Audiopipe APCL-6002 Manuel utilisateur
The front panel of the APCL-6002 contains both connections for RCA and speaker level
inputs, along with the audio controls as shown below.
1. Filter
2. Bass Boost
3. X-Over freq
4. Subsonic
5. Gain
6. Output
7. Input
8. Bass Level
The front panel of the APCL-6004 contains both connections for RCA and speaker level
inputs, along with the audio controls as shown below.
1. Front High Level Input
2. Rear Right RCA Input Jacks
3. Front Right RCA Input Jacks
4. Front Gain Control
5. Front Bass Boost Level
6. Front Filter Select Switch
7. Front High Pass Filter Control
8. Front Low Pass Filter Control
9. Power/Protect LED
10. Front High Level Input
11. Rear Left RCA Input Jacks
12. Front Left RCA Input Jacks
13. Rear Gain Control
14. Rear Bass Boost Level
15. Rear Filter Select Switch
16. Rear High Pass Filter Control
17. Rear Low Pass Filter Control
18. Rear Remote Volume Control
10
98653 421
7
11 12 13 14 18171615
1 2 3 4 5 6
78
The rear panel of the APCL-6002 contains power and speaker connections as shown
below.
1. Left Speaker Output
2. Right Speaker Output
3. Battery +12V Input
12 53 4
4. Remote Turn-On Input
5. Ground Input
1 2
3 45 6
7
The rear panel of the APCL-6004 contains power and speaker connections as shown
below.
1. RR Speaker Output
2. RL Speaker Output
3. FR Speaker Output
4. FL Speaker Output
5. Ground Input
6. Remote Turn-On Input
7. Battery +12V Input
Connections for power and speakers
APCL-6002
Connections for power and speakers
APCL-6004
We recommend to have the installation done by an Authorized Audiopipe Dealer.
Required power, ground wire and proper external fuse as below:
We recommend a fuse should be installed away 0.2m from the battery. The ground wire
should be connected directly with the chassis of your vehicle which should be metal to
metal ground point connection. The amplifier must be mounted securely at a solid, dry
and low vibration surface in the trunk or passenger area. Fix the amplifier in an open air
area to insure proper heat dissipation. Fix the amplifier in a place where can access easily
to set the input controllers. Install all amplifier cables as far as possible from car electrical
cables such as the car ignition cable.
Fuse
90 AMP
150 AMP
Model
APCL-6002
APCL-6004
Wire
2 Gauge
0 ~ 2 Gauge
The Audiopipe APCL-6002 2-channel amplifier can be used in a variety of system
applications. Here are some examples to help plan your own installation.
Bridged - Mono Subwoofer System
In this application the amplifier is bridged for mono operation to drive a subwoofer.
APCL-6002
In this application, the amplifier is used in stereo and drives two full-range (or satellite or
subwoofer) speakers. NOTE: A passive crossover must be used with satellite speakers.
2-Channel Full-Range, Satellite, or Subwoofer Stereo System
(Set INPUT SELECT Switch to STEREO)
APCL-6002
2-Channel Stereo System with Low-Pass
Bridged Mono Channel
The Audiopipe APCL-6004 4-channel amplifier can be used in a variety of system
applications. Here are some examples to help plan your own installation.
In this application the amplifier is bridged for mono operation to drive a subwoofer.
APCL-6004
4-Channel, Satellite, or Subwoofer Stereo System
APCL-6004
In this application, the amplifier is used in stereo and drives two full-range (or satellite or
subwoofer) speakers. NOTE: A passive crossover must be used with satellite speakers.
