer to your
TV manual for help.
External Speakers
TV Speakers
Blue Tooth Speakers
Installation using
DIGITAL Outputs
STEP 1b
Turn on TV.
Plug the optical cable* into the
TV and dock.
*Remove plastic protective tips
at ends of cord.
TV
STEP 2b
On the side of the dock there is
a switch for ANALOG or DIGITAL.
Slide the switch to DIGITAL.
STEP 3b
Remove headphones from the dock
and hold the power button for 3
seconds to turn the headphones on.
After 3-7 seconds you should begin to
hear audio.
STEP 4b
You have successfully setup your Audiorange
OTE-1000.
If you cannot hear any sound:
Increase the volume on your headphone
Increase the volume on the TV
Check that your TV’s audio settings are set to
external speaker
IMPORTANT: If you cannot
access your TV’s audio
settings, please refer to your
TV manual for help.
External Speakers
TV Speakers
Blue Tooth Speakers
